▶ EnginePTO Power 45.6 hp (34.0 kW) 37.0 hp (27.6 kW) @ 2,100 rpm Alternator Not Published 12 V, 60 A Air Cleaner Not Published Dry type, dual element Engine Type In-Line Vertical, Water-Cooled Turbo Diesel Engine, CRDI Diesel, turbocharged and aftercooled Fuel System Common Rail Direct Injection (CRDI) Electronically controlled, high-pressure common rail Displacement 111.4 in³ (1,826 cc) 179 in³ (2933 cc) No. of Cylinders 3 3 Rated Engine Speed 2,600 rpm 2,100 rpm Cooling System Type Water-cooled Liquid cooled with overflow reservoir Engine Manufacturer KIOTI (Daedong) John Deere PowerTech™ 3029 EWR Engine Emissions Constraints Tier 4 Final Tier 4 (EPA Final Tier 4) Engine Power (Gross vs. Net HP) Gross: 50 hp (37.3 kW) Gross: 50.9 hp (37.4 kW) @ 2,100 rpm; Net: Not Published ▶ WeightTractor Weight with Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published Weight with ROPS and Loader Not Published Not Published ▶ HydraulicsPump Type Gear Tandem gear pump (implement + steering) Steering Flow Not Published 25.7 L/min (6.8 gpm) Implement Flow Not Published 43.1 L/min (11.4 gpm) Total Hydraulic Flow 55.1 L/min (14.5 gpm) 68.8 L/min (18.2 gpm) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 43.1 L/min (11.4 gpm) at a single rear SCV Overall Hydraulic Pump Flow 55.1 L/min (14.5 gpm) 68.8 L/min (18.2 gpm) No. of Optional Remote Valves 2 2 No. of Standard Remote Valves 0 1 ▶ Tire OptionsR3 Turf - Rear 21.5L-16.1 41X14.00-20 4PR R3; 44X18.00-20 4PR R3 (Premium) R3 Turf - Front 29X12.5-15 33X15.50-15 6PR R3; 33X12.50-15 6PR R3; 29X12.5-15 4PR R3 (Premium) Tire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Ag / R3 Turf / R4 Industrial / Snow R4 Industrial - Rear 14.9-24 17.5L-24 8PR R4; 19.5L-24 8PR R4; 16.9-30 10PR R4; 43X16.00-20 R4; 43X16.00-20 R4 (Premium); 18.4-30 10PR R4 R4 Industrial - Front 10-16.5 27/12LL-15 6PR R4; 10-16.5 8PR R4; 28X8.50-15 8PR R4; 12.5/80-18 12PR R4 R1 Agricultural - Rear 13.6-24 14.9-28 6PR R1; 16.9-28 6PR R1; 16.9-30 6PR R1; 18.4-30 6PR R1; 460/85R30 R1; 460/85R30 R1W R1 Agricultural - Front 8.0-16 9.5-24 10PR R1; 12.4-24 8PR R1; 320/85R24 R1; 320/85R24 R1W ▶ Pto & HitchPTO Rear 540 rpm 540 rpm @ 2,083 engine rpm; mechanical shift PTO Type Independent Independent Lift Control Type Position Position control with draft control; adjustable rate of drop Hitch Lift Capacity 2,716 lbs (1,232 kg) (24 in aft. of hitch) 3,968 lb (1,800 kg) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I Category II; convertible to Category I Hitch Lift Capacity (at 24”) 2,716 lbs (1,232 kg) 3,197 lb (1,450 kg) Rear 3-Point Hitch Lift Capacity 2,716 lbs (1,232 kg) (24 in aft. of hitch) 3,968 lb (1,800 kg) ▶ Fluid CapacityCoolant Capacity Not Published Open operator station: 2.85 gal (13 L) Crankcase Capacity Not Published 9.0 qt (8.5 L) (with filter) Fuel Tank Capacity 11.9 gal (45 L) Open operator station: 15.6 ± 0.44 gal (71 ± 2 L) Front Axle Fluid Capacity Not Published 2WD: 16.1 qt (15.2 L); MFWD: 8.0 qt (7.6 L) Transmission / Hydraulic System Capacity Not Published 8.36 gal (38 L) (9x3) ▶ Loader & AttachmentsLoader Lift Height 109 in (2,768 mm) (to pivot pin) 124 in (3,150 mm) Loader Breakout Force 3,900 lb (1,769 kg) (at pivot pin) 4,354 lb (1,975 kg) (measured at pivot) Price for Backhoe Option Not Published Not Published Price for Mid-Mount Mower Not Published Not Published Quick Attach Loader System Built-in parking stand (quick attach/detach); single-lever joystick w/ float; bucket level indicator Parkable loader (parking system; no tools required for removal/installation); optional John Deere skid steer attachment carrier (tool-free attachment changes) Loader Lift Capacity (Full Height) 2,660 lb (1,207 kg) (at pivot pins) 3,225 lb (1,463 kg) (measured at pivot) ▶ Transmission & DrivetrainClutch Dry type, single stage Dual clutch, 11 in (PowrReverser) No. of Speeds 8F/8R 9F/3R Transmission Type Synchronized H-Shuttle SyncShuttle™ Max Travel Speed (Forward) 17.3 mph (27.9 km/h) Not Published Max Travel Speed (Reverse) 16.9 mph (27.2 km/h) Not Published Differential Lock & Limited Slip Options Rear differential lock (standard) Mechanical differential lock (pedal) ▶ Chassis Steering & ControlsBrakes Wet multi disc Hydraulically actuated wet disc brakes Steering Hydrostatic power steering; tilt steering wheel Hydrostatic power steering Frame Type Not Published Not Published Front Axle Type Mechanical 4WD 2WD standard; MFWD optional Drawbar Capacity Not Published 1,675 lb (760 kg) (fully extended); 2,470 lb (1,120 kg) (short position) Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Adjustable suspension seat Deluxe adjustable vinyl seat with retractable seat belt ▶ Dimensions & ManeuverabilityWheelbase 71.3 in (1,810 mm) 80.7 in (2,050 mm) Overall Width 62.8 in (1,596 mm) Not Published Ground Clearance 15.2 in (387 mm) Not Published Height to Top of ROPS 92.0 in (2,338 mm) Not Published Height to Top of Cab Model Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes Not Published 137.8 in (3,500 mm) (2WD); 183.1 in (4,650 mm) (4WD); 153.5 in (3,900 mm) (4WD, Carraro axle) Overall Length with 3-Point Hitch 124.3 in (3,157 mm) 143.3 in (3,639 mm) ▶ Pricing Financing & WarrantyFinancing Options Available through KIOTI dealers 0% APR fixed rate for 60 months Base Price with Loader Not Published Not Published Warranty Length & Coverage Limited: Tractors (Non-Commercial Application) 24 months parts & labor; Extended (driveline): 48 months parts & labor 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) Base Price with Loader + Cab Not Published Not Published ▶ SourcesSpec sheet sources [1] tractordata.com [2] tractorgearbox.com [3] payeur.com [4] payeur.com [5] agro-specs.com [1] deere.com [2] johndeere.widen.net [3] deere.com
