▶ EngineEngine Manufacturer KIOTI (Daedong) John Deere Engine Model 3HT-TH4C 3029H Engine Type 3-cylinder, liquid-cooled diesel Diesel, turbocharged No. of Cylinders 3 3 Displacement 111.4 in³ 179 in³ Rated Engine Speed 2600 rpm 2100 rpm Engine Power (Gross) 50.3 hp 50 hp PTO Power 39.3 hp 37 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid cooled with overflow reservoir Air Cleaner Dry element Dry type with safety element Fuel System Not Published Electronically controlled, high-pressure common rail Alternator Not Published 70 A ▶ HydraulicsPump Type Gear Tandem gear pump (implement + steering) Implement Flow 9.62 gpm 11.4 gpm Steering Flow 6.87 gpm 6.8 gpm Total Hydraulic Flow 16.5 gpm 18.2 gpm Overall Hydraulic Pump Flow 16.5 gpm 18.2 gpm Hydraulic System Type Not Published Open Center Rear Remote Hydraulic Flow Not Published 11.4 gpm at a single rear SCV No. of Standard Remote Valves 2 1 No. of Optional Remote Valves Not Published 2 ▶ Fluid CapacityFuel Tank Capacity 12.7 gal 19.6 gal Coolant Capacity 2.1 gal Open operator station: 2.85 gal Crankcase Capacity 1.95 gal 9.0 qt (with filter) Transmission / Hydraulic System Capacity 11.4 gal 8.36 gal (9x3) Front Axle Fluid Capacity 1.48 gal 2WD: 16.1 qt; MFWD: 8.0 qt ▶ PTO & HitchPTO Type Independent Independent, mechanical engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional (2,000 rpm) Not Published Category, 3-Point Hitch Category I Category II, convertible to I Hitch Lift Capacity 2,998 lb 3,968 lb Hitch Lift Capacity (at 24”) 2,716 lb 3,192 lb Lift Control Type Position Position control, draft control, adjustable rate of drop ▶ Transmission & DrivetrainTransmission Type Hydrostatic (HST) SyncShuttle No. of Speeds 3 ranges (hydrostatic, infinite speeds) 9F/3R Max Travel Speed (Forward) 18.45 mph Not Published Max Travel Speed (Reverse) 12.92 mph Not Published Clutch None (hydrostatic transmission) Dual clutch, 11 in (PowrReverser) Differential Lock & Limited Slip Options Rear differential lock (standard) Mechanical, rear ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet multi-disc Hydraulically actuated wet disk brakes, self-equalizing and self-adjusting Seat Suspension & Adjustability Deluxe suspension seat Deluxe adjustable vinyl seat with retractable seat belt Front Axle Type Mechanical 4WD 2WD or MFWD Front Axle Rating Not Published Not Published Drawbar Capacity 1,655 lb (max. drawbar vertical load) 1,675 lb (fully extended); 2,470 lb (short position) ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 125.5 in 143.3 in Overall Width 62.8 in Not Published Wheelbase 71.3 in 80.7 in Ground Clearance 14.5 in Not Published Min. Turn Radius without Brakes 102.8 in (with brake applied) 137.8 in (2WD); 183.1 in (4WD); 153.5 in (4WD, Carraro axle) Height to Top of ROPS 96.8 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 93.0 in Not Published ▶ WeightTractor Weight (Base) 3,523 lb (DK5320SEH); 4,043 lb (DK5320SEH CAB) 5,335 to 5,809 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial, R14 R1 Ag / R3 Turf / R4 Industrial / Snow R1 Agricultural - Front 8-16 11L-15 R1 Agricultural - Rear 13.6-24 14.9-28 R3 Turf - Front 29-12.5-15 33X15.50-15 6PR R3; 33X12.50-15 6PR R3; 29X12.5-15 4PR R3 (Premium) R3 Turf - Rear 21.5L-16.1 41X14.00-20 4PR R3; 44X18.00-20 4PR R3 (Premium) R4 Industrial - Front 10-16.5 27/12LL-15 6PR R4; 10-16.5 8PR R4; 28X8.50-15 8PR R4; 12.5/80-18 12PR R4 R4 Industrial - Rear 14.9-24 17.5L-24 8PR R4; 19.5L-24 8PR R4; 16.9-30 10PR R4; 43X16.00-20 R4; 43X16.00-20 R4 (Premium); 18.4-30 10PR R4 ▶ Loader & AttachmentsQuick Attach Loader System Quick attach (QA) bucket, 66 in or 72 in 512 or 520M Loader Model KL5520; KL5521 (Cab models) 512 or 520M Loader Lift Height KL5520: 107.7 in; KL5521: 107.7 in 512: 113 in; 520M: 132 in Loader Lift Capacity (Full Height) KL5520: 2,474 lb; KL5521: 2,474 lb 512: 2,453 lb; 520M: 3,523 lb Loader Breakout Force KL5520: 3,895 lb; KL5521: 3,895 lb 512: 4,781 lb; 520M: 4,641 lb ▶ WarrantyWarranty Length & Coverage Non-commercial: 24 months, unlimited hours, parts and labor, 0% deductible; non-commercial powertrain (engine and driveline): 72 months, unlimited hours 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) ▶ ITC Company AccessoriesAccessories that fit None tagged yet
