▶ EngineEngine Manufacturer KIOTI (Daedong) Shibaura Engine Model 4A220T N4LDI-TA Engine Type Indirect injection, vertical, water-cooled, turbocharged 4-cycle diesel 4-cylinder turbocharged intercooled diesel, liquid-cooled No. of Cylinders 4 4 Displacement 134.1 in³ 135.2 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 54 hp 53.9 hp PTO Power 45.2 hp 41.3 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner High efficiency air filter with cyclone pre-cleaner canister Dry Fuel System Indirect injection Common rail direct injection Alternator 50 A, 12 V Not Published ▶ HydraulicsPump Type Tandem gear Engine-driven gear-type pump Implement Flow 9.88 gpm 12.7 gpm Steering Flow 4.33 gpm Not Published Total Hydraulic Flow 14.2 gpm Not Published Overall Hydraulic Pump Flow 14.2 gpm 12.6 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published 12.1 gpm No. of Standard Remote Valves 2 2 No. of Optional Remote Valves Not Published Up to 3 ▶ Fluid CapacityFuel Tank Capacity 18.0 gal 14.0 gal Coolant Capacity 2.51 gal 7.08 qt Crankcase Capacity 2.25 gal 6.87 qt Transmission / Hydraulic System Capacity 10.0 gal 12x12 Power Shuttle: 10.04 gal; HST: 9.25 gal Front Axle Fluid Capacity 2.17 gal 9.0 qt ▶ PTO & HitchPTO Type Independent Independent, with soft-start feature PTO Rear 540/1000 rpm 540 rpm (1-3/8 in 6-spline) Mid-PTO Availability Not Published Optional, 2,000 rpm Category, 3-Point Hitch Category II (Category I ends optional) Category I with extendable ball ends Hitch Lift Capacity Not Published 3,483 lb Hitch Lift Capacity (at 24”) 2,654 lb 3,086 lb Lift Control Type Position, Draft and Mixed control Position and draft control ▶ Transmission & DrivetrainTransmission Type Synchronized shuttle 12 x 12 power shuttle or 3-range hydrostatic No. of Speeds 12F/12R 12x12 Power Shuttle: 12F / 12R; HST: 3-range infinite Max Travel Speed (Forward) 16.42 mph Not Published Max Travel Speed (Reverse) 13.59 mph Not Published Clutch Dry type single plate, single stage Single stage dry type Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical engagement via right side heel pedal ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Wet disc type Internal wet disc brakes, individual control via independent foot pedals Seat Suspension & Adjustability Adjustable seat Deluxe suspended seat with armrests and seatbelts (vinyl seat on ROPS, cloth seat on cab), tilt steering Front Axle Type 4WD (bevel gear front wheel drive, push-button engagement) Cast steel 4WD front axle with center drive line and bevel-gear final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 128.6 in 132.3 in Overall Width 69.3 in 65.4 in Wheelbase 75.6 in 77.9 in Ground Clearance 17.5 in 14.8 in Min. Turn Radius without Brakes 145 in Not Published Height to Top of ROPS 106.5 in 102.4 in Height to Top of ROPS (folded) 85.5 in Not Published Height to Top of Cab Model 97.2 in 92.9 in ▶ WeightTractor Weight (Base) 4,795 lb 12x12 Power Shuttle: 3,968 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 9.5-20 9.5x16 R1 Agricultural - Rear 14.9-28 13.6x28 R3 Turf - Front 29x12.5-15 27x10.50-15 R3 Turf - Rear 44x18-20 44x18.00-20 R4 Industrial - Front 14x17.5 10-16.5 R4 Industrial - Rear 18.4x24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System KL551: universal quick-attach bucket mount, 78 in QA bucket DL135: Skid steer quick attach Loader Model KL551; KL1595 DL135 Loader Lift Height KL551: 113.58 in; KL1595: 127.52 in DL135: 111 in Loader Lift Capacity (Full Height) KL551: 2,850 lb; KL1595: 2,685 lb DL135: 2,610 lb Loader Breakout Force KL551: 4,675 lb; KL1595: 4,500 lb DL135: 4,000 lb ▶ WarrantyWarranty Length & Coverage Limited: Tractors (Non-Commercial Application) 24 months parts & labor; Extended (driveline): 48 months parts & labor 5-year powertrain warranty ▶ ITC Company AccessoriesAccessories that fit None tagged yet
