▶ EngineEngine Manufacturer KIOTI (Daedong) FPT Engine Model 4A220T S8000 Engine Type Indirect injection, vertical, water-cooled, turbocharged 4-cycle diesel Turbocharged 3-cylinder diesel No. of Cylinders 4 3 Displacement 134.1 in³ 179 in³ Rated Engine Speed 2600 rpm 2300 rpm Engine Power (Gross) 54 hp 54 hp PTO Power 45.2 hp 40 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Not Published Air Cleaner High efficiency air filter with cyclone pre-cleaner canister PowerCore dry air cleaner Fuel System Indirect injection Bosch electronic high-pressure common rail Alternator 50 A, 12 V 120 A ▶ HydraulicsPump Type Tandem gear Dual gear pumps Implement Flow 9.88 gpm 12.6 gpm Steering Flow 4.33 gpm 7.6 gpm Total Hydraulic Flow 14.2 gpm 20.2 gpm Overall Hydraulic Pump Flow 14.2 gpm 20.2 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 2 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 18.0 gal 21.7 gal Coolant Capacity 2.51 gal Not Published Crankcase Capacity 2.25 gal Not Published Transmission / Hydraulic System Capacity 10.0 gal Not Published Front Axle Fluid Capacity 2.17 gal Not Published ▶ PTO & HitchPTO Type Independent Fully independent, hydraulic wet clutch PTO Rear 540/1000 rpm 540 rpm (540/540E optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II (Category I ends optional) Category I/II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 2,654 lb 3,500 lb (4,000 lb with optional auxiliary lift ram) Lift Control Type Position, Draft and Mixed control Lift-O-Matic with mechanical draft control (upper-link draft sensing) ▶ Transmission & DrivetrainTransmission Type Synchronized shuttle 12x12 hydraulic power shuttle No. of Speeds 12F/12R 12F/12R Max Travel Speed (Forward) 16.42 mph 25 mph Max Travel Speed (Reverse) 13.59 mph Not Published Clutch Dry type single plate, single stage 11 in single dry disc Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanically engaged rear differential lock; limited-slip 4WD front axle with electro-hydraulic push-button engagement ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc type Hydraulic-assist wet brakes Seat Suspension & Adjustability Adjustable seat Cloth air-suspension seat with fold-back instructor seat Front Axle Type 4WD (bevel gear front wheel drive, push-button engagement) 4WD (MFD) limited-slip front axle, electro-hydraulic engagement Front Axle Rating Not Published 6,500 lb dynamic capacity Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 128.6 in 154.1 in Overall Width 69.3 in Not Published Wheelbase 75.6 in 83.6 in Ground Clearance 17.5 in Not Published Min. Turn Radius without Brakes 145 in Not Published Height to Top of ROPS 106.5 in Not Published Height to Top of ROPS (folded) 85.5 in Not Published Height to Top of Cab Model 97.2 in 100.2 in ▶ WeightTractor Weight (Base) 4,795 lb 6,800 lb (cab, 4WD) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 agricultural (11.2x24 / 16.9x30 standard, R1W radials optional), R4 industrial (12.5/80-18 / 19.5L-24) R1 Agricultural - Front 9.5-20 11.2x24 R1, 6 ply R1 Agricultural - Rear 14.9-28 16.9x30 R1, 6 ply R3 Turf - Front 29x12.5-15 Not Published R3 Turf - Rear 44x18-20 Not Published R4 Industrial - Front 14x17.5 12.5/80-18 R4, 10 ply R4 Industrial - Rear 18.4x24 19.5L-24 R4, 10 ply ▶ Loader & AttachmentsQuick Attach Loader System KL551: universal quick-attach bucket mount, 78 in QA bucket 72 in bucket with SSL (skid steer) or Euro-style quick attach Loader Model KL551; KL1595 550LU (non self-leveling); 555LU (mechanical self-leveling) Loader Lift Height KL551: 113.58 in; KL1595: 127.52 in 550LU: 131.3 in; 555LU: 130.0 in (at pivot pin) Loader Lift Capacity (Full Height) KL551: 2,850 lb; KL1595: 2,685 lb 550LU: 2,425 lb; 555LU: 3,153 lb (at max height, 31.5 in ahead of bucket pivot pin) Loader Breakout Force KL551: 4,675 lb; KL1595: 4,500 lb Not Published ▶ WarrantyWarranty Length & Coverage Limited: Tractors (Non-Commercial Application) 24 months parts & labor; Extended (driveline): 48 months parts & labor Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
