▶ EngineEngine Manufacturer KIOTI Daedong Engine Model 3HT-TM4B 3FT-TL4-U Engine Type 3-cylinder, liquid-cooled diesel Turbocharged diesel No. of Cylinders 3 3 Displacement 111.4 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2750 rpm Engine Power (Gross) 55 hp 55 hp PTO Power 46.4 hp 49.6 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System Not Published Not Published Alternator Not Published Not Published ▶ HydraulicsPump Type Gear Not Published Implement Flow 9.62 gpm 9.6 gpm Steering Flow 4.94 gpm 4.5 gpm Total Hydraulic Flow 14.56 gpm 14.1 gpm Overall Hydraulic Pump Flow 14.56 gpm 14.1 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None (2 optional) None standard; 2 pairs optional No. of Optional Remote Valves 2 2 pairs ▶ Fluid CapacityFuel Tank Capacity 11.9 gal 11.9 gal Coolant Capacity 0.89 gal Not Published Crankcase Capacity 1.95 gal Not Published Transmission / Hydraulic System Capacity 11.4 gal Not Published Front Axle Fluid Capacity 1.48 gal Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability No mid PTO (N/A) Not offered (SST model) Category, 3-Point Hitch Category II Category I Hitch Lift Capacity 2,998 lb Not Published Hitch Lift Capacity (at 24”) 2,716 lb 2,716 lb Lift Control Type Position Hydraulic position control ▶ Transmission & DrivetrainTransmission Type Synchronized shuttle 8F x 8R synchro shuttle (SST) No. of Speeds 8F/8R 8 forward, 8 reverse Max Travel Speed (Forward) 16.71 mph 16.3 mph Max Travel Speed (Reverse) 16.28 mph 15.9 mph Clutch Dry single stage Not Published Differential Lock & Limited Slip Options Rear differential lock (standard) Rear differential lock, standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet multi-disc Wet multi-disc Seat Suspension & Adjustability Deluxe suspension seat Adjustable seat (standard) Front Axle Type Mechanical 4WD Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1,655 lb (max. drawbar vertical load) Not Published ▶ Dimensions & ManeuverabilityOverall Width 62.8 in 70.3 in (with industrial tires) Wheelbase 71.3 in 71.2 in Ground Clearance 14.5 in 15.3 in (with industrial tires) Min. Turn Radius without Brakes 102.7 in (with brake applied) 103.5 in (with assisted braking) Height to Top of ROPS 96.8 in 97.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published n/a (open-station ROPS model) Overall Length 124.8 in 125.5 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,373 lb 3,745 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published n/a (open-station ROPS model) ▶ Tire OptionsTire Size & Options Agricultural, Turf, Industrial, R14 Agricultural; Turf; Industrial R1 Agricultural - Front 8-16 8-16 R1 Agricultural - Rear 13.6-24 13.6-24 R3 Turf - Front 29-12.5-15 Not Published R3 Turf - Rear 21.5L-16.1 Not Published R4 Industrial - Front 10-16.5 Not Published R4 Industrial - Rear 14.9-24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Quick attach (QA) bucket, 66 in or 72 in Standard quick attach mounting system Loader Model KL5520 FL9 Loader Lift Height KL5520: 107.7 in (at pivot pin) 103.0 in (to pivot pin) Loader Lift Capacity (Full Height) KL5520: 2,474 lb (at pivot pin) 1,858 lb (at pivot pin, max height) Loader Breakout Force KL5520: 3,895 lb (at pivot pin) 3,938 lb (at pivot point) ▶ WarrantyWarranty Length & Coverage Non-commercial: basic 24 months, unlimited hours, parts and labor, 0% deductible; powertrain 72 months, unlimited hours Not Published ▶ ITC Company AccessoriesAccessories that fit
