▶ EngineEngine Manufacturer KIOTI KIOTI (Daedong) Engine Model 3HT-TM4B 4A220TLWB Engine Type 3-cylinder, liquid-cooled diesel Water-cooled 4-cycle diesel No. of Cylinders 3 4 Displacement 111.4 in³ 134.1 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 55 hp 54 hp PTO Power 46.4 hp 45.2 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Not Published Air Cleaner Not Published High efficiency air filter with cyclone pre-cleaner canister Fuel System Not Published Not Published Alternator Not Published Not Published ▶ HydraulicsPump Type Gear Tandem gear Implement Flow 9.62 gpm 9.88 gpm Steering Flow 4.94 gpm 4.33 gpm Total Hydraulic Flow 14.56 gpm 14.2 gpm Overall Hydraulic Pump Flow 14.56 gpm 14.2 gpm Hydraulic System Type Not Published Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None (2 optional) 2 No. of Optional Remote Valves 2 Not Published ▶ Fluid CapacityFuel Tank Capacity 11.9 gal 18.0 gal Coolant Capacity 0.89 gal Not Published Crankcase Capacity 1.95 gal Not Published Transmission / Hydraulic System Capacity 11.4 gal Not Published Front Axle Fluid Capacity 1.48 gal Not Published ▶ PTO & HitchPTO Type Independent Hydraulic independent PTO Rear 540 rpm 540/1000 rpm Mid-PTO Availability No mid PTO (N/A) Not Published Category, 3-Point Hitch Category II Category II (Category I ends optional) Hitch Lift Capacity 2,998 lb Not Published Hitch Lift Capacity (at 24”) 2,716 lb 2,654 lb Lift Control Type Position Position, Draft and Mixed control ▶ Transmission & DrivetrainTransmission Type Synchronized shuttle Synchronized shuttle No. of Speeds 8F/8R 12F/12R Max Travel Speed (Forward) 16.71 mph 16.42 mph Max Travel Speed (Reverse) 16.28 mph 13.59 mph Clutch Dry single stage Dry single Differential Lock & Limited Slip Options Rear differential lock (standard) Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet multi-disc Wet disc Seat Suspension & Adjustability Deluxe suspension seat Adjustable seat Front Axle Type Mechanical 4WD 4WD (bevel gear front wheel drive, push-button engagement) Front Axle Rating Not Published Not Published Drawbar Capacity 1,655 lb (max. drawbar vertical load) Not Published ▶ Dimensions & ManeuverabilityOverall Width 62.8 in 69.3 in (minimum tread) Wheelbase 71.3 in 75.6 in Ground Clearance 14.5 in 17.5 in Min. Turn Radius without Brakes 102.7 in (with brake applied) 145 in Height to Top of ROPS 96.8 in 106.5 in Height to Top of ROPS (folded) Not Published 85.5 in Height to Top of Cab Model Not Published 99.6 in Overall Length 124.8 in 130.5 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,373 lb 4,795 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Turf, Industrial, R14 R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 8-16 9.5-20 R1 Agricultural - Rear 13.6-24 14.9-28 R3 Turf - Front 29-12.5-15 29x12.5-15 R3 Turf - Rear 21.5L-16.1 44x18-20 R4 Industrial - Front 10-16.5 14x17.5 R4 Industrial - Rear 14.9-24 18.4x24 ▶ Loader & AttachmentsQuick Attach Loader System Quick attach (QA) bucket, 66 in or 72 in KL551: universal quick-attach bucket mount, 78 in QA bucket Loader Model KL5520 KL551; KL1595 Loader Lift Height KL5520: 107.7 in (at pivot pin) KL551: 113.58 in; KL1595: 127.52 in Loader Lift Capacity (Full Height) KL5520: 2,474 lb (at pivot pin) KL551: 2,850 lb; KL1595: 2,685 lb Loader Breakout Force KL5520: 3,895 lb (at pivot pin) KL551: 4,675 lb; KL1595: 4,500 lb ▶ WarrantyWarranty Length & Coverage Non-commercial: basic 24 months, unlimited hours, parts and labor, 0% deductible; powertrain 72 months, unlimited hours Not Published ▶ ITC Company AccessoriesAccessories that fit
