▶ EngineEngine Manufacturer KIOTI KIOTI Engine Model 3HT-TM4B 3HT-S4TM58A Engine Type 3-cylinder, liquid-cooled diesel 3-cylinder, in-line vertical, water-cooled, 4-cycle turbo diesel, CRDI No. of Cylinders 3 3 Displacement 111.4 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 55 hp 57.7 hp PTO Power 46.4 hp 48.3 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Not Published Dry element Fuel System Not Published Common Rail Diesel (CRDI) Alternator Not Published Not Published ▶ HydraulicsPump Type Gear Gear Implement Flow 9.62 gpm 9.62 gpm Steering Flow 4.94 gpm 6.87 gpm Total Hydraulic Flow 14.56 gpm 16.5 gpm Overall Hydraulic Pump Flow 14.56 gpm 16.5 gpm Hydraulic System Type Not Published Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None (2 optional) 1 No. of Optional Remote Valves 2 1 ▶ Fluid CapacityFuel Tank Capacity 11.9 gal 13.2 gal Coolant Capacity 0.89 gal 2.03 gal Crankcase Capacity 1.95 gal 1.95 gal Transmission / Hydraulic System Capacity 11.4 gal 11.36 gal Front Axle Fluid Capacity 1.48 gal 2.25 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability No mid PTO (N/A) Optional (2,000 rpm) Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 2,998 lb 2,940 lb Hitch Lift Capacity (at 24”) 2,716 lb 2,493 lb Lift Control Type Position Position with Draft Control ▶ Transmission & DrivetrainTransmission Type Synchronized shuttle Synchro Shuttle No. of Speeds 8F/8R 12x12 Max Travel Speed (Forward) 16.71 mph 16.7 mph Max Travel Speed (Reverse) 16.28 mph 14.8 mph Clutch Dry single stage Dry Type Single Stage Differential Lock & Limited Slip Options Rear differential lock (standard) Mechanical differential lock: rear standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic Power Steering Brakes Wet multi-disc Wet disc type Seat Suspension & Adjustability Deluxe suspension seat Deluxe suspension seat Front Axle Type Mechanical 4WD Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1,655 lb (max. drawbar vertical load) Not Published ▶ Dimensions & ManeuverabilityOverall Width 62.8 in 67.1 in Wheelbase 71.3 in 75.5 in Ground Clearance 14.5 in 13.4 in Min. Turn Radius without Brakes 102.7 in (with brake applied) 11.0 ft (with brake applied) Height to Top of ROPS 96.8 in 98.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 124.8 in 136.4 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,373 lb 4,027 lb (with AG tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Turf, Industrial, R14 Agricultural, Turf, Industrial R1 Agricultural - Front 8-16 8-16 R1 Agricultural - Rear 13.6-24 13.6-24 R3 Turf - Front 29-12.5-15 29-12.5-15 R3 Turf - Rear 21.5L-16.1 21.5L-16.1 R4 Industrial - Front 10-16.5 10-16.5 R4 Industrial - Rear 14.9-24 14.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Quick attach (QA) bucket, 66 in or 72 in Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator Loader Model KL5520 KL5810 Loader Lift Height KL5520: 107.7 in (at pivot pin) KL5810: 106.3 in (to pivot pin) Loader Lift Capacity (Full Height) KL5520: 2,474 lb (at pivot pin) KL5810: 2,621 lb (at pivot pin) Loader Breakout Force KL5520: 3,895 lb (at pivot pin) KL5810: 3,896 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Non-commercial: basic 24 months, unlimited hours, parts and labor, 0% deductible; powertrain 72 months, unlimited hours Non-commercial: basic 24 months, powertrain 72 months, unlimited hours, parts and labor ▶ ITC Company AccessoriesAccessories that fit
