▶ EngineEngine Manufacturer KIOTI Kubota Engine Model 3HT-TM4B V3307-DI Engine Type 3-cylinder, liquid-cooled diesel 4-cylinder inline, direct injected diesel No. of Cylinders 3 4 Displacement 111.4 in³ 203 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 55 hp Not Published PTO Power 46.4 hp 55 hp Engine Emissions Constraints Tier 4 Tier 2 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published 8 in dry, dual element Fuel System Not Published Direct injection Alternator Not Published ROPS: 45 A, 12 V; Cab: 60 A, 12 V ▶ HydraulicsPump Type Gear Not Published Implement Flow 9.62 gpm 11.0 gpm Steering Flow 4.94 gpm 6.1 gpm Total Hydraulic Flow 14.56 gpm 17.1 gpm (11.0 + 6.1, computed) Overall Hydraulic Pump Flow 14.56 gpm 17.1 gpm (11.0 + 6.1, computed) Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published 11.0 gpm No. of Standard Remote Valves None (2 optional) 1 No. of Optional Remote Valves 2 2nd and 3rd optional ▶ Fluid CapacityFuel Tank Capacity 11.9 gal ROPS: 18.5 gal; Cab: 29.1 gal Coolant Capacity 0.89 gal 8.5 qt Crankcase Capacity 1.95 gal 11.6 qt Transmission / Hydraulic System Capacity 11.4 gal 59.2 qt Front Axle Fluid Capacity 1.48 gal Front differential case: 5.8 qt; front axle gear case: 3.7 qt each side ▶ PTO & HitchPTO Type Independent Live, independent PTO, hydraulically operated wet clutch with PTO brake PTO Rear 540 rpm 540 rpm Mid-PTO Availability No mid PTO (N/A) Not Published Category, 3-Point Hitch Category II Category I and II Hitch Lift Capacity 2,998 lb 4,189 lb Hitch Lift Capacity (at 24”) 2,716 lb 3,307 lb Lift Control Type Position Position, draft (top link sensing) and mix control ▶ Transmission & DrivetrainTransmission Type Synchronized shuttle Synchro shuttle, 8F/8R (4-speed synchronized main, 2-speed Hi/Lo range); hydraulic shuttle optional on cab models No. of Speeds 8F/8R 8F/8R (12F/12R with optional creep) Max Travel Speed (Forward) 16.71 mph 17.8 mph Max Travel Speed (Reverse) 16.28 mph 18.0 mph Clutch Dry single stage Dry single plate (synchro shuttle); multiple wet discs (hydraulic shuttle) Differential Lock & Limited Slip Options Rear differential lock (standard) Rear differential lock (bevel gears) ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS (canopy optional); Ultra Grand Cab optional Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet multi-disc Multiple wet disc, mechanical Seat Suspension & Adjustability Deluxe suspension seat Reclining, fully adjustable seat (height, weight, fore-aft, armrests) with retractable seat belt; optional air-suspension seat (cab) Front Axle Type Mechanical 4WD 4WD: bevel-gear type, on-the-go engagement Front Axle Rating Not Published Not Published Drawbar Capacity 1,655 lb (max. drawbar vertical load) 2,200 lb ▶ Dimensions & ManeuverabilityOverall Width 62.8 in 73.2 in Wheelbase 71.3 in 2WD ROPS: 82.1 in; 2WD cab: 84.4 in; 4WD ROPS: 80.7 in; 4WD cab: 83.1 in Ground Clearance 14.5 in 15.4 in Min. Turn Radius without Brakes 102.7 in (with brake applied) 2WD: 11.2 ft; 4WD: 11.8 ft Height to Top of ROPS 96.8 in 96.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 99.8 in Overall Length 124.8 in 2WD: 140.4 in; 4WD: 135.6 in ▶ WeightTractor Weight (Base) 3,373 lb 2WD ROPS: 4,650 lb; 4WD ROPS: 4,785 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Turf, Industrial, R14 Standard: 7.50-16 (2WD) or 9.5-24 (4WD) front, 16.9-28 rear R1 Agricultural - Front 8-16 2WD: 7.5-16; 4WD: 9.5-24 R1 Agricultural - Rear 13.6-24 16.9-28 R3 Turf - Front 29-12.5-15 2WD: 29x12.5-15 or 27x9.5-15 R3 Turf - Rear 21.5L-16.1 2WD: 21.5L-16.1 or 16.9-24 R4 Industrial - Front 10-16.5 12.5/80-18 (4WD) R4 Industrial - Rear 14.9-24 16.9-24 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System Quick attach (QA) bucket, 66 in or 72 in LA1153: two-lever quick coupler Loader Model KL5520 LA1153 Loader Lift Height KL5520: 107.7 in (at pivot pin) LA1153 height position: 132.7 in; LA1153 power position: 117.2 in Loader Lift Capacity (Full Height) KL5520: 2,474 lb (at pivot pin) Not Published Loader Breakout Force KL5520: 3,895 lb (at pivot pin) Not Published ▶ WarrantyWarranty Length & Coverage Non-commercial: basic 24 months, unlimited hours, parts and labor, 0% deductible; powertrain 72 months, unlimited hours Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
