▶ EngineEngine Manufacturer Not Published Kubota Engine Model 3H-TH4C V2403-CR-TE4 Engine Type 3-cylinder, in-line vertical, water-cooled 4-cycle diesel, CRDI 4-cylinder in-line, common rail direct injection, turbocharged diesel No. of Cylinders 3 4 Displacement 111.4 in³ 148.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 57.7 hp 57.9 hp PTO Power 44.9 hp 50 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled, pressurized radiator with recovery tank Air Cleaner Not Published Dry paper dual element, 8 in diameter, pre-cleaner standard Fuel System Common rail direct injection (CRDI) Common rail direct injection Alternator Not Published 45 A ▶ HydraulicsPump Type Gear Gear pump Implement Flow Not Published 10.6 gpm Steering Flow Not Published 6.1 gpm Total Hydraulic Flow 16.49 gpm 16.5 gpm Overall Hydraulic Pump Flow 16.49 gpm 16.5 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 (2 port) 1 (SCD) No. of Optional Remote Valves 1 2 optional (3 maximum) ▶ Fluid CapacityFuel Tank Capacity 12.7 gal 17.7 gal Coolant Capacity Not Published 8.5 qt Crankcase Capacity Not Published 7.6 qt Transmission / Hydraulic System Capacity Not Published 50.7 qt Front Axle Fluid Capacity Not Published No front axle oil, 2WD (M5660SUH); 6.9 qt front differential case plus 3.2 qt per bevel gear case (M5660SUHD) ▶ PTO & HitchPTO Type Independent Hydraulic independent PTO, self-modulating multi-plate wet clutch with brake PTO Rear 540 rpm 540 rpm (540/540E optional) Mid-PTO Availability Optional (2,000 rpm) Not Published Category, 3-Point Hitch Category I Category I and II Hitch Lift Capacity Not Published 4189 lb Hitch Lift Capacity (at 24”) 2,716 lb 3307 lb Lift Control Type Position Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic (HST) Fully synchronized 4-speed main gear shift with hi-lo range and hydraulic shuttle, 8F/8R No. of Speeds 3 range (hydrostatic, infinite speeds) 8F/8R Max Travel Speed (Forward) 18.5 mph 18.2 mph Max Travel Speed (Reverse) 12.9 mph 18.6 mph Clutch Not Published Multiple wet disc Differential Lock & Limited Slip Options Rear differential lock (standard) Rear differential lock standard (mechanical) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc Mechanical wet disc Seat Suspension & Adjustability Deluxe adjustable suspension seat Fully adjustable suspension seat with retractable seat belt Front Axle Type Mechanical 4WD Adjustable tubular steel, 2WD (M5660SUH); Cast iron bevel pinion drive with 55 degree turning angle, 4WD (M5660SUHD) Front Axle Rating Not Published 4410 lb at 55.9 in tread spacing (M5660SUH); 5290 lb at 55.9 in tread spacing (M5660SUHD) Drawbar Capacity Not Published 2200 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 125.5 in 138.7 in (M5660SUH); 136 in (M5660SUHD) Overall Width 62.8 in 73.2 in Wheelbase 71.3 in 82 in (M5660SUH); 80.7 in (M5660SUHD) Ground Clearance 14.5 in 16.3 in Min. Turn Radius without Brakes 8.63 ft (with brake applied) 10.8 ft (M5660SUH); 12.8 ft (M5660SUHD) Height to Top of ROPS 96.8 in 95.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 93 in Not Published ▶ WeightTractor Weight (Base) DK6010SE HST: 3,522.9 lb; DK6010SE HST Cab: 4,043.3 lb 4189 lb (M5660SUH); 4387 lb (M5660SUHD) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural: 8-16 front, 13.6-24 rear; R3 Turf: 29-12.5-15 front, 21.5L-16.1 rear; R4 Industrial: 10-16.5 front, 14.9-24 rear 2WD: 6.50-16, 7.5-16, 9.5L-15 fronts with 14.9-28 or 16.9-28 R1 rears; R3 29x12.50-15 / 21.5L-16.1 and LSW; 4WD: 9.5-22 or 280/85R20 fronts with 14.9-28 R1 rears; R3 29x12.50-15 / 21.5L-16.1; R4 12.5/80-18 / 16.9-24 R1 Agricultural - Front 8-16 6.5-16 (M5660SUH); 8.3-24 (M5660SUHD) R1 Agricultural - Rear 13.6-24 14.9-28 R3 Turf - Front 29-12.5-15 29x12.50-15 R3 Turf - Rear 21.5L-16.1 21.5L-16.1 R4 Industrial - Front 10-16.5 12.5/80-18 (M5660SUHD) R4 Industrial - Rear 14.9-24 16.9-24 (M5660SUHD) ▶ Loader & AttachmentsQuick Attach Loader System Quick attach (QA) bucket, 66 in or 72 in LA1154SU: 2-lever quick attach coupler standard Loader Model KL5520 (ROPS); KL5521 (Cab) LA1154SU (also printed LA1154) Loader Lift Height KL5520: 105.7 in; KL5521: 105.7 in LA1154: 130.9 in (height position); 115.7 in (power position) Loader Lift Capacity (Full Height) KL5520: 2,474 lb; KL5521: 2,474 lb LA1154: 2469 lb (height position); 2928 lb (power position) Loader Breakout Force KL5520: 3,895 lb; KL5521: 3,895 lb LA1154SU: 4230 lbf (height position); 5354 lbf (power position) ▶ WarrantyWarranty Length & Coverage Not Published All usage - Basic Standard Limited: 24 months or 2000 hours; Limited Powertrain: 36 months or 3000 hours.
