▶ EngineEngine Manufacturer KIOTI John Deere Engine Model 4J243TA-TP5B PowerTech 4045 (4.5L) PWL Engine Type 4-cylinder, in-line vertical, water-cooled, turbocharged and intercooled CRDI diesel (4J243TA-TP5B) 4-cylinder, turbocharged and aftercooled diesel, electronic fuel control No. of Cylinders 4 4 Displacement 233.9 in³ 276 in³ Rated Engine Speed 2200 rpm 2400 rpm Engine Power (Gross) 90 hp 90 hp PTO Power 70 hp 76.7 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry element with evacuator valve Dry type with safety element Fuel System CRDI High pressure common rail, electronic fuel control Alternator Not Published OOS: 90 A; Cab: 120 A ▶ HydraulicsPump Type Gear Tandem gear pump, two engine-mounted pumps Implement Flow 19.8 gpm 15.9 gpm Steering Flow 12.2 gpm 6.6 gpm Total Hydraulic Flow 32 gpm 22.5 gpm Overall Hydraulic Pump Flow 32 gpm 22.5 gpm Hydraulic System Type Open Center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 3 2 rear; 0 mid No. of Optional Remote Valves 4th remote valve 3 rear; up to 3 mid ▶ Fluid CapacityFuel Tank Capacity 47.6 gal 25 gal (open operator station); 30 gal (cab) Coolant Capacity 4.6 gal 2.5 gal (open operator station); 3 gal (cab) Crankcase Capacity 3.9 gal 3.2 gal Transmission / Hydraulic System Capacity 20.34 gal 11.5 gal Front Axle Fluid Capacity 2.6 gal 1.3 gal (MFWD differential housing); 0.74 qt (each wheel hub) ▶ PTO & HitchPTO Type Independent Independent, electro-hydraulic engagement, wet PTO clutch PTO Rear 540 / 540E / 1000 rpm 540/540E standard; 540/1000 optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category 2, convertible to Category 1 Hitch Lift Capacity 8,079 lb 5,159 lb (maximum lift force at hitch ball); 3,846 lb throughout lift range Hitch Lift Capacity (at 24”) 8,002 lb 4,630 lb (electrohydraulic hitch) Lift Control Type Electronic control Electro-hydraulic hitch with electronic quick raise and lower (premium cab); top-link draft sensing ▶ Transmission & DrivetrainTransmission Type Power Shuttle w/ Hi-Lo Shift PowrReverser 12F/12R standard; PowrReverser Hi-Lo 24F/12R optional No. of Speeds 24 forward / 24 reverse 12 forward, 12 reverse (standard); 24 forward, 12 reverse (Hi-Lo) Max Travel Speed (Forward) 23.83 mph 21.7 mph (electronically limited) Max Travel Speed (Reverse) 23.67 mph 21.7 mph (electronically limited) Clutch Wet Multi Disc Wet Differential Lock & Limited Slip Options Mechanical rear differential lock (standard); front limited-slip differential Rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Foldable ROPS (open operator station); standard or premium cab; MFWD Steering Hydrostatic Power Steering Hydrostatic power steering Brakes Wet Disc Hydraulic wet disc, self-equalizing and self-adjusting, dual-stage Seat Suspension & Adjustability Heated air suspension seat, 20 degree swivel both directions, adjustable fore/aft Mechanical seat standard; air-suspension seat optional for cab Front Axle Type 4WD, outboard planetary drives, limited-slip differential MFWD Front Axle Rating Not Published 6,615 lb Drawbar Capacity Max. Drawbar vertical load: 3,307 lb; Max. Trailer loading weight: 9,921 lb 2,755 lb (standard drawbar, 9.8 in extended); 2,425 lb (standard drawbar, 350 and 15.7 in extended); 3,195 lb (heavy-duty drawbar, 9.8 in extended); 2,645 lb (heavy-duty drawbar, 350 and 15.7 in extended) ▶ Dimensions & ManeuverabilityOverall Width 88.6 in 83.6 in (minimum, 16.9-30 R1 tires); 85.1 in (minimum, 18.4-30 R1 tires) Wheelbase 94.9 in 92.5 in Ground Clearance 18.9 in 17 in (front axle) Min. Turn Radius without Brakes 12.7 ft (with brake applied) 11.6 ft (MFWD) Height to Top of ROPS Not Published 101.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 111.9 in 102.4 in Overall Length 170.8 in (with 3-point hitch) 159.13 in ▶ WeightTractor Weight (Base) 10,230 lb (with AG tires) 7,275 lb (MFWD open operator station, shipping weight); 8,150 lb (MFWD cab, shipping weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural (bias 13.6-24 / 18.4-34, radial 13.6R-24 / 18.4R-34); R14 radial (340/85R24 / 460/85R34) 18.4-30 R1 bias rear standard; 16.9-30 R1 also listed R1 Agricultural - Front 13.6-24 12.4-24 R1 Agricultural - Rear 18.4-34 18.4-30 R1 bias R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System KL1155: quick-attach system with built-in parking stand; single-lever joystick control with float; bucket level indicator Quick attach option with integrated parking stand Loader Model KL1155 520M (NSL and MSL); 540M (NSL) Loader Lift Height KL1155: 150.6 in (to pivot pin) 520M MSL: 132.0 in Loader Lift Capacity (Full Height) KL1155: 4,216 lb (at pivot pins) 520M MSL: 2,606 lb (to maximum height, measured at pivot) Loader Breakout Force KL1155: 8,554 lb (at pivot pins) 520M NSL: 4,511 lbf; 520M MSL: 4,793 lbf (at pivot point) ▶ WarrantyWarranty Length & Coverage Non-commercial: basic 24 months, unlimited hours, parts and labor, 0% deductible; powertrain 48 months, unlimited hours, HX series Powertrain 5 years or 2,000 hours, as sold new
