▶ EngineEngine Manufacturer KIOTI (Daedong) John Deere Engine Model 4J243TA-TP5B PowerTech 4045 PWL Engine Type In-Line Vertical, Water-cooled 4-Cycle Turbo Diesel, CRDI (4J243TA-TP5B) Diesel, turbocharged, air-to-air aftercooled No. of Cylinders 4 4 Displacement 233.9 in³ 276 in³ Rated Engine Speed 2200 rpm 2200 rpm Engine Power (Gross) 90 hp 89.2 hp PTO Power 70 hp 75 hp @ 100 rpm Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Liquid-cooled (Cool-Gard II coolant) Air Cleaner Dry element with evacuator valve Dry air cleaner, primary and secondary elements Fuel System Common Rail Direct Injection (CRDI) High Pressure Common Rail (HPCR) electronic fuel injection Alternator Not Published OOS: 90 A; Cab: 120 A; Field-installed option: 200 A, 12 V ▶ HydraulicsPump Type Gear Tandem gear pump Implement Flow 19.8 gpm 18.4 gpm Steering Flow 12.2 gpm 6.3 gpm Total Hydraulic Flow 32 gpm 24.7 gpm Overall Hydraulic Pump Flow 32 gpm 24.7 gpm Hydraulic System Type Open Center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 3 2 (rear, Dual SCV) No. of Optional Remote Valves 1 Up to 1 additional rear (3 total, Deluxe Triple SCV); mid SCVs up to 3 (XI, XII, XIII) for loader functions ▶ Fluid CapacityFuel Tank Capacity 47.6 gal OOS: 29.6 gal; OOS (High Capacity): 37.2 gal; Cab: 37 gal; Cab (High Capacity): 44.9 gal Coolant Capacity 4.6 gal OOS: 5.2 gal; Cab: 5.8 gal Crankcase Capacity 3.9 gal 3.4 gal Transmission / Hydraulic System Capacity 20.34 gal 10.4 gal Front Axle Fluid Capacity 2.6 gal Differential housing (MFWD): 1.3 gal; Wheel hub (each): 0.2 gal ▶ PTO & HitchPTO Type Independent Independent rear PTO (electro-hydraulic wet disc clutch): 540/540E standard; 540/540E/1000 optional PTO Rear 540 / 540E / 1000 rpm 540/540E rpm standard; 1000 rpm optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category 2 (convertible to 1) Hitch Lift Capacity 8,079 lb 5,305 lb standard; 6,114 lb optional Hitch Lift Capacity (at 24”) 8,002 lb 5,159 lb standard; 5,954 lb optional Lift Control Type Electronic control Mechanical or electrohydraulic (draft control) ▶ Transmission & DrivetrainTransmission Type Power Shuttle w/ Hi-Lo Shift PowrReverser 16F/16R (base); optional 32F/16R PowrReverser Hi-Lo or 12F/4R SyncShuttle Plus No. of Speeds 24 forward / 24 reverse 16F/16R (standard PowrReverser); 12F/4R (optional SyncShuttle Plus); 32F/16R (optional PowrReverser Hi-Lo) Max Travel Speed (Forward) 23.83 mph 16F/16R PowrReverser, top gear (D-4): 30K config: 18.6 mph; 40K config: 21.7 mph Max Travel Speed (Reverse) 23.67 mph 16F/16R PowrReverser, top gear (D-4): 30K config: 20.5 mph; 40K config: 23.9 mph Clutch Wet Multi Disc Wet Differential Lock & Limited Slip Options Mechanical rear differential lock (standard); front limited-slip differential Electro-hydraulic rear differential lock, engage on the go ▶ Chassis, Steering & ControlsFrame Type Not Published Cast iron mid-frame Steering Hydrostatic Power Steering Not Published Brakes Wet Multi Disc Not Published Seat Suspension & Adjustability Heated air suspension seat, 20 degree swivel both directions, adjustable fore/aft OOS: isolated mechanical seat standard (fore/aft, weight, lumbar adjust) or air suspension seat optional; Cab: mechanical seat standard or air suspension seat optional; adjustable weight range 88-330 lb Front Axle Type 4WD with outboard planetary final drives and limited-slip differential MFWD Front Axle Rating Not Published 6,613 lb (MFWD, max permissible front axle load) Drawbar Capacity Max. Drawbar vertical load: 3,307 lb; Max. Trailer loading weight: 9,921 lb Standard drawbar: 2,756 lb; 2,425 lb; 2,205 lb. Heavy-duty drawbar: 3,197 lb; 2,646 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 170.8 in 149.5 in Overall Width 88.6 in Cab, with fender extension: 85.6 in; Cab, without fender extension: 74.0 in; OOS, with fender extension: 69.1 in; OOS, without fender extension: 51.7 in Wheelbase 94.9 in 92.5 in Ground Clearance 18.9 in Not Published Min. Turn Radius without Brakes 12.7 ft (with brake applied) Not Published Height to Top of ROPS Not Published 102.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 111.9 in 102.9 in ▶ WeightTractor Weight (Base) 10,230 lb 2WD, OOS: 8,140 lb; 2WD, Cab: 8,580 lb; MFWD, OOS: 8,765 lb; MFWD, Cab: 9,185 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural (bias 13.6-24 / 18.4-34, radial 13.6R-24 / 18.4R-34); R14 radial (340/85R24 / 460/85R34) Not Published R1 Agricultural - Front 13.6-24 12.4R24 (320/85R24) R1W Radial R1 Agricultural - Rear 18.4-34 18.4R30 (460/85R30) R1W Radial R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System KL1155: quick-attach system with built-in parking stand; single-lever joystick control with float; bucket level indicator Not Published Loader Model KL1155 540M NSL; 540M SL; 540R NSL; 540R SL; H310 NSL (MFWD required for H310) Loader Lift Height KL1155: 150.6 in (to pivot pin) 540M NSL: 138 in; 540M SL: 138 in; 540R NSL: 141 in; 540R SL: 141 in; H310 NSL: 149 in Loader Lift Capacity (Full Height) KL1155: 4,216 lb (at pivot pins) 540M NSL: 3,674 lb; 540M SL: 3,058 lb; 540R NSL: 4,246 lb; 540R SL: 3,395 lb; H310 NSL: 4,644 lb (measured at pivot) Loader Breakout Force KL1155: 8,554 lb (at pivot pins) 540M NSL: 6,686 lbf; 540M SL: 5,513 lbf; 540R NSL: 4,945 lbf; 540R SL: 5,291 lbf; H310 NSL: 6,767 lbf (measured at pivot) ▶ WarrantyWarranty Length & Coverage Tractors (Non-Commercial): 24 months parts & labor, unlimited hours, 0% deductible; powertrain (engine and driveline): 48 months unlimited hours on HX Series 24 Months or 2000 Hours, Whichever Comes First (whole-machine, standard Agricultural Equipment tractor term)
