▶ EngineEngine Manufacturer KIOTI (Daedong) Kubota Engine Model 4J243TA-TP5B V3800CR-TIEF4 Engine Type In-Line Vertical, Water-cooled 4-Cycle Turbo Diesel, CRDI (4J243TA-TP5B) 4-cylinder in-line, common rail direct injection, turbocharged with intercooler, DPF, DOC and SCR diesel No. of Cylinders 4 4 Displacement 233.9 in³ 230 in³ Rated Engine Speed 2200 rpm 2400 rpm Engine Power (Gross) 90 hp 92.5 hp PTO Power 70 hp 76 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry element with evacuator valve Dry paper, dual element, 8 in diameter, with pre-cleaner Fuel System Common Rail Direct Injection (CRDI) Common rail direct injection Alternator Not Published 60 A, 12 V ▶ HydraulicsPump Type Gear Gear pump Implement Flow 19.8 gpm 15.9 gpm Steering Flow 12.2 gpm 5.4 gpm Total Hydraulic Flow 32 gpm 21.3 gpm Overall Hydraulic Pump Flow 32 gpm 21.3 gpm Hydraulic System Type Open Center Open center Rear Remote Hydraulic Flow Not Published 15.7 gpm No. of Standard Remote Valves 3 1 standard (3 maximum) No. of Optional Remote Valves 1 2 optional (3 maximum) ▶ Fluid CapacityFuel Tank Capacity 47.6 gal 27.7 gal Coolant Capacity 4.6 gal 11 qt Crankcase Capacity 3.9 gal 11.3 qt Transmission / Hydraulic System Capacity 20.34 gal 15.9 gal Front Axle Fluid Capacity 2.6 gal 6.3 qt (differential) plus 3.7 qt (each bevel gear case) ▶ PTO & HitchPTO Type Independent Live-independent PTO, electro-hydraulic clutch with brake PTO Rear 540 / 540E / 1000 rpm 540 rpm (540/540E on 12-speed models) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 8,079 lb 7055 lb (8860 lb optional, standard on 12-speed) Hitch Lift Capacity (at 24”) 8,002 lb 5181 lb (8-speed); 7275 lb (12-speed) Lift Control Type Electronic control Position, draft (top link sensing) and mixed control ▶ Transmission & DrivetrainTransmission Type Power Shuttle w/ Hi-Lo Shift Fully synchronized main gear shift with electro-hydraulic shuttle No. of Speeds 24 forward / 24 reverse 8 forward, 8 reverse (8-speed models); 12 forward, 12 reverse (12-speed models) Max Travel Speed (Forward) 23.83 mph 18.6 mph (8-speed); 23.6 mph (12-speed) Max Travel Speed (Reverse) 23.67 mph 18.4 mph (8-speed); 23.5 mph (12-speed) Clutch Wet Multi Disc Multiple wet disc Differential Lock & Limited Slip Options Mechanical rear differential lock (standard); front limited-slip differential Limited slip differential (front); mechanical differential lock (rear) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Steering Hydrostatic power steering Brakes Wet Multi Disc Hydraulic wet disc Seat Suspension & Adjustability Heated air suspension seat, 20 degree swivel both directions, adjustable fore/aft Suspension seat with fore and aft travel adjustment, suspension tension knob, backrest tilt adjustment and arm rest Front Axle Type 4WD with outboard planetary final drives and limited-slip differential Bevel gear type with 55 degree turning angle (4WD) Front Axle Rating Not Published 5730 lb Drawbar Capacity Max. Drawbar vertical load: 3,307 lb; Max. Trailer loading weight: 9,921 lb 3300 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 170.8 in 155.9 in Overall Width 88.6 in 78.3 in Wheelbase 94.9 in 88.6 in Ground Clearance 18.9 in 18.7 in Min. Turn Radius without Brakes 12.7 ft (with brake applied) 13.8 ft Height to Top of ROPS Not Published 98.8 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 111.9 in 100.2 in ▶ WeightTractor Weight (Base) 10,230 lb 6041 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural (bias 13.6-24 / 18.4-34, radial 13.6R-24 / 18.4R-34); R14 radial (340/85R24 / 460/85R34) Front: 7.50-18, 9.5L-15, 9.5-22, 10.00-16, 11.2-24, 12.4-24; Rear: 16.9-30, 16.9-34, 18.4-30 R1 Agricultural - Front 13.6-24 11.2-24 R1 Agricultural - Rear 18.4-34 18.4-28 R3 Turf - Front Not Published 9.5L-15 F2 or 27x9.50-15 HF-1 (rib fronts paired with the R3 rears) R3 Turf - Rear Not Published 18.4-26 R3 or 19.5L-24 R3 R4 Industrial - Front Not Published 9.5L-15 F2 (rib front paired with the R4 rear) R4 Industrial - Rear Not Published 19.5L-24 R4 ▶ Loader & AttachmentsQuick Attach Loader System KL1155: quick-attach system with built-in parking stand; single-lever joystick control with float; bucket level indicator Quick coupler standard (Euro type optional); quick-mount loader attach and detach without tools; single-lever hydraulic hose quick coupler optional Loader Model KL1155 LA1854 Loader Lift Height KL1155: 150.6 in (to pivot pin) 145.7 in (height position); 131.9 in (power position) Loader Lift Capacity (Full Height) KL1155: 4,216 lb (at pivot pins) 3990 lb (height position); 4144 lb (power position) Loader Breakout Force KL1155: 8,554 lb (at pivot pins) Not Published ▶ WarrantyWarranty Length & Coverage Tractors (Non-Commercial): 24 months parts & labor, unlimited hours, 0% deductible; powertrain (engine and driveline): 48 months unlimited hours on HX Series 24 months or 2000 hours; Limited Powertrain: 36 months or 3000 hours.
