▶ EngineEngine Manufacturer KIOTI (Daedong) John Deere Engine Model 3HT-S4TH50A 3029H Engine Type KIOTI 3 Cylinder, In-Line Vertical, Water-Cooled 4-Cycle Turbo Diesel, CRDI Diesel, turbocharged No. of Cylinders 3 3 Displacement 111.4 in³ 179 in³ Rated Engine Speed 2600 rpm 2100 rpm Engine Power (Gross) 50.3 hp 50 hp PTO Power 41.8 hp 37 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid cooled with overflow reservoir Air Cleaner Dry type element Dry type with safety element Fuel System Common Rail Direct Injection (CRDI) Electronically controlled, high-pressure common rail Alternator Not Published 70 A ▶ HydraulicsPump Type Gear Tandem gear pump (implement + steering) Implement Flow 9.61 gpm 11.4 gpm Steering Flow 6.87 gpm 6.8 gpm Total Hydraulic Flow 16.5 gpm 18.2 gpm Overall Hydraulic Pump Flow 16.5 gpm 18.2 gpm Hydraulic System Type Open Center Open Center Rear Remote Hydraulic Flow Not Published 11.4 gpm at a single rear SCV No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 1 2 ▶ Fluid CapacityFuel Tank Capacity 13.2 gal 19.6 gal Coolant Capacity 2.03 gal Open operator station: 2.85 gal Crankcase Capacity 1.95 gal 9.0 qt (with filter) Transmission / Hydraulic System Capacity 9.51 gal 8.36 gal (9x3) Front Axle Fluid Capacity 2.25 gal 2WD: 16.1 qt; MFWD: 8.0 qt ▶ PTO & HitchPTO Type Independent Independent, mechanical engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional (2,000 rpm) Not Published Category, 3-Point Hitch Category I Category II, convertible to I Hitch Lift Capacity 2,940 lb 3,968 lb Hitch Lift Capacity (at 24”) 2,493 lb 3,192 lb Lift Control Type Position with Draft Control Position control, draft control, adjustable rate of drop ▶ Transmission & DrivetrainTransmission Type Hydrostatic SyncShuttle No. of Speeds 3-Range 9F/3R Max Travel Speed (Forward) 17.5 mph Not Published Max Travel Speed (Reverse) 12.2 mph Not Published Clutch Not Published Dual clutch, 11 in (PowrReverser) Differential Lock & Limited Slip Options Mechanical differential lock: rear standard Mechanical, rear ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Steering Hydrostatic power steering Brakes Wet disc type Hydraulically actuated wet disk brakes, self-equalizing and self-adjusting Seat Suspension & Adjustability Deluxe suspension seat Deluxe adjustable vinyl seat with retractable seat belt Front Axle Type Not Published 2WD or MFWD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,675 lb (fully extended); 2,470 lb (short position) ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 136.4 in 143.3 in Overall Width 67.1 in Not Published Wheelbase 75.5 in 80.7 in Ground Clearance 13.4 in Not Published Min. Turn Radius without Brakes 11.0 ft (with brake applied) 137.8 in (2WD); 183.1 in (4WD); 153.5 in (4WD, Carraro axle) Height to Top of ROPS 98.4 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 4,027 lb 5,335 to 5,809 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Ag / R3 Turf / R4 Industrial / Snow R1 Agricultural - Front 8-16 11L-15 R1 Agricultural - Rear 13.6-24 14.9-28 R3 Turf - Front 29-12.5-15 33X15.50-15 6PR R3; 33X12.50-15 6PR R3; 29X12.5-15 4PR R3 (Premium) R3 Turf - Rear 21.5L-16.1 41X14.00-20 4PR R3; 44X18.00-20 4PR R3 (Premium) R4 Industrial - Front 10-16.5 27/12LL-15 6PR R4; 10-16.5 8PR R4; 28X8.50-15 8PR R4; 12.5/80-18 12PR R4 R4 Industrial - Rear 14.9-24 17.5L-24 8PR R4; 19.5L-24 8PR R4; 16.9-30 10PR R4; 43X16.00-20 R4; 43X16.00-20 R4 (Premium); 18.4-30 10PR R4 ▶ Loader & AttachmentsQuick Attach Loader System Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator 512 or 520M Loader Model KL5810 512 or 520M Loader Lift Height KL5810: 106.3 in (to pivot pin) 512: 113 in; 520M: 132 in Loader Lift Capacity (Full Height) KL5810: 2,621 lb (at pivot pin, max height) 512: 2,453 lb; 520M: 3,523 lb Loader Breakout Force KL5810: 3,896 lb (at pivot pin) 512: 4,781 lb; 520M: 4,641 lb ▶ WarrantyWarranty Length & Coverage Non-commercial tractor: 24 months, unlimited hours, parts & labor; non-commercial powertrain (engine and driveline): 72 months, unlimited hours, parts & labor 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)
