▶ EngineEngine Manufacturer KIOTI KIOTI Engine Model 3F183T 3HT-S4TM45A Engine Type 3-cylinder, in-line vertical, water-cooled, 4-cycle turbo diesel, CRDI 3-cylinder, in-line vertical, water-cooled, 4-cycle turbo diesel, CRDI No. of Cylinders 3 3 Displacement 111.4 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 45 hp 44.9 hp PTO Power 37.6 hp 36.6 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Water-cooled Air Cleaner Dry element Dry element Fuel System Common Rail Diesel (CRDI) Common Rail Diesel (CRDI) Alternator Not Published Not Published ▶ HydraulicsPump Type Gear Gear Implement Flow Not Published 9.62 gpm Steering Flow Not Published 6.87 gpm Total Hydraulic Flow 16.5 gpm 16.5 gpm Overall Hydraulic Pump Flow 16.5 gpm 16.5 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 1 1 ▶ Fluid CapacityFuel Tank Capacity 14.8 gal 13.2 gal Coolant Capacity 2.0 gal 2.03 gal Crankcase Capacity 1.58 gal 1.95 gal Transmission / Hydraulic System Capacity 14.53 gal 11.36 gal Front Axle Fluid Capacity 1.8 gal 2.25 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional (2,000 rpm) Optional (2,000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 3,538 lb 2,940 lb Hitch Lift Capacity (at 24”) 3,177 lb 2,493 lb Lift Control Type Position with Draft Control Position with Draft Control ▶ Transmission & DrivetrainTransmission Type Synchro Shuttle Synchro Shuttle No. of Speeds 24x24 12x12 Max Travel Speed (Forward) 15.71 mph 16.7 mph Max Travel Speed (Reverse) 13.96 mph 14.8 mph Clutch Dry Type Single Stage Dry Type Single Stage Differential Lock & Limited Slip Options Differential Lock: Rear (Standard) Mechanical differential lock: rear standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Steering Hydrostatic Power Steering Brakes Wet Multi Disc Wet disc type Seat Suspension & Adjustability Adjustable Seat Deluxe suspension seat Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1,655 lb (max. drawbar vertical load) Not Published ▶ Dimensions & ManeuverabilityOverall Width 65.6 in 67.1 in Wheelbase 75.6 in 75.5 in Ground Clearance 13.8 in 13.4 in Min. Turn Radius without Brakes 9.8 ft 11.0 ft (with brake applied) Height to Top of ROPS 103.1 in 98.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 139.6 in (with 3-point hitch) 136.4 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,978 lb (with AG tires) 4,027 lb (with AG tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Turf, Industrial Agricultural, Turf, Industrial R1 Agricultural - Front 8-16 8-16 R1 Agricultural - Rear 13.6-24 13.6-24 R3 Turf - Front 29-12.5-15 29-12.5-15 R3 Turf - Rear 21.5L-16.1 21.5L-16.1 R4 Industrial - Front 10-16.5 10-16.5 R4 Industrial - Rear 14.9-24 14.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator Loader Model KL6010 KL5810 Loader Lift Height KL6010: 108.3 in (to pivot pin) KL5810: 106.3 in (to pivot pin) Loader Lift Capacity (Full Height) KL6010: 2,761 lb (at pivot pin, max height) KL5810: 2,621 lb (at pivot pin) Loader Breakout Force KL6010: 3,727 lb (at pivot pin) KL5810: 3,896 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Non-commercial: basic 2 years, powertrain 72 months, unlimited hours, parts and labor Non-commercial: basic 24 months, powertrain 72 months, unlimited hours, parts and labor ▶ ITC Company AccessoriesAccessories that fit
