▶ EngineEngine Manufacturer KIOTI John Deere Engine Model 3F183T PowerTech 3029 (2.9L) EWR Engine Type 3-cylinder, in-line vertical, water-cooled, 4-cycle, turbocharged, common rail diesel Diesel, turbocharged No. of Cylinders 3 3 Displacement 111.4 in³ 179 in³ Rated Engine Speed 2600 rpm 2100 rpm Engine Power (Gross) 50 hp 50 hp PTO Power 41.8 hp 38 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid cooled with overflow reservoir Air Cleaner Dry type element Dry type with safety element Fuel System Common Rail Diesel (CRDI) Electronically controlled, high-pressure common rail Alternator Not Published 70 A ▶ HydraulicsPump Type Gear Tandem gear pump (implement + steering) Implement Flow Not Published 11.4 gpm Steering Flow Not Published 6.8 gpm Total Hydraulic Flow 16.5 gpm 18.2 gpm Overall Hydraulic Pump Flow 16.5 gpm 18.2 gpm Hydraulic System Type Open Center Open Center Rear Remote Hydraulic Flow Not Published 11.4 gpm at a single rear SCV No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 1 Not Published ▶ Fluid CapacityFuel Tank Capacity 14.8 gal 19 gal Coolant Capacity 2.0 gal Not Published Crankcase Capacity 1.58 gal 9.0 qt (with filter) Transmission / Hydraulic System Capacity 14.53 gal Not Published Front Axle Fluid Capacity 1.8 gal MFWD (Dana axle): 1.18 gal differential; 0.21 gal each wheel hub ▶ PTO & HitchPTO Type Independent Independent, mechanical engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional (2,000 rpm) Not Published Category, 3-Point Hitch Category I Category II, convertible to I Hitch Lift Capacity 3,538 lb 3,968 lb Hitch Lift Capacity (at 24”) 3,177 lb 3,192 lb Lift Control Type Position with Draft Control Position control, draft control, adjustable rate of drop ▶ Transmission & DrivetrainTransmission Type Synchro Shuttle SyncShuttle No. of Speeds 24x24 9F/3R Max Travel Speed (Forward) 15.71 mph Not Published Max Travel Speed (Reverse) 13.96 mph Not Published Clutch Dry Type Single Stage Dry Differential Lock & Limited Slip Options Differential Lock: Rear (Standard) Mechanical, rear ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Steering Hydrostatic power steering Brakes Wet Multi Disc Hydraulically actuated wet disc brakes, self-equalizing and self-adjusting Seat Suspension & Adjustability Adjustable Seat Deluxe adjustable vinyl seat with retractable seat belt Front Axle Type Not Published 2WD or MFWD Front Axle Rating Not Published Not Published Drawbar Capacity 1,655 lb (max. drawbar vertical load) 1,675 lb (fully extended); 2,470 lb (short position) ▶ Dimensions & ManeuverabilityOverall Width 65.6 in Not Published Wheelbase 75.6 in 80.7 in Ground Clearance 13.8 in Not Published Min. Turn Radius without Brakes 9.8 ft 11.5 ft (2WD); 15.3 ft (MFWD) Height to Top of ROPS 103.1 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 139.6 in (with 3-point hitch) 144.5 in ▶ WeightTractor Weight (Base) 3,978 lb (with AG tires) 5,335 to 5,809 lb (shipping weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Turf, Industrial Not Published R1 Agricultural - Front 8-16 MFWD: 9.5-24; 11.2-24; 12.4-24 R1 Agricultural - Rear 13.6-24 14.9-28 R3 Turf - Front 29-12.5-15 Not Published R3 Turf - Rear 21.5L-16.1 Not Published R4 Industrial - Front 10-16.5 Not Published R4 Industrial - Rear 14.9-24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator 520M and H240 loaders (Loader Prep Package includes loader mounting frames and hood guard); not compatible with the 512 loader Loader Model KL6010 500E, 500M or 520M Loader Lift Height KL6010: 108.3 in (to pivot pin) 500M: 124 in Loader Lift Capacity (Full Height) KL6010: 2,761 lb (at pivot pin, max height) 500M: 3,225 lb (at pivot, full height) Loader Breakout Force KL6010: 3,727 lb (at pivot pin) 500M: 4,354 lb (at pivot) ▶ WarrantyWarranty Length & Coverage Non-commercial: basic 2 years, powertrain 72 months, unlimited hours, parts and labor Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
