▶ EngineEngine Manufacturer KIOTI (Daedong) LS Engine Model 3F183T L3C19-T2 Engine Type KIOTI 3 Cylinder, In-Line Vertical, Water-Cooled 4-Cycle Turbo Diesel, CRDI 4-stroke, vertical, water cooling, CRDI No. of Cylinders 3 3 Displacement 111.4 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 50 hp 50 hp PTO Power 38.9 hp 43 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Water-cooled Water-cooled Air Cleaner Dry type element Dry Fuel System Common Rail Direct Injection (CRDI) Delphi CRDI (Common Rail Direct Injection) Alternator Not Published 70 A, 12 V ▶ HydraulicsPump Type Gear Gear pump type, engine drive Implement Flow 9.6 gpm 8.2 gpm Steering Flow 8.2 gpm 4.1 gpm (mechanical); 6.2 gpm (HST) Total Hydraulic Flow 17.9 gpm 12.3 gpm Overall Hydraulic Pump Flow 17.9 gpm Not Published Hydraulic System Type Open Center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 2 No. of Optional Remote Valves 1 Not Published ▶ Fluid CapacityFuel Tank Capacity 14.8 gal 10.6 gal (roll-bar); 12.4 gal (cabin) Coolant Capacity 2.0 gal 2.3 gal Crankcase Capacity 1.58 gal 1.6 gal Transmission / Hydraulic System Capacity 11.89 gal 11.4 gal Front Axle Fluid Capacity 1.8 gal 2.1 gal ▶ PTO & HitchPTO Type Independent Independent PTO with wet disk clutch PTO Rear 540 rpm 540 (standard); 540 / 750 / 1,000 (optional 3-speed) Mid-PTO Availability Optional (2,000 rpm) Yes, 2000 rpm mid-PTO Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 3,538 lb 2,756 lb Hitch Lift Capacity (at 24”) 3,177 lb 2,469 lb Lift Control Type Position with Draft Control Position and draft control ▶ Transmission & DrivetrainTransmission Type Hydrostatic Synchro-shuttle (mechanical) No. of Speeds 3 Range F16 x R16 (F32 x R16 with creeper, optional) Max Travel Speed (Forward) 16.52 mph 16.8 mph Max Travel Speed (Reverse) 16.52 mph 15.3 mph Clutch Not Published Dry single clutch (mechanical only) Differential Lock & Limited Slip Options Differential Lock: Rear (Standard) Mechanical pedal type differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Steering Hydrostatic Brakes Wet Multi Disc Wet disc Seat Suspension & Adjustability Adjustable Seat Not Published Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1,655 lb (max. drawbar vertical load) Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 139.6 in 133 in Overall Width 65.6 in 62.5 in Wheelbase 75.6 in 73.2 in Ground Clearance 13.8 in Not Published Min. Turn Radius without Brakes 9.8 ft 9.5 ft (with brake applied) Height to Top of ROPS Not Published 93 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 94.1 in 92 in ▶ WeightTractor Weight (Base) 4,309 lb Roll-bar: 3,770 lb; Cabin: 4,210 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial Ag 9.5-16 / 13.6-24; Turf 28x8.5-15 / 41x14-20; Industrial 12-16.5 / 17.5L-24 R1 Agricultural - Front 8-16 9.5-16 (6PR) R1 Agricultural - Rear 13.6-24 13.6-24 (8PR) R3 Turf - Front 29-12.5-15 28x8.5-15 R3 Turf - Rear 21.5L-16.1 41x14-20 R4 Industrial - Front 10-16.5 12-16.5 R4 Industrial - Rear 14.9-24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator Not Published Loader Model KL6010 LL4104; LL4106 Loader Lift Height KL6010: 108.3 in (to pivot pin) LL4104: 96.3 in; LL4106: 94.4 in Loader Lift Capacity (Full Height) KL6010: 2,761 lb (at pivot pin, max height) LL4104: 2,713 lb; LL4106: 2,680 lb Loader Breakout Force KL6010: 3,727 lb (at pivot pin) LL4104: 3,802 lb; LL4106: 4,063 lb ▶ WarrantyWarranty Length & Coverage Non-commercial tractor: 24 months, unlimited hours, parts & labor; non-commercial powertrain (engine and driveline): 72 months, unlimited hours, parts & labor 6-year / 1,500-hour limited powertrain warranty; 2-year / 750-hour bumper-to-bumper warranty ▶ ITC Company AccessoriesAccessories that fit None tagged yet
