▶ EnginePTO Power 38.9 hp (29.0 kW) 45.6 hp (34.0 kW) Alternator Not Published Not Published Air Cleaner Not Published Not Published Engine Type In-Line Vertical, Water-cooled 4-Cycle Turbo Diesel, CRDI In-Line Vertical, Water-Cooled Turbo Diesel Engine, CRDI Fuel System Common Rail Direct Injection (CRDI) Common Rail Direct Injection (CRDI) Displacement 111.40 in³ (1,826 cc) 111.4 in³ (1,826 cc) No. of Cylinders 3 3 Rated Engine Speed 2,600 rpm 2,600 rpm Cooling System Type Water-cooled Water-cooled Engine Manufacturer KIOTI (Daedong) KIOTI (Daedong) Engine Emissions Constraints Tier 4 Tier 4 Engine Power (Gross vs. Net HP) Gross: 50 hp (37.3 kW) Gross: 50 hp (37.3 kW) ▶ WeightTractor Weight with Loader Not Published Not Published Weight with Cab and Loader Not Applicable Not Published Weight with ROPS and Loader 4,000 lb (1,814.4 kg) Not Published ▶ HydraulicsPump Type Gear Gear Steering Flow 31.2 L/min (8.2 gpm) Not Published Implement Flow 36.4 L/min (9.6 gpm) Not Published Total Hydraulic Flow 67.60 L/min (17.90 gpm) 55.1 L/min (14.5 gpm) Hydraulic System Type Open Center Open center Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 67.60 L/min (17.90 gpm) 55.1 L/min (14.5 gpm) No. of Optional Remote Valves 1 2 No. of Standard Remote Valves 1 0 ▶ Tire OptionsR3 Turf - Rear 21.5lx16.1 21.5L-16.1 R3 Turf - Front 29x12.5-15 29X12.5-15 Tire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R4 Industrial - Rear 14.9-24 14.9-24 R4 Industrial - Front 10-16.5 10-16.5 R1 Agricultural - Rear 13.6-24 13.6-24 R1 Agricultural - Front 8.0-16 8.0-16 ▶ Pto & HitchPTO Rear 540 rpm 540 rpm PTO Type Independent Independent Lift Control Type Position with Draft Control Position Hitch Lift Capacity Not Published 2,716 lbs (1,232 kg) (24 in aft. of hitch) Mid-PTO Availability Optional (2,000 rpm) Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity (at 24”) 3,177 lbs (1,441 kg) 2,716 lbs (1,232 kg) Rear 3-Point Hitch Lift Capacity 3,177 lbs (1,441 kg) (at 24 in) 2,716 lbs (1,232 kg) (24 in aft. of hitch) ▶ Fluid CapacityCoolant Capacity 2.0 gal (7.7 L) Not Published Crankcase Capacity 1.58 gal (6.0 L) Not Published Fuel Tank Capacity 14.8 gal (56 L) 11.9 gal (45 L) Front Axle Fluid Capacity 1.8 gal (7.0 L) Not Published Transmission / Hydraulic System Capacity 11.89 gal (45 L) Not Published ▶ Loader & AttachmentsLoader Lift Height 108.3 in (2,750 mm) 109 in (2,768 mm) (to pivot pin) Loader Breakout Force 3,727 lb (1,691 kg) 3,900 lb (1,769 kg) (at pivot pin) Price for Backhoe Option KB2485: $9,504 MSRP (KIOTI notes subframe & bucket sold separately) Not Published Price for Mid-Mount Mower Not Applicable Not Published Quick Attach Loader System Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator Built-in parking stand (quick attach/detach); single-lever joystick w/ float; bucket level indicator Loader Lift Capacity (Full Height) 2,761 lb (1,252 kg) 2,660 lb (1,207 kg) (at pivot pins) ▶ Transmission & DrivetrainClutch None Dry type, single stage No. of Speeds 3 Range 8F/8R Transmission Type Hydrostatic Synchronized H-Shuttle Max Travel Speed (Forward) 16.52 mph (26.59 km/h) 17.3 mph (27.9 km/h) Max Travel Speed (Reverse) 16.52 mph (26.59 km/h) 16.9 mph (27.2 km/h) Differential Lock & Limited Slip Options Differential Lock: Rear (Standard) Rear differential lock (standard) ▶ Chassis Steering & ControlsBrakes Wet Multi Disc Wet multi disc Steering Hydrostatic Power Steering Hydrostatic power steering; tilt steering wheel Frame Type Not Published Not Published Front Axle Type Not Published Mechanical 4WD Drawbar Capacity Not Published Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Adjustable Seat Adjustable suspension seat ▶ Dimensions & ManeuverabilityWheelbase 75.6 in (1,920 mm) 71.3 in (1,810 mm) Overall Width 65.6 in (1,665 mm) 62.8 in (1,596 mm) Ground Clearance 13.7 in (350 mm) 15.2 in (387 mm) Height to Top of ROPS 103.1 in (2,618 mm) 92.0 in (2,338 mm) Height to Top of Cab Model Not Applicable Not Published Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes 9.81 ft (2.99 m) Not Published Overall Length with 3-Point Hitch 139.6 in (3,547 mm) 124.3 in (3,157 mm) ▶ Pricing Financing & WarrantyFinancing Options NX Series offers listed: up to $4,000 cash offer OR 0% APR up to 36 months OR 6.99% interest rate Available through KIOTI dealers Base Price with Loader Tractor Starting MSRP $35,628 + LOADER $7,535 = $43,163 MSRP Not Published Warranty Length & Coverage Tractors (Non-Commercial Application): 24 months parts & labor; Tractors (Non-Commercial Application and driveline): 48 months parts & labor; eligible purchases may receive total 6 years (72 months) extended powertrain warranty coverage (limited time) Limited: Tractors (Non-Commercial Application) 24 months parts & labor; Extended (driveline): 48 months parts & labor Base Price with Loader + Cab Not Applicable Not Published ▶ SourcesSpec sheet sources [1] kioti.com [2] kioti-api.files.svdcdn.com [3] daedong-kioti.com [1] tractordata.com [2] tractorgearbox.com [3] payeur.com [4] payeur.com [5] agro-specs.com
