▶ EngineEngine Manufacturer KIOTI (Daedong) KIOTI (Daedong) Engine Model 3F183T 4A220T Engine Type KIOTI 3 Cylinder, In-Line Vertical, Water-Cooled 4-Cycle Turbo Diesel, CRDI Indirect injection, vertical, water-cooled, turbocharged 4-cycle diesel No. of Cylinders 3 4 Displacement 111.4 in³ 134.1 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 55 hp 54 hp PTO Power 43.1 hp 45.2 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry type element High efficiency air filter with cyclone pre-cleaner canister Fuel System Common Rail Direct Injection (CRDI) Indirect injection Alternator Not Published 50 A, 12 V ▶ HydraulicsPump Type Gear Tandem gear Implement Flow 9.6 gpm 9.88 gpm Steering Flow 8.2 gpm 4.33 gpm Total Hydraulic Flow 17.9 gpm 14.2 gpm Overall Hydraulic Pump Flow 17.9 gpm 14.2 gpm Hydraulic System Type Open Center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 2 No. of Optional Remote Valves 1 Not Published ▶ Fluid CapacityFuel Tank Capacity 14.8 gal 18.0 gal Coolant Capacity 2.0 gal 2.51 gal Crankcase Capacity 1.58 gal 2.25 gal Transmission / Hydraulic System Capacity 11.89 gal 10.0 gal Front Axle Fluid Capacity 1.8 gal 2.17 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540/1000 rpm Mid-PTO Availability Optional (2,000 rpm) Not Published Category, 3-Point Hitch Category I & II Category II (Category I ends optional) Hitch Lift Capacity 3,538 lb Not Published Hitch Lift Capacity (at 24”) 3,177 lb 2,654 lb Lift Control Type Position with Draft Control Position, Draft and Mixed control ▶ Transmission & DrivetrainTransmission Type Hydrostatic Synchronized shuttle No. of Speeds 3 Range 12F/12R Max Travel Speed (Forward) 18.26 mph 16.42 mph Max Travel Speed (Reverse) 18.26 mph 13.59 mph Clutch Not Published Dry type single plate, single stage Differential Lock & Limited Slip Options Differential Lock: Rear (Standard) Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Steering Hydrostatic power steering Brakes Wet Multi Disc Wet disc type Seat Suspension & Adjustability Adjustable Seat Adjustable seat Front Axle Type Not Published 4WD (bevel gear front wheel drive, push-button engagement) Front Axle Rating Not Published Not Published Drawbar Capacity 1,655 lb (max. drawbar vertical load) Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 139.6 in 128.6 in Overall Width 65.7 in 69.3 in Wheelbase 75.6 in 75.6 in Ground Clearance 15.7 in 17.5 in Min. Turn Radius without Brakes 10.0 ft 145 in Height to Top of ROPS Not Published 106.5 in Height to Top of ROPS (folded) Not Published 85.5 in Height to Top of Cab Model 94.1 in 97.2 in ▶ WeightTractor Weight (Base) 4,529 lb 4,795 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 9.5-16 9.5-20 R1 Agricultural - Rear 16.9-24 14.9-28 R3 Turf - Front 29-12.5-15 29x12.5-15 R3 Turf - Rear 21.5L-16.1 44x18-20 R4 Industrial - Front 10-16.5 14x17.5 R4 Industrial - Rear 17.5-24 18.4x24 ▶ Loader & AttachmentsQuick Attach Loader System Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator KL551: universal quick-attach bucket mount, 78 in QA bucket Loader Model KL6010 KL551; KL1595 Loader Lift Height KL6010: 108.3 in (to pivot pin) KL551: 113.58 in; KL1595: 127.52 in Loader Lift Capacity (Full Height) KL6010: 2,761 lb (at pivot pin, max height) KL551: 2,850 lb; KL1595: 2,685 lb Loader Breakout Force KL6010: 3,727 lb (at pivot pin) KL551: 4,675 lb; KL1595: 4,500 lb ▶ WarrantyWarranty Length & Coverage Non-commercial tractor: 24 months, unlimited hours, parts & labor; non-commercial powertrain (engine and driveline): 72 months, unlimited hours, parts & labor Limited: Tractors (Non-Commercial Application) 24 months parts & labor; Extended (driveline): 48 months parts & labor ▶ ITC Company AccessoriesAccessories that fit
