▶ EngineEngine Manufacturer KIOTI Kubota Engine Model 3F183T V3307-DI Engine Type 3-cylinder, in-line vertical, water-cooled, 4-cycle, turbocharged, common rail diesel 4-cylinder inline, direct injected diesel No. of Cylinders 3 4 Displacement 111.4 in³ 203 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 55 hp Not Published PTO Power 43.1 hp 55 hp Engine Emissions Constraints Tier 4 Tier 2 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry type element 8 in dry, dual element Fuel System Common Rail Diesel (CRDI) Direct injection Alternator Not Published ROPS: 45 A, 12 V; Cab: 60 A, 12 V ▶ HydraulicsPump Type Gear Not Published Implement Flow Not Published 11.0 gpm Steering Flow Not Published 6.1 gpm Total Hydraulic Flow 17.9 gpm 17.1 gpm (11.0 + 6.1, computed) Overall Hydraulic Pump Flow 17.9 gpm 17.1 gpm (11.0 + 6.1, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 11.0 gpm No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 1 2nd and 3rd optional ▶ Fluid CapacityFuel Tank Capacity 14.8 gal ROPS: 18.5 gal; Cab: 29.1 gal Coolant Capacity 2.0 gal 8.5 qt Crankcase Capacity 1.58 gal 11.6 qt Transmission / Hydraulic System Capacity 11.89 gal 59.2 qt Front Axle Fluid Capacity 1.8 gal Front differential case: 5.8 qt; front axle gear case: 3.7 qt each side ▶ PTO & HitchPTO Type Independent Live, independent PTO, hydraulically operated wet clutch with PTO brake PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional (2,000 rpm) Not Published Category, 3-Point Hitch Category I Category I and II Hitch Lift Capacity 3,538 lb 4,189 lb Hitch Lift Capacity (at 24”) 3,177 lb 3,307 lb Lift Control Type Position with Draft Control Position, draft (top link sensing) and mix control ▶ Transmission & DrivetrainTransmission Type Hydrostatic Synchro shuttle, 8F/8R (4-speed synchronized main, 2-speed Hi/Lo range); hydraulic shuttle optional on cab models No. of Speeds 3 Range 8F/8R (12F/12R with optional creep) Max Travel Speed (Forward) 18.26 mph 17.8 mph Max Travel Speed (Reverse) 18.26 mph 18.0 mph Clutch Not Published Dry single plate (synchro shuttle); multiple wet discs (hydraulic shuttle) Differential Lock & Limited Slip Options Differential Lock: Rear (Standard) Rear differential lock (bevel gears) ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS (canopy optional); Ultra Grand Cab optional Steering Hydrostatic Power Steering Hydrostatic power steering Brakes Wet Multi Disc Multiple wet disc, mechanical Seat Suspension & Adjustability Adjustable Air-Ride Seat Reclining, fully adjustable seat (height, weight, fore-aft, armrests) with retractable seat belt; optional air-suspension seat (cab) Front Axle Type Not Published 4WD: bevel-gear type, on-the-go engagement Front Axle Rating Not Published Not Published Drawbar Capacity 1,655 lb (max. drawbar vertical load) 2,200 lb ▶ Dimensions & ManeuverabilityOverall Width 65.7 in 73.2 in Wheelbase 75.6 in 2WD ROPS: 82.1 in; 2WD cab: 84.4 in; 4WD ROPS: 80.7 in; 4WD cab: 83.1 in Ground Clearance 15.7 in 15.4 in Min. Turn Radius without Brakes 10.0 ft 2WD: 11.2 ft; 4WD: 11.8 ft Height to Top of ROPS Not Published 96.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 94.1 in 99.8 in Overall Length 139.6 in (with 3-point hitch) 2WD: 140.4 in; 4WD: 135.6 in ▶ WeightTractor Weight (Base) 4,529 lb (with AG tires) 2WD ROPS: 4,650 lb; 4WD ROPS: 4,785 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Turf, Industrial Standard: 7.50-16 (2WD) or 9.5-24 (4WD) front, 16.9-28 rear R1 Agricultural - Front 9.5-16 2WD: 7.5-16; 4WD: 9.5-24 R1 Agricultural - Rear 16.9-24 16.9-28 R3 Turf - Front 29-12.5-15 2WD: 29x12.5-15 or 27x9.5-15 R3 Turf - Rear 21.5L-16.1 2WD: 21.5L-16.1 or 16.9-24 R4 Industrial - Front 10-16.5 12.5/80-18 (4WD) R4 Industrial - Rear 17.5-24 16.9-24 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator LA1153: two-lever quick coupler Loader Model KL6010 LA1153 Loader Lift Height KL6010: 108.3 in (to pivot pin) LA1153 height position: 132.7 in; LA1153 power position: 117.2 in Loader Lift Capacity (Full Height) KL6010: 2,761 lb (at pivot pin, max height) Not Published Loader Breakout Force KL6010: 3,727 lb (at pivot pin) Not Published ▶ WarrantyWarranty Length & Coverage Non-commercial: basic 2 years, powertrain 72 months, unlimited hours, parts and labor Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
