▶ EngineEngine Manufacturer KIOTI (Daedong) FPT Engine Model 3F183T R 753 IE4 Engine Type KIOTI 3 Cylinder, In-Line Vertical, Water-Cooled 4-Cycle Turbo Diesel, CRDI 3-cylinder, FPT turbocharged & aftercooled No. of Cylinders 3 3 Displacement 111.4 in³ 135.9 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 60 hp 60 hp PTO Power 48.3 hp 51 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry type element Dry Fuel System Common Rail Direct Injection (CRDI) Electronic high pressure common rail Alternator Not Published 75 A ▶ HydraulicsPump Type Gear Engine-driven dual gear-type Implement Flow 9.6 gpm 11.9 gpm Steering Flow 8.2 gpm 5.5 gpm Total Hydraulic Flow 17.9 gpm 17.4 gpm (11.9 + 5.5, computed) Overall Hydraulic Pump Flow 17.9 gpm Not Published Hydraulic System Type Open Center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 1 2 ▶ Fluid CapacityFuel Tank Capacity 14.8 gal 17.2 gal Coolant Capacity 2.0 gal Not Published Crankcase Capacity 1.58 gal Not Published Transmission / Hydraulic System Capacity 11.89 gal Not Published Front Axle Fluid Capacity 1.8 gal Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 / 540E Mid-PTO Availability Optional (2,000 rpm) Not Published Category, 3-Point Hitch Category I & II Category I/II Hitch Lift Capacity 3,538 lb Not Published Hitch Lift Capacity (at 24”) 3,177 lb 2,701 lb Lift Control Type Position with Draft Control Mechanical Draft Control (MDC), top link sensing ▶ Transmission & DrivetrainTransmission Type Hydrostatic 8x8 mechanical shuttle (dry clutch) No. of Speeds 3 Range 8F/8R Max Travel Speed (Forward) 18.26 mph Not Published Max Travel Speed (Reverse) 18.26 mph Not Published Clutch Not Published Dry clutch Differential Lock & Limited Slip Options Differential Lock: Rear (Standard) Mechanical rear differential lock; MFD engagement mechanical; limited-slip MFD front axle ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Steering Hydrostatic Brakes Wet Multi Disc Wet disc Seat Suspension & Adjustability Adjustable Seat Contoured seat, adjustable Front Axle Type Not Published 2WD or MFD with limited slip Front Axle Rating Not Published Not Published Drawbar Capacity 1,655 lb (max. drawbar vertical load) Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 139.6 in 2WD: 129.5 in; MFD: 134.0 in Overall Width 65.7 in 67.5 in Wheelbase 75.6 in 2WD: 77.5 in; MFD: 77.7 in Ground Clearance 15.7 in Not Published Min. Turn Radius without Brakes 10.0 ft 2WD: 135.8 in; MFD: 190.9 in Height to Top of ROPS 103.1 in 2WD: 92.7 in; MFD: 97.4 in Height to Top of ROPS (folded) Not Published 77 in Height to Top of Cab Model 94.1 in Not Published ▶ WeightTractor Weight (Base) NX6010H: 4,198 lb; NX6010HC: 4,529 lb 2WD: 4,442 lb; MFD: 5,060 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 (bar tread) 2WD or MFD; R4 (industrial tread) MFD R1 Agricultural - Front 9.5-16 2WD: 7.5x16; MFD: 8.3x24 R1 Agricultural - Rear 16.9-24 13.6x28 R3 Turf - Front 29-12.5-15 Not Published R3 Turf - Rear 21.5L-16.1 Not Published R4 Industrial - Front 10-16.5 MFD: 12.5x18 R4 Industrial - Rear 17.5-24 MFD: 18.4x24 ▶ Loader & AttachmentsQuick Attach Loader System Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator Compatible loaders: L545, L555 Loader Model KL6010 L545; L555 Loader Lift Height KL6010: 108.3 in (to pivot pin) L545: 106 in; L555: 105 in Loader Lift Capacity (Full Height) KL6010: 2,761 lb (at pivot pin, max height) L545 NSL: 1,565 lb; L545 MSL: 2,205 lb; L555 NSL: 1,940 lb; L555 MSL: 2,734 lb Loader Breakout Force KL6010: 3,727 lb (at pivot pin) L545: 3,131 lb; L555: 3,527 lb ▶ WarrantyWarranty Length & Coverage Non-commercial tractor: 24 months, unlimited hours, parts & labor; non-commercial powertrain (engine and driveline): 72 months, unlimited hours, parts & labor Not Published
