▶ EngineEngine Manufacturer KIOTI (Daedong) John Deere Engine Model 3F183T 3029H Engine Type KIOTI 3 Cylinder, In-Line Vertical, Water-Cooled 4-Cycle Turbo Diesel, CRDI Diesel, turbocharged No. of Cylinders 3 3 Displacement 111.4 in³ 179 in³ Rated Engine Speed 2600 rpm 2100 rpm Engine Power (Gross) 60 hp 60 hp PTO Power 48.3 hp OOS: 45.6 hp; Cab: 42.9 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry type element Dry type with safety element Fuel System Common Rail Direct Injection (CRDI) Electronically controlled, high-pressure common rail Alternator Not Published OOS: 70 A; Cab: 110 A ▶ HydraulicsPump Type Gear Tandem gear pump (implement + steering) Implement Flow 9.6 gpm 11.4 gpm Steering Flow 8.2 gpm 6.8 gpm Total Hydraulic Flow 17.9 gpm 18.2 gpm Overall Hydraulic Pump Flow 17.9 gpm 18.2 gpm Hydraulic System Type Open Center Open Center Rear Remote Hydraulic Flow Not Published 11.4 gpm at a single rear SCV No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 1 1 ▶ Fluid CapacityFuel Tank Capacity 14.8 gal OOS: 19.6 gal; Cab: 21.6 gal Coolant Capacity 2.0 gal Open operator station: 2.85 gal; Cab: 3.08 gal Crankcase Capacity 1.58 gal 9.0 qt (with filter) Transmission / Hydraulic System Capacity 11.89 gal 8.36 gal (9x3); 9.46 gal (12x12) Front Axle Fluid Capacity 1.8 gal DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm (SyncShuttle); 540/540E rpm (PowrReverser) Mid-PTO Availability Optional (2,000 rpm) Not Published Category, 3-Point Hitch Category I & II Category II, convertible to I Hitch Lift Capacity 3,538 lb 3,968 lb Hitch Lift Capacity (at 24”) 3,177 lb 3,192 lb Lift Control Type Position with Draft Control Position control, draft control, adjustable rate of drop ▶ Transmission & DrivetrainTransmission Type Hydrostatic SyncShuttle (standard); PowrReverser (optional) No. of Speeds 3 Range 9F/3R (SyncShuttle); 12F/12R (PowrReverser) Max Travel Speed (Forward) 18.26 mph 15.5 mph (SyncShuttle); 20.5 mph (PowrReverser) Max Travel Speed (Reverse) 18.26 mph 14.2 mph (SyncShuttle); 22.3 mph (PowrReverser) Clutch Not Published Wet traction clutch (PowrReverser) Differential Lock & Limited Slip Options Differential Lock: Rear (Standard) Mechanical, rear ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Steering Hydrostatic power steering Brakes Wet Multi Disc Hydraulically actuated wet disk brakes, self-equalizing and self-adjusting Seat Suspension & Adjustability Adjustable Seat Mechanical suspension with weight adjustment; fore/aft and backrest angle adjustment Front Axle Type Not Published 2WD or MFWD Front Axle Rating Not Published Up to 9,612 lb (max permissible MFWD axle load w/ loader; varies by tire) Drawbar Capacity 1,655 lb (max. drawbar vertical load) 1,675 lb (fully extended); 2,470 lb (short position) ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 139.6 in 143.3 in Overall Width 65.7 in Not Published Wheelbase 75.6 in 80.7 in Ground Clearance 15.7 in Not Published Min. Turn Radius without Brakes 10.0 ft 137.8 in (2WD); 183.1 in (4WD); 153.5 in (4WD, Carraro axle) Height to Top of ROPS 103.1 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 94.1 in Not Published ▶ WeightTractor Weight (Base) NX6010H: 4,198 lb; NX6010HC: 4,529 lb 5,445 to 6,702 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Ag / R3 Turf / R4 Industrial / Snow R1 Agricultural - Front 9.5-16 11L-15 R1 Agricultural - Rear 16.9-24 14.9-28 R3 Turf - Front 29-12.5-15 33X15.50-15 6PR R3; 33X12.50-15 6PR R3; 29X12.5-15 4PR R3 (Premium) R3 Turf - Rear 21.5L-16.1 41X14.00-20 4PR R3; 44X18.00-20 4PR R3 (Premium) R4 Industrial - Front 10-16.5 27/12LL-15 6PR R4; 10-16.5 8PR R4; 28X8.50-15 8PR R4; 12.5/80-18 12PR R4 R4 Industrial - Rear 17.5-24 17.5L-24 8PR R4; 19.5L-24 8PR R4; 16.9-30 10PR R4; 43X16.00-20 R4; 43X16.00-20 R4 (Premium); 18.4-30 10PR R4 ▶ Loader & AttachmentsQuick Attach Loader System Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator 512 or 520M Loader Model KL6010 512 or 520M Loader Lift Height KL6010: 108.3 in (to pivot pin) 512: 113 in; 520M: 132 in Loader Lift Capacity (Full Height) KL6010: 2,761 lb (at pivot pin, max height) 512: 2,453 lb; 520M: 3,523 lb Loader Breakout Force KL6010: 3,727 lb (at pivot pin) 512: 4,781 lb; 520M: 4,641 lb ▶ WarrantyWarranty Length & Coverage Non-commercial tractor: 24 months, unlimited hours, parts & labor; non-commercial powertrain (engine and driveline): 72 months, unlimited hours, parts & labor 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)
