▶ EngineEngine Manufacturer KIOTI (Daedong) YANMAR Engine Model 3F183T 4TNV98C Engine Type KIOTI 3 Cylinder, In-Line Vertical, Water-Cooled 4-Cycle Turbo Diesel, CRDI 4-cylinder, naturally aspirated diesel No. of Cylinders 3 4 Displacement 111.4 in³ 202.5 in³ Rated Engine Speed 2600 rpm 2500 rpm Engine Power (Gross) 60 hp 58.9 hp PTO Power 48.3 hp 52 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid cooled Air Cleaner Dry type element Dual stage cyclonic (resin 6.5") Fuel System Common Rail Direct Injection (CRDI) Common rail direct injection Alternator Not Published 55 A, 12 V ▶ HydraulicsPump Type Gear Not Published Implement Flow 9.6 gpm 9.4 gpm Steering Flow 8.2 gpm 5.3 gpm Total Hydraulic Flow 17.9 gpm 14.7 gpm (9.4 + 5.3, computed) Overall Hydraulic Pump Flow 17.9 gpm 14.7 gpm (9.4 + 5.3, computed) Hydraulic System Type Open Center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 2 No. of Optional Remote Valves 1 1 ▶ Fluid CapacityFuel Tank Capacity 14.8 gal 12.7 gal Coolant Capacity 2.0 gal 7.8 qt Crankcase Capacity 1.58 gal 8.0 qt Transmission / Hydraulic System Capacity 11.89 gal 7.7 gal Front Axle Fluid Capacity 1.8 gal 2.4 gal ▶ PTO & HitchPTO Type Independent Independent (electro-hydraulic) PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional (2,000 rpm) Not Published Category, 3-Point Hitch Category I & II Category I Hitch Lift Capacity 3,538 lb 3,307 lb Hitch Lift Capacity (at 24”) 3,177 lb 2,756 lb Lift Control Type Position with Draft Control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic I-HMT (Integrated Hydro Mechanical Transmission) No. of Speeds 3 Range 3 ranges (variable speed) Max Travel Speed (Forward) 18.26 mph 18 mph (with R1 tires) Max Travel Speed (Reverse) 18.26 mph 18 mph (with R1 tires) Clutch Not Published Clutch-less shifting (i-HMT) Differential Lock & Limited Slip Options Differential Lock: Rear (Standard) Rear differential lock (foot pedal engagement) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Steering Fully hydraulic power steering Brakes Wet Multi Disc Mechanical wet disc Seat Suspension & Adjustability Adjustable Seat Not Published Front Axle Type Not Published 2WD/4WD selectable engagement Front Axle Rating Not Published Not Published Drawbar Capacity 1,655 lb (max. drawbar vertical load) Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 139.6 in 132.1 in Overall Width 65.7 in 70.6 in (with R4 tires) Wheelbase 75.6 in 77.4 in Ground Clearance 15.7 in 12.8 in (with R4 tires) Min. Turn Radius without Brakes 10.0 ft Not Published Height to Top of ROPS 103.1 in 95.7 in (with R4 tires) Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 94.1 in Not Published ▶ WeightTractor Weight (Base) NX6010H: 4,198 lb; NX6010HC: 4,529 lb 4,039 lb (with ROPS, R4 tires, full fluid) Weight with ROPS and Loader Not Published 5,135 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 9.5-16 8-16 R1 Agricultural - Rear 16.9-24 14.9-24 R3 Turf - Front 29-12.5-15 27x10.5-15 R3 Turf - Rear 21.5L-16.1 44x18-20 R4 Industrial - Front 10-16.5 10-16.5 R4 Industrial - Rear 17.5-24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator YL610: Skid-steer-style loader quick attachment system Loader Model KL6010 YL610 Loader Lift Height KL6010: 108.3 in (to pivot pin) YL610: 113 in (to bucket pivot pin) Loader Lift Capacity (Full Height) KL6010: 2,761 lb (at pivot pin, max height) YL610: 2,500 lb at pivot pins Loader Breakout Force KL6010: 3,727 lb (at pivot pin) YL610: 3,969 lb at pivot pins ▶ WarrantyWarranty Length & Coverage Non-commercial tractor: 24 months, unlimited hours, parts & labor; non-commercial powertrain (engine and driveline): 72 months, unlimited hours, parts & labor Tractor: 24 months or 2,000 hours; Powertrain: 10 years or 3,000 hours; Attachments: 1-year limited warranty
