▶ EngineEngine Manufacturer KIOTI John Deere Engine Model 4F243T John Deere PowerTech 3029 Engine Type 4-cylinder, in-line vertical, water-cooled, 4-cycle turbo diesel, CRDI (4F243T) Diesel, turbocharged, liquid-cooled No. of Cylinders 4 3 Displacement 148.6 in³ 179 in³ Rated Engine Speed 2600 rpm 2100 rpm Engine Power (Gross) 66 hp 67 hp PTO Power 57.6 hp 49 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry element Dry type, dual element (primary and secondary) Fuel System CRDI Not Published Alternator Not Published 40 A ▶ HydraulicsPump Type Gear Not Published Implement Flow 11.0 gpm 11.4 gpm Steering Flow 6.9 gpm 6.8 gpm Total Hydraulic Flow 17.9 gpm 18.2 gpm Overall Hydraulic Pump Flow 17.9 gpm 18.2 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 2 2 ▶ Fluid CapacityFuel Tank Capacity 22.5 gal 19.6 gal Coolant Capacity 2.4 gal 10 qt Crankcase Capacity 2.2 gal 9 qt Transmission / Hydraulic System Capacity 15.9 gal 10.3 gal Front Axle Fluid Capacity 2.2 gal Dana axle: differential housing 1.18 gal, wheel hub (each) 0.21 gal; Carraro axle: differential housing 1.03 gal, reduction gear oil (each side) 0.15 gal ▶ PTO & HitchPTO Type Independent Independent; mechanical engagement (SyncShuttle); electrohydraulic engagement (PowrReverser) PTO Rear 540 / 540E rpm 540 rpm (540E optional with PowrReverser) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II, convertible to I Hitch Lift Capacity 4,575 lb Not Published Hitch Lift Capacity (at 24”) 3,594 lb 3,192 lb Lift Control Type Position, Draft, Mixed Control Position control with top link draft sensing ▶ Transmission & DrivetrainTransmission Type Manual: Synchro Shuttle SyncShuttle (standard); PowrReverser (optional) No. of Speeds 12 forward / 12 reverse 9F/3R (SyncShuttle); 12F/12R (PowrReverser optional) Max Travel Speed (Forward) 21.79 mph Not Published Max Travel Speed (Reverse) 21.42 mph Not Published Clutch Dry Single Plate Dry (SyncShuttle); wet (12F/12R PowrReverser) Differential Lock & Limited Slip Options Rear differential lock (standard) Differential lock, standard; pedal-operated, mechanical ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Steering Power steering Brakes Wet Multi Disc Hydraulic wet disc brakes Seat Suspension & Adjustability Adjustable Seat Not Published Front Axle Type Not Published 2WD or MFWD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,675 lb (fully extended); 2,470 lb (short position) ▶ Dimensions & ManeuverabilityOverall Width 70.9 in 57.3 in Wheelbase 82.7 in 80.7 in Ground Clearance 16.5 in 2WD: 18.8 in; MFWD: 13.4 in Min. Turn Radius without Brakes 10.2 ft (with brake applied) 11.5 ft (2WD); 15.3 ft (4WD); 12.8 ft (4WD, Carraro axle) Height to Top of ROPS 105.5 in 98.4 in Height to Top of ROPS (folded) Not Published 78.5 in Height to Top of Cab Model Not Published 95.6 in Overall Length 145 in (with 3-point hitch) 137.8 in ▶ WeightTractor Weight (Base) 5,202 lb (with AG tires) 2WD: 4,634 lb; MFWD: 5,621 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Turf, Industrial, R14 Not Published R1 Agricultural - Front 9.5-20 MFWD: 9.5-24; 280/85R24 (11.2R24) R1W Radial R1 Agricultural - Rear 14.9-28 16.9-28 R3 Turf - Front 31x13.5-15/8 9.5-16 (MFWD) R3 Turf - Rear 44x18-20/4 21.5L-16.1; 22.5LL-16.1 (Turf Special) R4 Industrial - Front 12.5/80-18 12.5/80-18 (MFWD) R4 Industrial - Rear 18.4-24/8 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Built-in parking stand; quick attach and detach 520M; H240 (NSL or MSL) Loader Model KL7320 H240NSL Loader Lift Height KL7320: 133.9 in (to pivot pin) 131 in Loader Lift Capacity (Full Height) KL7320: 3,384 lb (to full height at pivot pins) 3,671 lb (H240NSL, at pivot) Loader Breakout Force KL7320: 5,359 lb (at pivot pins) 4,504 lb (H240NSL, at pivot) ▶ WarrantyWarranty Length & Coverage Non-commercial: basic 24 months, powertrain 48 months, parts and labor Not Published
