▶ EngineEngine Manufacturer KIOTI Kubota Engine Model 4F243T V3307-CR-TE4 Engine Type 4-cylinder, in-line vertical, water-cooled, 4-cycle turbo diesel, CRDI (4F243T) Liquid-cooled, diesel, 4-cylinder No. of Cylinders 4 4 Displacement 148.6 in³ 203 in³ Rated Engine Speed 2600 rpm 2400 rpm Engine Power (Gross) 66 hp 65.4 hp PTO Power 57.6 hp 52 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry element Dual element (primary and secondary elements) Fuel System CRDI Common Rail System (CRS) Alternator Not Published 130 A ▶ HydraulicsPump Type Gear Not Published Implement Flow 11.0 gpm 16.7 gpm Steering Flow 6.9 gpm 6.3 gpm Total Hydraulic Flow 17.9 gpm 23.0 gpm (16.7 gpm implement + 6.3 gpm steering, computed) Overall Hydraulic Pump Flow 17.9 gpm 23.0 gpm (16.7 + 6.3, computed) Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 2 (SCD / FD) No. of Optional Remote Valves 2 Max. 3 ▶ Fluid CapacityFuel Tank Capacity 22.5 gal 23.8 gal Coolant Capacity 2.4 gal 10.6 qt Crankcase Capacity 2.2 gal 12.7 qt Transmission / Hydraulic System Capacity 15.9 gal 49.6 qt Front Axle Fluid Capacity 2.2 gal 5.8 qt (front differential case) plus 3.7 qt (front axle gear case) ▶ PTO & HitchPTO Type Independent Live-independent PTO, electro-hydraulic clutch with brake PTO Rear 540 / 540E rpm 540/540E rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II I / II Hitch Lift Capacity 4,575 lb 4,189 lb Hitch Lift Capacity (at 24”) 3,594 lb 3,307 lb Lift Control Type Position, Draft, Mixed Control Position, draft (top link sensing) & mixed control ▶ Transmission & DrivetrainTransmission Type Manual: Power Shuttle Fully synchronized 6-speed main gear shift with electro-hydraulic shuttle, 12F/12R (option: 18F/18R with creep) No. of Speeds 12 forward / 12 reverse F12/R12 (option: F18/R18 with creep) Max Travel Speed (Forward) 21.79 mph 24.9 mph Max Travel Speed (Reverse) 21.42 mph 24.7 mph Clutch Wet Disc Multiple wet disc Differential Lock & Limited Slip Options Rear differential lock (standard) Front: limited-slip differential; Rear: mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Ultra Grand Cab II Steering Hydrostatic Power Steering Hydrostatic power steering Brakes Wet Multi Disc Hydraulic wet disc Seat Suspension & Adjustability Adjustable Seat Mechanical-suspension seat with adjustable armrest, seat height, weight (suspension) and backrest tilt; optional air-suspension seat Front Axle Type Not Published Bevel gear type (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 2,200 lb ▶ Dimensions & ManeuverabilityOverall Width 70.9 in 75.6 in Wheelbase 82.7 in 84.1 in Ground Clearance 16.5 in 18.1 in (front axle crop clearance) Min. Turn Radius without Brakes 10.2 ft (with brake applied) 11.8 ft Height to Top of ROPS 105.5 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 101 in Overall Length 145 in (with 3-point hitch) 144 in ▶ WeightTractor Weight (Base) 5,148 lb (with AG tires) 6,008 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Turf, Industrial, R14 Standard: 320/70R24 front, 420/75R34 rear R1 Agricultural - Front 9.5-20 320/70R24 R1 Agricultural - Rear 14.9-28 420/75R34 R3 Turf - Front 31x13.5-15/8 9.50-24 R3 Turf - Rear 44x18-20/4 18.4-26 R4 Industrial - Front 12.5/80-18 14-17.5 R4 Industrial - Rear 18.4-24/8 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Built-in parking stand; quick attach and detach LA1154A: 2-Lever Quick Coupler Loader Model KL7320 LA1154A Loader Lift Height KL7320: 133.9 in (to pivot pin) LA1154A: Height position: 133.0 in; Power position: 117.6 in Loader Lift Capacity (Full Height) KL7320: 3,384 lb (to full height at pivot pins) LA1154A: Height position: 2,674 lb; Power position: 2,928 lb Loader Breakout Force KL7320: 5,359 lb (at pivot pins) LA1154A: Height position: 4,079 lbf; Power position: 5,128 lbf ▶ WarrantyWarranty Length & Coverage Non-commercial: basic 24 months, powertrain 48 months, parts and labor Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours
