▶ EngineEngine Manufacturer KIOTI Daedong Engine Model 4H243T 4HT-TP4A Engine Type 4-cylinder, in-line vertical, water-cooled, 4-cycle turbo diesel, CRDI (4H243T) Turbocharged diesel No. of Cylinders 4 4 Displacement 148.6 in³ 148.6 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 66.4 hp 66.4 hp PTO Power 54.9 hp 57.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Not Published Air Cleaner Not Published Not Published Fuel System CRDI Common rail Alternator Not Published Not Published ▶ HydraulicsPump Type Tandem Gear Not Published Implement Flow 12.4 gpm 11.0 gpm Steering Flow 8.2 gpm 6.9 gpm Total Hydraulic Flow 20.6 gpm 17.9 gpm Overall Hydraulic Pump Flow 20.6 gpm 17.9 gpm Hydraulic System Type Not Published Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 2 2 ▶ Fluid CapacityFuel Tank Capacity 26.4 gal 25.1 gal Coolant Capacity 2.51 gal Not Published Crankcase Capacity 2.83 gal Not Published Transmission / Hydraulic System Capacity 11.75 gal Not Published Front Axle Fluid Capacity 2.6 gal Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 / 540E rpm 540/540E rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 5,584 lb Not Published Hitch Lift Capacity (at 24”) 4,328 lb 3,594 lb Lift Control Type Electronic Control Position with draft control ▶ Transmission & DrivetrainTransmission Type Manual: Power Shuttle 3-range powershuttle with electronic clutch No. of Speeds 12 forward / 12 reverse 12 forward, 12 reverse Max Travel Speed (Forward) 23.9 mph (22.01 mph on AG tires) 19.8 mph Max Travel Speed (Reverse) 23.3 mph (21.92 mph on AG tires) 19.5 mph Clutch Wet Disc Electronic clutch Differential Lock & Limited Slip Options Rear differential lock (standard) Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Steering Power steering with tilt wheel Brakes Wet Multi Disc Wet multi-disc Seat Suspension & Adjustability Adjustable Air-Ride Seat Suspension seat, adjustable (standard) Front Axle Type Not Published Four-wheel drive (standard) Front Axle Rating Not Published Not Published Drawbar Capacity 1,984 lb (max. drawbar vertical load) Not Published ▶ Dimensions & ManeuverabilityOverall Width 82.1 in 77.2 in Wheelbase 85.4 in 82.7 in Ground Clearance 15.7 in 12.3 in Min. Turn Radius without Brakes 12.8 ft 147.0 in Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 105.3 in 99.3 in Overall Length 150.3 in (with 3-point hitch) 148.8 in ▶ WeightTractor Weight (Base) 6,814 lb (with AG tires) 5,830 lb (operating weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Industrial Industrial (standard), Agricultural, Multi-Use R1 Agricultural - Front 11.2-24 9.5-24 R1 Agricultural - Rear 16.9-30 16.9-30 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 12.5/80-18 12.5/80-18 R4 Industrial - Rear 18.4-24/8 18.4-24 ▶ Loader & AttachmentsQuick Attach Loader System Built-in parking stand; quick attach and detach Bob-Tach Loader Model KL7340 FL10 Loader Lift Height KL7340: 127.1 in (to pivot pin) FL10: 129.0 in (to pivot pin) Loader Lift Capacity (Full Height) KL7340: 3,384 lb (to full height) FL10: 2,614 lb (at pivot pin, max height) Loader Breakout Force KL7340: 5,875 lb (at pivot pin) FL10: 4,558 lb (at pivot point) ▶ WarrantyWarranty Length & Coverage Non-commercial: basic 24 months, powertrain 48 months, parts and labor Basic 24 months or 1,500 hours; powertrain 36 months or 2,000 hours
