▶ EngineEngine Manufacturer Daedong KIOTI (Daedong) Engine Model 4F243DTP-A 3F183T Engine Type 4-cylinder, liquid-cooled turbocharged diesel KIOTI 3 Cylinder, In-Line Vertical, Water-Cooled 4-Cycle Turbo Diesel, CRDI No. of Cylinders 4 3 Displacement 148.6 in³ 111.4 in³ Rated Engine Speed 2500 rpm 2600 rpm Engine Power (Gross) 66 hp 60 hp PTO Power Not Published 48.3 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Not Published Dry type element Fuel System Not Published Common Rail Direct Injection (CRDI) Alternator Not Published Not Published ▶ HydraulicsPump Type Not Published Gear Implement Flow 11 gpm 9.6 gpm Steering Flow 6.9 gpm 8.2 gpm Total Hydraulic Flow 17.9 gpm 17.9 gpm Overall Hydraulic Pump Flow 17.9 gpm 17.9 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity Not Published 14.8 gal Coolant Capacity Not Published 2.0 gal Crankcase Capacity Not Published 1.58 gal Transmission / Hydraulic System Capacity Not Published 11.89 gal Front Axle Fluid Capacity Not Published 1.8 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 / 540E rpm 540 rpm Mid-PTO Availability Not Published Optional (2,000 rpm) Category, 3-Point Hitch Category II Category I & II Hitch Lift Capacity Not Published 3,538 lb Hitch Lift Capacity (at 24”) 4,575 lb 3,177 lb Lift Control Type Position and draft control Position with Draft Control ▶ Transmission & DrivetrainTransmission Type Power shuttle Hydrostatic No. of Speeds 24F/24R 3 Range Max Travel Speed (Forward) Not Published 18.26 mph Max Travel Speed (Reverse) Not Published 18.26 mph Clutch Hydraulic wet disc Not Published Differential Lock & Limited Slip Options Rear differential lock (mechanical) Differential Lock: Rear (Standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic Power Steering Brakes Wet disc Wet Multi Disc Seat Suspension & Adjustability Not Published Adjustable Seat Front Axle Type 4WD Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,655 lb (max. drawbar vertical load) ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 145.8 in 139.6 in Overall Width Not Published 65.7 in Wheelbase Not Published 75.6 in Ground Clearance 16.5 in 15.7 in Min. Turn Radius without Brakes Not Published 10.0 ft Height to Top of ROPS 106.3 in 103.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 103.5 in 94.1 in ▶ WeightTractor Weight (Base) Not Published NX6010H: 4,198 lb; NX6010HC: 4,529 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural (standard): 11.2-20 front, 14.9-30 rear R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 11.2-20 9.5-16 R1 Agricultural - Rear 14.9-30 16.9-24 R3 Turf - Front Not Published 29-12.5-15 R3 Turf - Rear Not Published 21.5L-16.1 R4 Industrial - Front Not Published 10-16.5 R4 Industrial - Rear Not Published 17.5-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator Loader Model KL601; KL701 KL6010 Loader Lift Height KL601: 114.2 in; KL701: 133.9 in KL6010: 108.3 in (to pivot pin) Loader Lift Capacity (Full Height) KL601: 2,864 lb; KL701: 3,384 lb KL6010: 2,761 lb (at pivot pin, max height) Loader Breakout Force KL601: 4,577 lb; KL701: 5,359 lb KL6010: 3,727 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Non-commercial tractor: 24 months, unlimited hours, parts & labor; non-commercial powertrain (engine and driveline): 72 months, unlimited hours, parts & labor
