▶ EngineEngine Manufacturer KIOTI Daedong Engine Model 4F243T 4HT-TP4A Engine Type Turbocharged, common-rail, water-cooled diesel (4F243T) Turbocharged diesel No. of Cylinders 4 4 Displacement 148.6 in³ 148.6 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 73 hp 73.1 hp PTO Power 63 hp 62.1 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Not Published Air Cleaner Dry element Not Published Fuel System Common Rail Direct Injection (CRDI) Common rail Alternator Not Published Not Published ▶ HydraulicsPump Type Gear Not Published Implement Flow 11.0 gpm 11.0 gpm Steering Flow 8.2 gpm 8.2 gpm Total Hydraulic Flow 19.2 gpm 19.2 gpm Overall Hydraulic Pump Flow 19.2 gpm 19.2 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 2 2 ▶ Fluid CapacityFuel Tank Capacity 25.0 gal 25.1 gal Coolant Capacity 2.4 gal Not Published Crankcase Capacity 2.2 gal Not Published Transmission / Hydraulic System Capacity 15.9 gal Not Published Front Axle Fluid Capacity 2.2 gal Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 / 540E rpm 540/540E rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 4,974 lb Not Published Hitch Lift Capacity (at 24”) 3,898 lb 3,898 lb Lift Control Type Position, Draft, Mixed Control Position with draft control ▶ Transmission & DrivetrainTransmission Type Manual: Power Shuttle 3-range powershuttle with electronic clutch No. of Speeds 12 forward / 12 reverse 12 forward, 12 reverse Max Travel Speed (Forward) 23.53 mph 19.9 mph Max Travel Speed (Reverse) 23.13 mph 19.6 mph Clutch Wet Disc Electronic clutch Differential Lock & Limited Slip Options Rear differential lock (standard) Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Power Steering Power steering with tilt wheel Brakes Wet Multi Disc Wet multi-disc Seat Suspension & Adjustability Adjustable Seat Suspension seat, adjustable (standard) Front Axle Type Not Published Four-wheel drive (standard) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 77.2 in 83.5 in Wheelbase 83.9 in 83.9 in Ground Clearance 17.3 in 12.3 in Min. Turn Radius without Brakes 11.2 ft (with brake applied) 154.0 in Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 104.5 in 101.1 in Overall Length 146.3 in (with 3-point hitch) 150.0 in ▶ WeightTractor Weight (Base) 6,162 lb 5,960 lb (operating weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural and Industrial: front AG 11.2-24 (Industrial 12.5/80-18), rear AG 16.9-30 (Industrial 18.4-24/8) Industrial (standard), Agricultural, Multi-Use R1 Agricultural - Front 11.2-24 11.2-24 R1 Agricultural - Rear 16.9-30 16.9-30 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 12.5/80-18 12.5/80-18 R4 Industrial - Rear 18.4-24/8 18.4-24 ▶ Loader & AttachmentsQuick Attach Loader System Built-in parking stand; quick attach and detach Bob-Tach Loader Model KL7320 FL10 Loader Lift Height KL7320: 133.9 in (to pivot pin) FL10: 129.0 in (to pivot pin) Loader Lift Capacity (Full Height) KL7320: 3,384 lb (to full height at pivot pins) FL10: 2,813 lb Loader Breakout Force KL7320: 5,359 lb (at pivot pins) FL10: 4,628 lb (at pivot point) ▶ WarrantyWarranty Length & Coverage Non-commercial: basic 24 months, powertrain 48 months, parts and labor Basic 24 months or 1,500 hours; powertrain 36 months or 2,000 hours
