▶ EnginePTO Power 19.2 (14.3) HP (kW) 16.2 hp Alternator 40 A 40 A Air Cleaner Dual paper element Dual element Engine Type E-TVCS, liquid cooled, 3-cylinder diesel Diesel Fuel System Radial air flow Indirect injection Displacement 68.5 (1123) cu. in. (cc) 60.6 in³ No. of Cylinders 3 3 Rated Engine Speed 2600 rpm 3200 rpm Cooling System Type Liquid Cooled Water pump Engine Manufacturer Kubota Yanmar Engine Power (Gross) 21.9 (16.3) HP (kW) 21.5 hp @ 200 rpm Engine Emissions Constraints Tier 4 Tier 4 ▶ WeightTractor Weight (Base) 1,404 lbs. Open station: 1446 lb Weight with ROPS and Loader 1,521 lbs. 1446 lb ▶ WarrantyWarranty Length & Coverage Full warranty: 2 years / 2,000 hours; Powertrain warranty: 6 years / 2,000 hours 6-year powertrain warranty (as stated in 2016 review; current terms may vary) ▶ HydraulicsPump Type Dual pump Single gear Steering Flow 2.6 gpm 9.8 lpm 3.5 gpm Implement Flow 4.0 gpm 3.5 gpm Total Hydraulic Flow 7.0 (26.4) gpm (ℓ/min.) 6.3 gpm 23.8 lpm Hydraulic System Type Open center Open center System Operating Pressure 2500 psi 2000 PSI Rear Remote Hydraulic Flow Front & Rear outlet 3.5 gpm (13.3 lpm) implement circuit Overall Hydraulic Pump Flow 7.0 (26.4) gpm (ℓ/min.) 6.3 gpm total (2.8 gpm steering + 3.5 gpm implement) No. of Optional Remote Valves 1 1 additional (optional 3rd SCV kit; standard is 2 mid-SCVs) No. of Standard Remote Valves 0 — ▶ PTO & HitchPTO Rear 540, 1000 rpm 540 rpm PTO Type Transmission driven with one way clutch independent Lift Control Type Position control valve Position control (rockshaft lever) Hitch Lift Capacity 1653 (750) lbs. (kg) 1,433 lbs 1,433 lb Mid-PTO Availability 2500 rpm 2100 rpm Category, 3-Point Hitch Category I Limited Category 1 Hitch Lift Capacity (at 24”) 1808 (820) lbs. (kg); 1411 (640) lbs. (kg); 1290 (585) lbs. (kg) 758 lb ▶ Tire OptionsR3 Turf - Rear 33x12.5-15 26x12-12 R3 Turf - Front 23x8.50-12 18x8.50-10 R1 Agricultural - Rear 9.5-16 26x12-12 R1 Agricultural - Front 6-12 18x8.5-10 R4 Industrial - Rear — 26x12-12 R4 Industrial - Front — 18x8.5-10 ▶ Fluid CapacityCoolant Capacity 4.0 (3.8) qts. (ℓ) 0.98 gal Crankcase Capacity 3.3 (3.1) qts. (ℓ) 0.71 gal Fuel Tank Capacity 6.1 gal. 5.6 gal Transmission / Hydraulic System Capacity 3.3 (12.5) gal (ℓ) 3.3 gal Front Axle Fluid Capacity — 0.74 gal ▶ Loader & AttachmentsLoader Lift Height 78.5" 71.2 in (D120 and H120 loaders) Loader Breakout Force 2,146 lbf. — Quick Attach Loader System LA435 Swift-Tach Loader; 1-lever Quick Coupler (standard); 2-Lever Quick Coupler (optional) Quik-Park Loader System Loader Lift Capacity (Full Height) 1,175 lbs. D120: 570 lb; H120: 512 lb (at full height, 71.2 in) ▶ Transmission & DrivetrainClutch Dry single plate Wet disk No. of Speeds 9 Forward, 3 Reverse Infinite (hydrostatic, 2-range) Transmission Type Gear (9 Forward, 3 Reverse) Hydrostatic - two range Max Travel Speed (Forward) 0-11.7 (0-18.8) mph (km/h) 9.1 mph Max Travel Speed (Reverse) 0-6.0 (0-9.6) mph (km/h) 9.1 mph Differential Lock & Limited Slip Options Standard Differential lock Yes; Limited slip differential No ▶ Chassis, Steering & ControlsBrakes Multi-plate wet disc Wet disc (left-hand pedal) Steering Integral type power steering Power Front Axle Type Cast-iron front axle MFWD (Mechanical Front-Wheel Drive) 4WD Drawbar Capacity 661.4 lb (660 lbs) — Seat Suspension & Adjustability High-back seat (absorbs shock); NOTE: Deluxe seat with armrests and seat suspension listed for HST models only - not explicitly confirmed for B2401 gear-drive (DT) in spec sheet Spring suspension seat, adjusts fore/aft Frame Type — Open center frame with two-post foldable ROPS Front Axle Rating — 1349 lb ▶ Dimensions & ManeuverabilityWheelbase 61.4 (1560) in. (mm) 57.1 in. Overall Width 44.3 (1125) in. (mm) 47.2 in with R3 tires; 47.3 in with R4 tires Overall Length 93.9 in / 93.9 in — Ground Clearance 12.0 (305) in. (mm) 7.7 in. Height to Top of ROPS 83.9 in. 78.6 in Min. Turn Radius without Brakes 6.9 (2.1) feet (m) 2.51 m 8.2 ft Overall Length with 3-Point Hitch 93.9 in. 87.6 in ▶ ITC Company AccessoriesAccessories that fit None tagged yet
