▶ EnginePTO Power 19.2 (14.3) HP (kW) 28.7 (21.4) HP (kW) Alternator 40 A — Air Cleaner Dual paper element LX2620: 4.5 inch paper filter (with dual filter); LX3520/LX4020: 6 inch paper filter (with dual element) Engine Type E-TVCS, liquid cooled, 3-cylinder diesel Indirect injection, vertical, water-cooled, 4-cycle diesel and Direct injection, vertical, water-cooled, 4-cycle diesel with turbocharger Fuel System Radial air flow Common Rail (CRS) diesel Displacement 68.5 (1123) cu. in. (cc) 77 in³ No. of Cylinders 3 4 Rated Engine Speed 2600 rpm 2500 rpm Cooling System Type Liquid Cooled Pressurized radiator with radial air flow fan Engine Manufacturer Kubota Kubota Engine Power (Gross) 21.9 (16.3) HP (kW) 23.3 hp Engine Emissions Constraints Tier 4 — ▶ WeightTractor Weight (Base) 1,404 lbs. LX2620: 1,775 lbs; LX3520DTN: 2,154 lbs; LX3520: 2,191 lbs; LX4020: 2,624 lbs Weight with ROPS and Loader 1,521 lbs. — ▶ WarrantyWarranty Length & Coverage Full warranty: 2 years / 2,000 hours; Powertrain warranty: 6 years / 2,000 hours Full warranty: 2 years / 2,000 hours | Powertrain warranty: 6 years / 2,000 hours ▶ HydraulicsPump Type Dual pump Dual pump Steering Flow 2.6 gpm 9.8 lpm — Implement Flow 4.0 gpm — Total Hydraulic Flow 7.0 (26.4) gpm (ℓ/min.) 9.1 (34.5) gpm (l/min.) Hydraulic System Type Open center Open center System Operating Pressure 2500 psi Open center system Rear Remote Hydraulic Flow Front & Rear outlet — Overall Hydraulic Pump Flow 7.0 (26.4) gpm (ℓ/min.) 9.1 (34.5) gpm (l/min.) No. of Optional Remote Valves 1 — No. of Standard Remote Valves 0 — ▶ PTO & HitchPTO Rear 540, 1000 rpm 540 rpm PTO Type Transmission driven with one way clutch Independent Lift Control Type Position control valve Position control valve Hitch Lift Capacity 1653 (750) lbs. (kg) 2348 (1065) lbs. (kg) Mid-PTO Availability 2500 rpm 2460 RPM Category, 3-Point Hitch Category I Category I Hitch Lift Capacity (at 24”) 1808 (820) lbs. (kg); 1411 (640) lbs. (kg); 1290 (585) lbs. (kg) LX2620: 1,819 lbs; LX3520/LX4020: 1,962 lbs ▶ Tire OptionsR3 Turf - Rear 33x12.5-15 16.6-16 R3 Turf - Front 23x8.50-12 24x8.5-14 R1 Agricultural - Rear 9.5-16 320/85D16 R1 Agricultural - Front 6-12 180/85D12 Tire Size & Options — Front R1: 7-12; R4: 23×8.50-12; R4 large: 25×8.50-14; R14: 23×8.50-12; R14 large: 25×8.50-14; TURF: 24×8.50-14; Rear R1: 12.4-16; R4: 14-17.5; R14: 14-17.5; TURF: 13.6-16; R4 large: 15-19.5; R14 large: 15-19.5 R4 Industrial - Rear — 14-17.5 or 15-19.5 R4 Industrial - Front — 23x8.5-12 or 25x8.5-14 ▶ Fluid CapacityCoolant Capacity 4.0 (3.8) qts. (ℓ) LX2620: 4.5 qts (4.3 ℓ); LX3520/LX4020: 5.7 qts (5.4 ℓ) Crankcase Capacity 3.3 (3.1) qts. (ℓ) LX2620: 4.2 qts (4.0 ℓ); LX3520/LX4020: 5.0 qts (4.7 ℓ) Fuel Tank Capacity 6.1 gal. LX2620: 7.1 gal (27 ℓ); LX3520/LX4020: 8.5 gal (32 ℓ) Transmission / Hydraulic System Capacity 3.3 (12.5) gal (ℓ) 5.5 (21.0) gal (ℓ) ▶ Loader & AttachmentsLoader Lift Height 78.5" 87.6 (2226) in. (mm) Loader Breakout Force 2,146 lbf. — Quick Attach Loader System LA435 Swift-Tach Loader; 1-lever Quick Coupler (standard); 2-Lever Quick Coupler (optional) 2-Lever Quick Coupler (Standard); Swift-Tach (Optional) Loader Lift Capacity (Full Height) 1,175 lbs. 1100 (499) lbs. (kg) ▶ Transmission & DrivetrainClutch Dry single plate N/A No. of Speeds 9 Forward, 3 Reverse HST (3 range) Transmission Type Gear (9 Forward, 3 Reverse) HST (3 ranges) Max Travel Speed (Forward) 0-11.7 (0-18.8) mph (km/h) 17.0 (0-27.4) mph (km/h) Max Travel Speed (Reverse) 0-6.0 (0-9.6) mph (km/h) 13.0 (0-20.8) mph (km/h) Differential Lock & Limited Slip Options Standard Standard ▶ Chassis, Steering & ControlsBrakes Multi-plate wet disc Multi-plate wet disk Steering Integral type power steering Hydrostatic power steering Front Axle Type Cast-iron front axle — Drawbar Capacity 661.4 lb (660 lbs) — Seat Suspension & Adjustability High-back seat (absorbs shock); NOTE: Deluxe seat with armrests and seat suspension listed for HST models only - not explicitly confirmed for B2401 gear-drive (DT) in spec sheet Deluxe suspension seat (high back, designed to absorb shock) ▶ Dimensions & ManeuverabilityWheelbase 61.4 (1560) in. (mm) 66.7 (1695) in. (mm) Overall Width 44.3 (1125) in. (mm) 53.7 (1365) in. (mm) Overall Length 93.9 in / 93.9 in LX2620: 101.8 in.; LX3520DTN: 98.2 in.; LX3520/LX4020: 101.6-103.9 in. (2580-103.9 in) Ground Clearance 12.0 (305) in. (mm) 12.8 (325) in. (mm) Height to Top of ROPS 83.9 in. LX3520 Narrow: 56.7 in. (folded) Min. Turn Radius without Brakes 6.9 (2.1) feet (m) 7.5 (2.3) feet (m) Front drive disengaged Overall Length with 3-Point Hitch 93.9 in. 101.8 (2586) in. (mm) Height to Top of ROPS (folded) — 56.7 (1440) in. (mm) ▶ ITC Company AccessoriesAccessories that fit None tagged yet
