▶ EnginePTO Power 19.2 (14.3) HP (kW) 15.4 PTO HP Alternator 40 A 40 A, 12 V Air Cleaner Dual paper element Single Dry Engine Type E-TVCS, liquid cooled, 3-cylinder diesel Yanmar EPA Tier 4 certified 3-cylinder, liquid cooled diesel (natural aspiration) Fuel System Radial air flow Indirect Fuel Injection Displacement 68.5 (1123) cu. in. (cc) 60.6 in³ No. of Cylinders 3 3 Rated Engine Speed 2600 rpm 3200 rpm Cooling System Type Liquid Cooled Water-cooled Engine Manufacturer Kubota Yanmar Engine Power (Gross) 21.9 (16.3) HP (kW) 21.5 hp Engine Emissions Constraints Tier 4 Tier 4 Engine Model — 3TNM74F ▶ WeightTractor Weight (Base) 1,404 lbs. — Weight with ROPS and Loader 1,521 lbs. 1,942 lb Weight with Cab and Loader — Not Applicable ▶ WarrantyWarranty Length & Coverage Full warranty: 2 years / 2,000 hours; Powertrain warranty: 6 years / 2,000 hours Full-machine: 24 months/2,000 hours; Powertrain: 96 months/3,000 hours (whichever comes first) ▶ HydraulicsPump Type Dual pump Single Gear Pump with Flow Divider Steering Flow 2.6 gpm 9.8 lpm 2.11 gpm Implement Flow 4.0 gpm 4.17 gpm Total Hydraulic Flow 7.0 (26.4) gpm (ℓ/min.) 6.97 gpm Hydraulic System Type Open center Live, independent System Operating Pressure 2500 psi — Rear Remote Hydraulic Flow Front & Rear outlet Not Published Overall Hydraulic Pump Flow 7.0 (26.4) gpm (ℓ/min.) 6.97 gpm No. of Optional Remote Valves 1 Not Published No. of Standard Remote Valves 0 Not Published ▶ PTO & HitchPTO Rear 540, 1000 rpm 540 rpm PTO Type Transmission driven with one way clutch Independent Lift Control Type Position control valve Position Hitch Lift Capacity 1653 (750) lbs. (kg) 1,100 lb Mid-PTO Availability 2500 rpm Optional (2,500 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity (at 24”) 1808 (820) lbs. (kg); 1411 (640) lbs. (kg); 1290 (585) lbs. (kg) 679 lb ▶ Tire OptionsR3 Turf - Rear 33x12.5-15 16X12.00-12 R3 Turf - Front 23x8.50-12 16X7.50-8 R1 Agricultural - Rear 9.5-16 BAR R 24X12.00-12 R1 Agricultural - Front 6-12 BAR F 16X7.50-9 Tire Size & Options — R4 Industrial (Std), R3 Turf (Opt), Goodyear R14 (Opt) R4 Industrial - Rear — Not Published R4 Industrial - Front — Not Published ▶ Fluid CapacityCoolant Capacity 4.0 (3.8) qts. (ℓ) 3.7 qt Crankcase Capacity 3.3 (3.1) qts. (ℓ) 2.1 qt Fuel Tank Capacity 6.1 gal. 6.6 gal Transmission / Hydraulic System Capacity 3.3 (12.5) gal (ℓ) 3.6 gal Front Axle Fluid Capacity — 2.6 qt ▶ Loader & AttachmentsLoader Lift Height 78.5" 72 in Loader Breakout Force 2,146 lbf. 1,285 lb Quick Attach Loader System LA435 Swift-Tach Loader; 1-lever Quick Coupler (standard); 2-Lever Quick Coupler (optional) Skid-Steer Compatible Quick-Attach Loader Lift Capacity (Full Height) 1,175 lbs. 617 lb ▶ Transmission & DrivetrainClutch Dry single plate Not Published No. of Speeds 9 Forward, 3 Reverse 2 Range Transmission Type Gear (9 Forward, 3 Reverse) Hydrostatic Max Travel Speed (Forward) 0-11.7 (0-18.8) mph (km/h) 7.8 mph Max Travel Speed (Reverse) 0-6.0 (0-9.6) mph (km/h) Not Published Differential Lock & Limited Slip Options Standard Differential lock ▶ Chassis, Steering & ControlsBrakes Multi-plate wet disc Wet Disc Steering Integral type power steering Hydrostatic Front Axle Type Cast-iron front axle center-pivot, reverse Eliot type Drawbar Capacity 661.4 lb (660 lbs) Not Published Seat Suspension & Adjustability High-back seat (absorbs shock); NOTE: Deluxe seat with armrests and seat suspension listed for HST models only - not explicitly confirmed for B2401 gear-drive (DT) in spec sheet Suspension seat with armrests & retractable seat belt Frame Type — Not Published Front Axle Rating — Not Published ▶ Dimensions & ManeuverabilityWheelbase 61.4 (1560) in. (mm) 53.1 in Overall Width 44.3 (1125) in. (mm) 44.5 in Overall Length 93.9 in / 93.9 in — Ground Clearance 12.0 (305) in. (mm) F/A 8.3 in Height to Top of ROPS 83.9 in. 86.6 in Min. Turn Radius without Brakes 6.9 (2.1) feet (m) 86.6 in Overall Length with 3-Point Hitch 93.9 in. 94.2 in Height to Top of Cab Model — Not Applicable Height to Top of ROPS (folded) — Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
