▶ EngineEngine Manufacturer Kubota Kubota Engine Model D1105 D1105 Engine Type E-TVCS, liquid cooled, 3-cylinder diesel E-TVCS, liquid cooled, 3-cylinder diesel No. of Cylinders 3 3 Displacement 68.5 in³ 68.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 21.9 hp 21.9 hp PTO Power 19.2 hp 19.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid Cooled Liquid Cooled Air Cleaner Dual paper element Dual paper element Fuel System Not Published Not Published Alternator 40 A 40 A ▶ HydraulicsPump Type Dual pump Dual pump Implement Flow 4.4 gpm 4.4 gpm Steering Flow 2.6 gpm 2.6 gpm Total Hydraulic Flow 7.0 gpm 7.0 gpm Overall Hydraulic Pump Flow 7.0 gpm 7.0 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 0 0 No. of Optional Remote Valves 1 1 ▶ Fluid CapacityFuel Tank Capacity 6.1 gal 6.1 gal Coolant Capacity 4.0 qt 4.0 qt Crankcase Capacity 3.3 qt 3.3 qt Transmission / Hydraulic System Capacity 3.3 gal 3.3 gal Front Axle Fluid Capacity 0.8 gal 0.9 gal ▶ PTO & HitchPTO Type Transmission driven with one way clutch Transmission driven with one way clutch PTO Rear 540, 980 rpm 540, 1000 rpm Mid-PTO Availability Not Published 2500 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1653 lb 1653 lb Hitch Lift Capacity (at 24”) 1290 lb 1290 lb Lift Control Type Position control valve Position control valve ▶ Transmission & DrivetrainTransmission Type Gear (9 Forward, 3 Reverse) Gear (9 Forward, 3 Reverse) No. of Speeds 9 Forward, 3 Reverse 9 Forward, 3 Reverse Max Travel Speed (Forward) 10.9 mph 11.7 mph Max Travel Speed (Reverse) 5.6 mph 6.0 mph Clutch Dry single plate Dry single plate Differential Lock & Limited Slip Options Standard Standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Integral type power steering Integral type power steering Brakes Multi-plate wet disc Multi-plate wet disc Seat Suspension & Adjustability Fore and aft slide adjustment (position adjust lever) Fore and aft slide adjustment (position adjust lever) Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 660 lb 660 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 92.9 in (without 3-point hitch) 93.9 in (without 3-point hitch) Overall Width 35.4 in 44.3 in Wheelbase 61.4 in 61.4 in Ground Clearance 11.8 in 12.0 in Min. Turn Radius without Brakes 6.9 ft (with brake applied) 6.9 ft (with brake applied) Height to Top of ROPS 75.2 in 83.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1334 lb 1521 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Farm (R1): 5-12 front, 8-16 rear Farm (R1): 6-12 front, 9.5-16 rear; Turf (R3): 23x8.50-12 front, 33x12.5-15 rear; Industrial (R4): 23x8.50-12 front, 12-16.5 rear; R14: 23x8.50-12 front, 12-16.5 rear R1 Agricultural - Front 5-12 6-12 R1 Agricultural - Rear 8-16 9.5-16 R3 Turf - Front Not Published 23x8.50-12 R3 Turf - Rear Not Published 33x12.5-15 R4 Industrial - Front Not Published 23x8.50-12 R4 Industrial - Rear Not Published 12-16.5 ▶ Loader & AttachmentsQuick Attach Loader System Not Published LA435 Swift-Tach Loader; 1-lever Quick Coupler (standard); 2-Lever Quick Coupler (optional) Loader Model Not Published LA435 Loader Lift Height Not Published 78.5 in Loader Lift Capacity (Full Height) Not Published 948 lb Loader Breakout Force Not Published 2,146 lbf ▶ WarrantyWarranty Length & Coverage Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. ▶ ITC Company AccessoriesAccessories that fit
