▶ EngineEngine Manufacturer Kubota Kubota Engine Model D1105 D1005 Engine Type E-TVCS, liquid cooled, 3-cylinder diesel Liquid cooled, 4-cycle, diesel No. of Cylinders 3 3 Displacement 68.5 in³ 61.1 in³ Rated Engine Speed 2600 rpm 3200 rpm Engine Power (Gross) 21.9 hp 23.3 hp PTO Power 19.2 hp 19.2 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid Cooled Water with pressurized radiator, reverse air-flow design Air Cleaner Dual paper element Dry element Fuel System Not Published Direct injection Alternator 40 A 40 A, 12 V ▶ HydraulicsPump Type Dual pump Open center tandem pump gear type Implement Flow 4.4 gpm 5.2 gpm Steering Flow 2.6 gpm 1.0 gpm Total Hydraulic Flow 7.0 gpm 6.2 gpm Overall Hydraulic Pump Flow 7.0 gpm 6.2 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 0 0 standard (2-valve rear remote coupler optional) No. of Optional Remote Valves 1 2 (optional; ISO 7241-1 series A or B) ▶ Fluid CapacityFuel Tank Capacity 6.1 gal 6.6 gal Coolant Capacity 4.0 qt 3.5 qt Crankcase Capacity 3.3 qt 4.2 qt Transmission / Hydraulic System Capacity 3.3 gal 3.0 gal Front Axle Fluid Capacity 0.8 gal 3.8 qt ▶ PTO & HitchPTO Type Transmission driven with one way clutch Live independent PTO (with hydraulic clutch) PTO Rear 540, 980 rpm STD (540 rpm) Mid-PTO Availability Not Published STD (2500 rpm) Category, 3-Point Hitch Category I SAE Category I Optional Hitch Lift Capacity 1653 lb 1,213 lb Hitch Lift Capacity (at 24”) 1290 lb 680 lb Lift Control Type Position control valve Quarter-inching valve ▶ Transmission & DrivetrainTransmission Type Gear (9 Forward, 3 Reverse) Hydrostatic transmission No. of Speeds 9 Forward, 3 Reverse 2 Range (Low-High) Max Travel Speed (Forward) 10.9 mph 8.4 mph Max Travel Speed (Reverse) 5.6 mph 6.5 mph Clutch Dry single plate Dry type single plate - Main clutch 9.45 in. Differential Lock & Limited Slip Options Standard Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS Steering Integral type power steering Integral power steering Brakes Multi-plate wet disc Mechanical, wet disc type Seat Suspension & Adjustability Fore and aft slide adjustment (position adjust lever) High-back deluxe seat with armrests; fore/aft slide and backrest tilt adjustment Front Axle Type Not Published 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published Not Published Drawbar Capacity 660 lb Max. drawbar load @ hitch: 550 lb. ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 92.9 in (without 3-point hitch) 95.5 in (without 3-point hitch) Overall Width 35.4 in 45.1 in Wheelbase 61.4 in 55.1 in Ground Clearance 11.8 in 6.5 in (minimum; 8.9 in at front axle) Min. Turn Radius without Brakes 6.9 ft (with brake applied) 7.5 ft Height to Top of ROPS 75.2 in 83.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1334 lb 1521 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Farm (R1): 5-12 front, 8-16 rear R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 5-12 18X8.5-10 R1 Agricultural - Rear 8-16 26X12-12 R3 Turf - Front Not Published 18X8.5-10 R3 Turf - Rear Not Published 26X12-12 R4 Industrial - Front Not Published 18X8.5-10 R4 Industrial - Rear Not Published 26X12-12 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Swift-Tach Loader (LA344S - Two Lever Quick Attach Bucket) Loader Model Not Published LA344S (standard, quick attach); LA344 (pin-on option) Loader Lift Height Not Published 71.0 in Loader Lift Capacity (Full Height) Not Published 739 lb (LA344 pin-on); 613 lb (LA344S quick attach) Loader Breakout Force Not Published 1,407 lbf (LA344 pin-on); 1,286 lbf (LA344S quick attach) ▶ WarrantyWarranty Length & Coverage Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. ▶ ITC Company AccessoriesAccessories that fit
