▶ EngineEngine Manufacturer Kubota Yanmar Engine Model D1105 3TNM74F Engine Type E-TVCS, liquid cooled, 3-cylinder diesel 3 cylinder, water-cooled diesel, natural aspiration No. of Cylinders 3 3 Displacement 68.5 in³ 60.6 in³ Rated Engine Speed 2600 rpm 3200 rpm Engine Power (Gross) 21.9 hp 21.5 hp PTO Power 19.2 hp 15.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid Cooled Water-cooled Air Cleaner Dual paper element Single dry element Fuel System Not Published Indirect injection Alternator 40 A 40 A, 12 V ▶ HydraulicsPump Type Dual pump Single gear pump with flow divider Implement Flow 4.4 gpm 4.17 gpm Steering Flow 2.6 gpm 2.11 gpm Total Hydraulic Flow 7.0 gpm 6.3 gpm Overall Hydraulic Pump Flow 7.0 gpm 6.97 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 0 Not Published No. of Optional Remote Valves 1 1 ▶ Fluid CapacityFuel Tank Capacity 6.1 gal 6.6 gal Coolant Capacity 4.0 qt 3.7 qt Crankcase Capacity 3.3 qt 2.1 qt Transmission / Hydraulic System Capacity 3.3 gal 3.6 gal Front Axle Fluid Capacity 0.9 gal 2.6 qt ▶ PTO & HitchPTO Type Transmission driven with one way clutch Independent PTO Rear 540, 1000 rpm 540 rpm Mid-PTO Availability 2500 rpm Optional, 2,500 rpm Category, 3-Point Hitch Category I Category 1 (limited) Hitch Lift Capacity 1653 lb 1,100 lb Hitch Lift Capacity (at 24”) 1290 lb 679 lb Lift Control Type Position control valve Position control ▶ Transmission & DrivetrainTransmission Type Gear (9 Forward, 3 Reverse) Hydrostatic (HST) No. of Speeds 9 Forward, 3 Reverse 2 range Max Travel Speed (Forward) 11.7 mph 7.8 mph Max Travel Speed (Reverse) 6.0 mph Not Published Clutch Dry single plate Dry single plate Differential Lock & Limited Slip Options Standard Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Sub-compact tractor, 4WD Steering Integral type power steering Hydrostatic power steering Brakes Multi-plate wet disc Wet disc Seat Suspension & Adjustability Fore and aft slide adjustment (position adjust lever) Standard adjustable seat Front Axle Type Not Published Selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity 660 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 93.9 in (without 3-point hitch) 94.2 in Overall Width 44.3 in 44.5 in Wheelbase 61.4 in 53.1 in Ground Clearance 12.0 in 8.3 in Min. Turn Radius without Brakes 6.9 ft (with brake applied) 86.6 in Height to Top of ROPS 83.9 in 86.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1521 lb 1,433 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Farm (R1): 6-12 front, 9.5-16 rear; Turf (R3): 23x8.50-12 front, 33x12.5-15 rear; Industrial (R4): 23x8.50-12 front, 12-16.5 rear; R14: 23x8.50-12 front, 12-16.5 rear R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 6-12 16x7.50-9 R1 Agricultural - Rear 9.5-16 24x12.00-12 R3 Turf - Front 23x8.50-12 18x8.5-10 R3 Turf - Rear 33x12.5-15 26x12.00-12 R4 Industrial - Front 23x8.50-12 18x8.5-10 R4 Industrial - Rear 12-16.5 26x12.00-12 ▶ Loader & AttachmentsQuick Attach Loader System LA435 Swift-Tach Loader; 1-lever Quick Coupler (standard); 2-Lever Quick Coupler (optional) Quick attach front loader Loader Model LA435 BBL100 Loader Lift Height 78.5 in 78.5 in Loader Lift Capacity (Full Height) 948 lb 617 lb Loader Breakout Force 2,146 lbf 1,253 lbf ▶ WarrantyWarranty Length & Coverage Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. Engine and powertrain: 84 months or 2,000 hours; other tractor parts: 24 months or 1,000 hours; loader and backhoe: 24 months from shipment, 12 months from sale, or 500 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
