▶ EngineEngine Manufacturer Kubota Yanmar Engine Model D1105-E4-TLB-1 3TNE74 Engine Type 3-cylinder, indirect injection, liquid-cooled diesel 3-cylinder liquid-cooled diesel, indirect injection No. of Cylinders 3 3 Displacement 68.5 in³ 61.4 in³ Rated Engine Speed 2800 rpm 3000 rpm Engine Power (Gross) 23.3 hp 23 hp PTO Power 19.4 hp 17.7 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Single element Dry type with safety element Fuel System Indirect injection Indirect injection, in-line fuel pump with solenoid shutoff Alternator 40 A, 12 V 20 A ▶ HydraulicsPump Type Not Published Not Published Implement Flow 7.0 gpm 3 gpm Steering Flow 4.2 gpm 2.5 gpm Total Hydraulic Flow 11.1 gpm 5.5 gpm Overall Hydraulic Pump Flow 11.1 gpm 5.5 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 3 Not Published ▶ Fluid CapacityFuel Tank Capacity 8.1 gal 5.0 gal Coolant Capacity 4.7 qt 3.2 qt Crankcase Capacity 3.2 qt 2.2 qt Transmission / Hydraulic System Capacity 6.9 gal 3.4 gal Front Axle Fluid Capacity 5.0 qt 2.6 qt ▶ PTO & HitchPTO Type Independent Independent, wet disk clutch PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Standard, 2100 rpm Category, 3-Point Hitch Category I (optional) Category 1 Hitch Lift Capacity 2,139 lb Not Published Hitch Lift Capacity (at 24”) 1,676 lb 701 lb Lift Control Type Position control Not Published ▶ Transmission & DrivetrainTransmission Type HST Plus hydrostatic transmission, 3-range 2-range hydrostatic No. of Speeds 3-range (infinite) Infinite forward and reverse, 2 ranges Max Travel Speed (Forward) 11.1 mph 8.4 mph Max Travel Speed (Reverse) 9.8 mph 6.3 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Rear axle differential lock standard Not Published ▶ Chassis, Steering & ControlsFrame Type Four-post ROPS/FOPS standard Two-post fixed ROPS; four-wheel drive Steering Hydrostatic power steering Power steering Brakes Wet disc Wet disk Seat Suspension & Adjustability Reversible seat; tilt steering standard Not Published Front Axle Type Not Published MFWD, standard, all ranges, on-the-go engagement Front Axle Rating Not Published 3,120 lb Drawbar Capacity 1,100 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 53.7 in 47.2 in Wheelbase 62.2 in 57.1 in Ground Clearance 13.8 in 7.7 in (front axle) Min. Turn Radius without Brakes 8.2 ft 88.6 in (MFWD off) Height to Top of ROPS 89.5 in 77.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 100.7 in (without 3-point hitch) 104.3 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,606 lb 1,400 lb (with all fluids) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Industrial (R4): 23x8.5-14 R4 front, 12.4-16 R4 rear; turf 24x8.50-14 front, 13.6-16 rear 18x8.5-10 front and 26x12.00-12 rear; R1 standard, R3 optional R1 Agricultural - Front Not Published 18x8.5-10 R1 Agricultural - Rear Not Published 26x12.00-12 R3 Turf - Front 24x8.50-14 18x8.5-10 R3 Turf - Rear 13.6-16 26x12.00-12 R4 Industrial - Front 23x8.50-14 R4 18x8.50-10 R4 Industrial - Rear 12.4-16 R4 26x12.00-12 ▶ Loader & AttachmentsQuick Attach Loader System TL500: 2-lever quick coupler standard Not Published Loader Model TL500 210 Loader Lift Height TL500: 94.5 in (at pivot pin) 210: 68.5 in (at pivot pin) Loader Lift Capacity (Full Height) TL500: 1,301 lb (at pivot pin) 210: 622 lb (to max height at pivot point) Loader Breakout Force TL500: 2,343 lbf (at pivot pin) 210: 1,577 lbf (at pivot point) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
