▶ EngineEngine Manufacturer Kubota Mitsubishi Engine Model D1105-E4-TLB-1 Not Published Engine Type E-TVCS, 3-cylinder, liquid-cooled diesel Three cylinder, four cycle, valve in cylinder head, cross flow porting diesel No. of Cylinders 3 3 Displacement 68.5 in³ 80.43 in³ Rated Engine Speed 2800 rpm 2600 rpm Engine Power (Gross) 26 hp 26 hp PTO Power 19.5 hp 23 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Liquid-cooled, pressurized, thermostat controlled bypass, impeller pump Air Cleaner Single element Dry type with double filter Fuel System Indirect injection (E-TVCS) Indirect injection; Bosch M type ND-PFR (Denso) injection pump, throttle type injectors Alternator 40 A, 12 V 50 A ▶ HydraulicsPump Type Not Published Gear type, front mounted, engine driven Implement Flow 7.0 gpm 7.8 gpm Steering Flow 4.2 gpm 3.4 gpm Total Hydraulic Flow 11.1 gpm 11.2 gpm (7.8 + 3.4, computed) Overall Hydraulic Pump Flow 11.1 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 3 1 ▶ Fluid CapacityFuel Tank Capacity 8.1 gal Not Published Coolant Capacity 4.7 qt Not Published Crankcase Capacity 3.2 qt Not Published Transmission / Hydraulic System Capacity 6.9 gal Not Published Front Axle Fluid Capacity 4.7 qt Not Published ▶ PTO & HitchPTO Type Independent Independent (3016 Gear Drive); Live (3016 Hydrostatic Drive) PTO Rear 540 rpm 540 rpm @ 2376 rpm Mid-PTO Availability Not Published Optional; 2000 rpm @ 2525 rpm Category, 3-Point Hitch Category I (optional) CAT I Hitch Lift Capacity 2139 lb Not Published Hitch Lift Capacity (at 24”) 1676 lb 1720 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type HST Plus hydrostatic transmission, 3-range Synchro shuttle, constant mesh main with 2 ranges (3016 Gear Drive); Hydrostatic, 3 ranges (3016 Hydrostatic Drive) No. of Speeds 3-range (infinite) 8F/8R (3016 Gear Drive); Infinite, 3 ranges (3016 Hydrostatic Drive) Max Travel Speed (Forward) 11.1 mph 11.9 mph (3016 Gear Drive); 13.8 mph (3016 Hydrostatic Drive) Max Travel Speed (Reverse) 9.8 mph 9.9 mph (3016 Gear Drive); 6.9 mph (3016 Hydrostatic Drive) Clutch Not Published Dry single disc, diaphragm type, 8.46 in Differential Lock & Limited Slip Options Rear axle differential lock standard Mechanical differential lock, pedal actuated ▶ Chassis, Steering & ControlsFrame Type Four-post ROPS/FOPS standard Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc Wet disc, mechanical Seat Suspension & Adjustability Reversible seat; tilt steering standard Not Published Front Axle Type Not Published Mechanical front drive (MFD), spiral bevel gear differential with bevel gear reductions Front Axle Rating Not Published Not Published Drawbar Capacity 1100 lb 969 lbf ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 100.7 in (w/o 3P) (without 3-point hitch) 121.3 in Overall Width 53.7 in 63 in Wheelbase 62.2 in 67.3 in Ground Clearance 13.8 in 11.4 in Min. Turn Radius without Brakes 8.2 ft 7.9 ft (with brake applied) Height to Top of ROPS 89.5 in 81.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2606 lb 2437 lb (3016 Gear Drive); 2459 lb (3016 Hydrostatic Drive) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Industrial (R4): 23x8.5-14 R4 front, 12.4-16 R4 rear; turf 24x8.50-14 front, 13.6-16 rear Not Published R1 Agricultural - Front Not Published 7x16 R1 Agricultural - Rear Not Published 11.2x24 R3 Turf - Front 24x8.50-14 25x8.5-14 R3 Turf - Rear 13.6-16 13.6x16 R4 Industrial - Front 23x8.50-14 R4 27x8.50-15 R4 Industrial - Rear 12.4-16 R4 15x19.5 ▶ Loader & AttachmentsQuick Attach Loader System TL500: 2-lever quick coupler standard Not Published Loader Model TL500 ML115 Loader Lift Height TL500: 94.5 in ML115: 99 in Loader Lift Capacity (Full Height) TL500: 1301 lb ML115: 1,650 lb Loader Breakout Force TL500: 2343 lbf ML115: 2,650 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
