▶ EngineEngine Manufacturer Kubota Kubota Engine Model D1105 D1105 Engine Type E-TVCS, liquid cooled, 3-cylinder diesel E-TVCS, liquid cooled, 3-cylinder diesel No. of Cylinders 3 3 Displacement 68.5 in³ 68.5 in³ Rated Engine Speed 2800 rpm 2600 rpm Engine Power (Gross) 24.3 hp 21.9 hp PTO Power 19.5 hp 19.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Pressurized radiator Liquid Cooled Air Cleaner Dual paper element Dual paper element Fuel System diesel Not Published Alternator Not Published 40 A ▶ HydraulicsPump Type Dual pump Dual pump Implement Flow Not Published 4.4 gpm Steering Flow Not Published 2.6 gpm Total Hydraulic Flow 8.3 gpm 7.0 gpm Overall Hydraulic Pump Flow 8.3 gpm 7.0 gpm Hydraulic System Type open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 0 No. of Optional Remote Valves 2 1 ▶ Fluid CapacityFuel Tank Capacity 6.1 gal 6.1 gal Coolant Capacity 4.0 qt 4.0 qt Crankcase Capacity 3.3 qt 3.3 qt Transmission / Hydraulic System Capacity 4.0 gal 3.3 gal Front Axle Fluid Capacity 3.7 qt 0.9 gal ▶ PTO & HitchPTO Type Independent Transmission driven with one way clutch PTO Rear 540 rpm 540, 1000 rpm Mid-PTO Availability independent, 2500 rpm 2500 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1808 lb 1653 lb Hitch Lift Capacity (at 24”) 1411 lb 1290 lb Lift Control Type position control Position control valve ▶ Transmission & DrivetrainTransmission Type HST (3 ranges) Gear (9 Forward, 3 Reverse) No. of Speeds 3 ranges (HST) 9 Forward, 3 Reverse Max Travel Speed (Forward) 12.7 mph 11.7 mph Max Travel Speed (Reverse) 9.5 mph 6.0 mph Clutch Not Published Dry single plate Differential Lock & Limited Slip Options Standard Standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Integral type power steering Brakes Wet disc brakes Multi-plate wet disc Seat Suspension & Adjustability High-back suspension seat with standard arm rests; tilt steering (HST models) Fore and aft slide adjustment (position adjust lever) Front Axle Type Four-wheel drive Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 660 lb 660 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 94.9 in (without 3-point hitch) 93.9 in (without 3-point hitch) Overall Width 49 in 44.3 in Wheelbase 61.4 in 61.4 in Ground Clearance 12.8 in 12.0 in Min. Turn Radius without Brakes 6.9 ft (with brake applied) 6.9 ft (with brake applied) Height to Top of ROPS 85.0 in 83.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1632 lb 1521 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Farm (R1): 7-12 front, 11.2-16 rear; Turf (R3): 23x8.50-12 front, 33x12.5-15 rear; Industrial (R4): 23x8.50-12 front, 12-16.5 rear Farm (R1): 6-12 front, 9.5-16 rear; Turf (R3): 23x8.50-12 front, 33x12.5-15 rear; Industrial (R4): 23x8.50-12 front, 12-16.5 rear; R14: 23x8.50-12 front, 12-16.5 rear R1 Agricultural - Front 7-12 6-12 R1 Agricultural - Rear 11.2-16 9.5-16 R3 Turf - Front 23x8.50-12 23x8.50-12 R3 Turf - Rear 33x12.5-15 33x12.5-15 R4 Industrial - Front 23x8.50-12 23x8.50-12 R4 Industrial - Rear 12-16.5 12-16.5 ▶ Loader & AttachmentsQuick Attach Loader System LA435 Swift-Tach Loader (1-lever Quick Coupler) LA435 Swift-Tach Loader; 1-lever Quick Coupler (standard); 2-Lever Quick Coupler (optional) Loader Model LA435 LA435 Loader Lift Height 78.5 in 78.5 in Loader Lift Capacity (Full Height) 948 lb 948 lb Loader Breakout Force 2146 lb 2,146 lbf ▶ WarrantyWarranty Length & Coverage Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. ▶ ITC Company AccessoriesAccessories that fit
