▶ EngineEngine Manufacturer Kubota Kubota Engine Model D1305-E4-D26-R D1105-E4-TLB-1 Engine Type 3-cylinder, indirect injection, liquid-cooled diesel 3-cylinder, indirect injection, liquid-cooled diesel No. of Cylinders 3 3 Displacement 77.0 in³ 68.5 in³ Rated Engine Speed 2500 rpm 2800 rpm Engine Power (Gross) 24.8 hp 23.3 hp PTO Power 19.5 hp 19.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled, pressurized radiator Liquid-cooled Air Cleaner 4.0 in dual paper element Single element Fuel System Indirect injection Indirect injection Alternator B2650HSD (ROPS): 14.5 A; B2650HSDC (cab): 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Dual pump Not Published Implement Flow 5.3 gpm 7.0 gpm Steering Flow Not Published 4.2 gpm Total Hydraulic Flow 8.7 gpm 11.1 gpm Overall Hydraulic Pump Flow 8.7 gpm 11.1 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 (rear outlet) Not Published No. of Optional Remote Valves Not Published Up to 3 ▶ Fluid CapacityFuel Tank Capacity 7.3 gal 8.1 gal Coolant Capacity 4.5 qt 4.7 qt Crankcase Capacity 4.2 qt 3.2 qt Transmission / Hydraulic System Capacity 4.0 gal 6.9 gal Front Axle Fluid Capacity Not Published 5.0 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability 2500 rpm Not Published Category, 3-Point Hitch Category I Category I (optional) Hitch Lift Capacity 2,139 lb 2,139 lb Hitch Lift Capacity (at 24”) 1,676 lb 1,676 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission, 3-range HST Plus hydrostatic transmission, 3-range No. of Speeds 3-range 3-range (infinite) Max Travel Speed (Forward) 11.9 mph 11.1 mph Max Travel Speed (Reverse) 9.5 mph 9.8 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Differential lock standard Rear axle differential lock standard ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS (cab optional) Four-post ROPS/FOPS standard Steering Hydraulic power steering Hydrostatic power steering Brakes Multi-plate wet disc Wet disc Seat Suspension & Adjustability Deluxe seat, parallel link with damper seat suspension Reversible seat; tilt steering standard Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,100 lb ▶ Dimensions & ManeuverabilityOverall Width 53.7 in 53.7 in Wheelbase 65.6 in 62.2 in Ground Clearance 14.6 in 13.8 in Min. Turn Radius without Brakes 6.9 ft (with brake applied) 8.2 ft Height to Top of ROPS 88.4 in 89.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 84.6 in Not Published Overall Length 101.2 in (without 3-point hitch) 100.7 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 1,786 lb 2,606 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard farm: 7-12 front, 12.4-16 rear; turf and industrial optional Industrial (R4): 23x8.5-14 R4 front, 12.4-16 R4 rear; turf 24x8.50-14 front, 13.6-16 rear R1 Agricultural - Front 7-12 Not Published R1 Agricultural - Rear 12.4-16 Not Published R3 Turf - Front 24x8.50-14 24x8.50-14 R3 Turf - Rear 13.6-16 13.6-16 R4 Industrial - Front 23x8.50-14 23x8.50-14 R4 R4 Industrial - Rear 12.4-16 12.4-16 R4 ▶ Loader & AttachmentsQuick Attach Loader System LA534A: 2-lever quick coupler (optional) TL500: 2-lever quick coupler standard Loader Model LA534A TL500 Loader Lift Height LA534A: 84.6 in (at pivot pin) TL500: 94.5 in (at pivot pin) Loader Lift Capacity (Full Height) LA534A: 1,146 lb (at pivot pin) TL500: 1,301 lb (at pivot pin) Loader Breakout Force LA534A: 2,321 lbf (at pivot pin) TL500: 2,343 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
