▶ EngineEngine Manufacturer Kubota Iseki Engine Model D1305-E4-D26-R E3CD Engine Type E-TVCS, liquid-cooled, 3-cylinder diesel 3-cylinder, liquid-cooled diesel No. of Cylinders 3 3 Displacement 77.0 in³ 91.4 in³ Rated Engine Speed 2500 rpm 2600 rpm Engine Power (Gross) 24.8 hp 24.8 hp PTO Power 19.5 hp 20.1 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled, pressurized radiator Liquid cooled Air Cleaner 4.0 in dual paper element Not Published Fuel System Indirect injection Not Published Alternator B2650HSD (ROPS): 14.5 A; B2650HSDC (cab): 40 A, 12 V Not Published ▶ HydraulicsPump Type Dual pump Not Published Implement Flow 5 gpm 5.5 gpm Steering Flow 3.7 gpm 3.2 gpm Total Hydraulic Flow 8.7 gpm 8.7 gpm Overall Hydraulic Pump Flow 8.7 gpm 8.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 5.5 gpm No. of Standard Remote Valves 1 (rear outlet) Not Published No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 7.3 gal 7.1 gal Coolant Capacity 4.5 qt Not Published Crankcase Capacity 4.2 qt Not Published Transmission / Hydraulic System Capacity 4.0 gal Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Standard mid-PTO, 2500 rpm Independent, 2000 rpm (optional) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2139 lb 1,322 lb Hitch Lift Capacity (at 24”) 1676 lb 992 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission, 3-range Hydrostatic No. of Speeds 3-range Infinite forward and reverse (3-range) Max Travel Speed (Forward) 11.9 mph Not Published Max Travel Speed (Reverse) 9.5 mph Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Rear differential lock standard Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS (cab optional) Not Published Steering Hydraulic power steering Power steering Brakes Multi-plate wet disc Wet, multiple disc Seat Suspension & Adjustability Deluxe seat with parallel link and damper seat suspension Adjustable mechanical suspension Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 101.2 in (w/o 3P) (without 3-point hitch) 111 in Overall Width 53.7 in 55.1 in Wheelbase 65.6 in 61.4 in Ground Clearance 14.6 in 11.6 in Min. Turn Radius without Brakes 6.9 ft (w/brake) (with brake applied) Not Published Height to Top of ROPS 88.4 in 96.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 84.6 in Not Published ▶ WeightTractor Weight (Base) 1786 lb 2,077 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard farm (R1): 7-12 front, 12.4-16 rear; turf and industrial optional R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 7-12 7-12 R1 Agricultural - Rear 12.4-16 35x12.00-16.5 or 9.5-16 R3 Turf - Front 24x8.50-14 25x8.50-14 R3 Turf - Rear 13.6-16 36x13.50-15 R4 Industrial - Front 23x8.50-14 25x8.50-14 R4 Industrial - Rear 12.4-16 14-17 ▶ Loader & AttachmentsQuick Attach Loader System LA534A: 2-lever quick coupler (optional), quick attach/detach mounting Not Published Loader Model LA534A FLx2106 Loader Lift Height LA534A: 84.6 in FLx2106: 83 in Loader Lift Capacity (Full Height) LA534A: 1146 lb FLx2106: 852 lb (to full height, at 19.5 in forward of pivot pin) Loader Breakout Force LA534A: 2321 lbf FLx2106: 1,282 lb (at 19.5 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
