▶ EngineEngine Manufacturer Kubota Iseki Engine Model D1305-E4-D26-R Not Published Engine Type E-TVCS, liquid-cooled, 3-cylinder diesel 3-cylinder, liquid-cooled diesel No. of Cylinders 3 3 Displacement 77.0 in³ 91.4 in³ Rated Engine Speed 2500 rpm 2600 rpm Engine Power (Gross) 24.8 hp 24.8 hp PTO Power 19.5 hp ROPS: 18.2 hp; CAB: 16.9 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled, pressurized radiator Liquid cooled Air Cleaner 4.0 in dual paper element Not Published Fuel System Indirect injection Not Published Alternator B2650HSD (ROPS): 14.5 A; B2650HSDC (cab): 40 A, 12 V Not Published ▶ HydraulicsPump Type Dual pump Not Published Implement Flow 5 gpm 5.5 gpm Steering Flow 3.7 gpm 3.2 gpm Total Hydraulic Flow 8.7 gpm 8.7 gpm (5.5 + 3.2, computed) Overall Hydraulic Pump Flow 8.7 gpm 8.7 gpm (5.5 + 3.2, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 (rear outlet) 2 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 7.3 gal 7.4 gal Coolant Capacity 4.5 qt Not Published Crankcase Capacity 4.2 qt Not Published Transmission / Hydraulic System Capacity 4.0 gal Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm, 1.375 in Mid-PTO Availability Standard mid-PTO, 2500 rpm Independent, 2000 rpm (optional) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2139 lb 1,433 lb Hitch Lift Capacity (at 24”) 1676 lb 1,091 lb Lift Control Type Position control Not Published ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission, 3-range Hydrostatic No. of Speeds 3-range Infinite forward and reverse (3-range) Max Travel Speed (Forward) 11.9 mph Not Published Max Travel Speed (Reverse) 9.5 mph Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Rear differential lock standard Differential lock (LHS pedal) ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS (cab optional) Not Published Steering Hydraulic power steering Power steering Brakes Multi-plate wet disc Internal wet disc Seat Suspension & Adjustability Deluxe seat with parallel link and damper seat suspension Not Published Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 101.2 in (w/o 3P) (without 3-point hitch) 116 in Overall Width 53.7 in 45.7-52 in Wheelbase 65.6 in 61.4 in Ground Clearance 14.6 in 9.9-11 in Min. Turn Radius without Brakes 6.9 ft (w/brake) (with brake applied) Not Published Height to Top of ROPS 88.4 in 95.3-97.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 84.6 in 80-82.1 in ▶ WeightTractor Weight (Base) 1786 lb ROPS: 2,044 lb; Cab: 2,169 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard farm (R1): 7-12 front, 12.4-16 rear; turf and industrial optional R1 Agricultural, R3 Turf R1 Agricultural - Front 7-12 6.00-12 R1 Agricultural - Rear 12.4-16 9.5-18 R3 Turf - Front 24x8.50-14 24X8.50-12 R3 Turf - Rear 13.6-16 315X75D-15 R4 Industrial - Front 23x8.50-14 Not Published R4 Industrial - Rear 12.4-16 Not Published ▶ Loader & AttachmentsQuick Attach Loader System LA534A: 2-lever quick coupler (optional), quick attach/detach mounting Skid Steer Loader Model LA534A FL.2106 Loader Lift Height LA534A: 84.6 in FL.2106: 83 in Loader Lift Capacity (Full Height) LA534A: 1146 lb FL.2106: 1,222 lb Loader Breakout Force LA534A: 2321 lbf FL.2106: 1,822 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
