▶ EngineEngine Manufacturer Kubota Yanmar Engine Model D1305-E4-D26-R 3TNV80F Engine Type E-TVCS, liquid-cooled, 3-cylinder diesel 3-cylinder, naturally aspirated, liquid-cooled diesel No. of Cylinders 3 3 Displacement 77.0 in³ 77.3 in³ Rated Engine Speed 2500 rpm 3000 rpm Engine Power (Gross) 24.8 hp 24.7 hp PTO Power 19.5 hp 17.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled, pressurized radiator Pressurized liquid with recirculating bypass Air Cleaner 4.0 in dual paper element Single-element dry air cleaner Fuel System Indirect injection In-line injection pump, indirect injection (swirl chamber) Alternator B2650HSD (ROPS): 14.5 A; B2650HSDC (cab): 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Dual pump Gear Implement Flow 5 gpm 4.6 gpm Steering Flow 3.7 gpm 2.1 gpm Total Hydraulic Flow 8.7 gpm 6.7 gpm Overall Hydraulic Pump Flow 8.7 gpm 6.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 (rear outlet) 0 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 7.3 gal 6.6 gal Coolant Capacity 4.5 qt 3.49 qt Crankcase Capacity 4.2 qt 3 qt Transmission / Hydraulic System Capacity 4.0 gal 3.3 gal Front Axle Fluid Capacity Not Published 0.5 gal ▶ PTO & HitchPTO Type Independent Independent, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Standard mid-PTO, 2500 rpm Standard (2,500 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2139 lb 992 lb Hitch Lift Capacity (at 24”) 1676 lb 728 lb Lift Control Type Position control Lift-hold-lower ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission, 3-range 2-range hydrostatic, dual pedal No. of Speeds 3-range Infinite (2 ranges) Max Travel Speed (Forward) 11.9 mph 9.1 mph Max Travel Speed (Reverse) 9.5 mph 5.5 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Rear differential lock standard Mechanical, foot-operated rear differential lock ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS (cab optional) Not Published Steering Hydraulic power steering Hydrostatic power steering Brakes Multi-plate wet disc Wet, multi-disc Seat Suspension & Adjustability Deluxe seat with parallel link and damper seat suspension Deluxe high-back seat with armrests and adjustable backrest Front Axle Type Not Published 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 101.2 in (w/o 3P) (without 3-point hitch) 97.4 in Overall Width 53.7 in 46.7 in Wheelbase 65.6 in 56.1 in Ground Clearance 14.6 in 12 in Min. Turn Radius without Brakes 6.9 ft (w/brake) (with brake applied) 94 in Height to Top of ROPS 88.4 in 90 in Height to Top of ROPS (folded) Not Published 64 in Height to Top of Cab Model 84.6 in 87.4 in ▶ WeightTractor Weight (Base) 1786 lb ROPS: 1,444 lb; Cab: 1,805 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard farm (R1): 7-12 front, 12.4-16 rear; turf and industrial optional R3 Turf, R4 Industrial R1 Agricultural - Front 7-12 Not Published R1 Agricultural - Rear 12.4-16 Not Published R3 Turf - Front 24x8.50-14 18x8.50-10 R3 Turf - Rear 13.6-16 26x12.0-12 R4 Industrial - Front 23x8.50-14 18x8.50-10 R4 Industrial - Rear 12.4-16 26x12.0-12 ▶ Loader & AttachmentsQuick Attach Loader System LA534A: 2-lever quick coupler (optional), quick attach/detach mounting 100LC: Quick Mount system, no tools needed Loader Model LA534A 100LC Loader Lift Height LA534A: 84.6 in 100LC: 72 in Loader Lift Capacity (Full Height) LA534A: 1146 lb 100LC: 1,005 lb Loader Breakout Force LA534A: 2321 lbf 100LC: 2,078 lb ▶ WarrantyWarranty Length & Coverage Not Published Boomer Guard6 limited warranty: 2 years or 750 hours full coverage plus powertrain coverage to 6 years or 1,500 hours total
