▶ EngineEngine Manufacturer Kubota Yanmar Engine Model D1305-E3-D22 3TNV88C-NJT2 Engine Type E-TVCS, liquid-cooled, 3-cylinder diesel Diesel, naturally aspirated No. of Cylinders 3 3 Displacement 77.0 in³ 100.2 in³ Rated Engine Speed 2800 rpm 2500 rpm Engine Power (Gross) 29 hp 30.7 hp PTO Power 21 hp 25 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled, pressurized radiator Water pump Air Cleaner Not Published Dry type with safety element Fuel System Indirect injection (E-TVCS) High pressure common rail direct injection Alternator 14.5 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Dual pump (3-point + power steering) Implement/steering pump: Tandem gear; hydrostatic pump: PV axial piston Implement Flow 4.7 gpm 5.3 gpm Steering Flow 3.6 gpm 4.0 gpm Total Hydraulic Flow 8.3 gpm (4.7 + 3.6, computed) 9.3 gpm Overall Hydraulic Pump Flow Not Published 10.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 or 2 Not Published No. of Optional Remote Valves Not Published Up to 2 (optional) ▶ Fluid CapacityFuel Tank Capacity 6.9 gal (6.9 U.S. gal, all models) 7.5 gal Coolant Capacity 4.1 qt 1.3 gal Crankcase Capacity 3.7 qt 4.5 qt Transmission / Hydraulic System Capacity 4.0 gal 5.5 gal Front Axle Fluid Capacity Not Published 1.0 gal ▶ PTO & HitchPTO Type Live Independent PTO Rear 540/960 rpm 540 rpm Mid-PTO Availability Optional mid-PTO, 2500 rpm (USA No. 5, Kubota 10-tooth) Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1356 lb Not Published Hitch Lift Capacity (at 24”) 1058 lb 1356 lb Lift Control Type Position control valve, quarter inching valve Position control ▶ Transmission & DrivetrainTransmission Type Main-hydrostatic transmission, 3-range Hydrostatic (2-range) No. of Speeds 3-range (3 forward, 3 reverse) Infinite (2-range HST) Max Travel Speed (Forward) 12.6 mph Not Published Max Travel Speed (Reverse) 10.0 mph Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Rear differential lock standard Not Published ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS (sunshade optional) Not Published Steering Integral type power steering Power steering Brakes Wet disk type Wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published 4WD (MFWD) Front Axle Rating Not Published 1760 lb Drawbar Capacity Not Published 880 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 95.1 in (w/o 3P) (without 3-point hitch) 115.9 in Overall Width 49.0 in 56.9 in (min. rear tread, standard R1 tires); 61.7 in (max. rear tread, larger R4 tires) Wheelbase 61.5 in 62.8 in Ground Clearance 12.8 in 12.7 in (R4 tires) Min. Turn Radius without Brakes 6.9 ft (w/brake) (with brake applied) 9.4 ft (2.9 m) Height to Top of ROPS 85.0 in 95.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1554 lb 2266 lb Weight with ROPS and Loader Not Published 2972 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard farm 7-12 front, 11.2-16 rear R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 7-12 7-14 R1 Agricultural - Rear 11.2-16 11.2-24 R3 Turf - Front Not Published 27X8.50-15 R3 Turf - Rear Not Published 41X14-20 R4 Industrial - Front 23x8.50-12 25X8.50-14 or 27X8.50-15 R4 Industrial - Rear 12-16.5 15.00-19.5 or 43X16-20 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick-change attachment carrier Loader Model LA364 D160 Loader Lift Height LA364: 78.6 in 84.0 in Loader Lift Capacity (Full Height) LA364: 952 lb 1,186 lb Loader Breakout Force LA364: 2144 lbf 1,704 lb ▶ WarrantyWarranty Length & Coverage Not Published 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)
