▶ EngineEngine Manufacturer Kubota Kubota Engine Model D1305-E3-D22 V1505-E3-D24H Engine Type E-TVCS, liquid-cooled, 3-cylinder diesel Indirect injection, vertical, water-cooled, 4-cycle diesel No. of Cylinders 3 4 Displacement 77.0 in³ 91.5 in³ Rated Engine Speed 2800 rpm 2700 rpm Engine Power (Gross) 29 hp 33 hp PTO Power 21 hp 25 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Liquid-cooled, pressurized radiator Water-cooled Air Cleaner Not Published Dual paper element Fuel System Indirect injection (E-TVCS) Indirect injection Alternator 14.5 A, 12 V 14.5 A, 12 V ▶ HydraulicsPump Type Dual pump (3-point + power steering) Not Published Implement Flow 4.7 gpm 6.7 gpm Steering Flow 3.6 gpm 3.2 gpm Total Hydraulic Flow 8.3 gpm (4.7 + 3.6, computed) 9.9 gpm Overall Hydraulic Pump Flow Not Published 9.9 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 or 2 Not Published No. of Optional Remote Valves Not Published 1 (optional rear valve) ▶ Fluid CapacityFuel Tank Capacity 6.9 gal (6.9 U.S. gal, all models) 8.1 gal Coolant Capacity 4.1 qt 4.7 qt Crankcase Capacity 3.7 qt 5.7 qt Transmission / Hydraulic System Capacity 4.0 gal 3.83 gal Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Live Live PTO Rear 540/960 rpm 540 rpm Mid-PTO Availability Optional mid-PTO, 2500 rpm (USA No. 5, Kubota 10-tooth) None (no mid-PTO) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1356 lb 1786 lb Hitch Lift Capacity (at 24”) 1058 lb 1400 lb Lift Control Type Position control valve, quarter inching valve Quarter inching valve ▶ Transmission & DrivetrainTransmission Type Main-hydrostatic transmission, 3-range Hydrostatic transmission, 3-range No. of Speeds 3-range (3 forward, 3 reverse) 3-range Max Travel Speed (Forward) 12.6 mph 11.9 mph Max Travel Speed (Reverse) 10.0 mph 9.5 mph Clutch Not Published Dry single plate Differential Lock & Limited Slip Options Rear differential lock standard Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS (sunshade optional) Two-post ROPS (sunshade optional) Steering Integral type power steering Integral type power steering Brakes Wet disk type Wet disc type Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1100 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 95.1 in (w/o 3P) (without 3-point hitch) 99.2 in (w/o 3P) (without 3-point hitch) Overall Width 49.0 in 53.7 in Wheelbase 61.5 in 66.8 in Ground Clearance 12.8 in 14.6 in Min. Turn Radius without Brakes 6.9 ft (w/brake) (with brake applied) 7.9 ft (w/brake) (with brake applied) Height to Top of ROPS 85.0 in 88.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1554 lb 1764 lb (farm tires); 1786 lb (industrial tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard farm 7-12 front, 11.2-16 rear Not Published R1 Agricultural - Front 7-12 7-12 R1 Agricultural - Rear 11.2-16 12.4-16 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published 13.6-16 R4 Industrial - Front 23x8.50-12 Not Published R4 Industrial - Rear 12-16.5 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model LA364 LA504 Loader Lift Height LA364: 78.6 in LA504: 82.6 in Loader Lift Capacity (Full Height) LA364: 952 lb LA504: 1065 lb Loader Breakout Force LA364: 2144 lbf Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
