▶ EngineEngine Manufacturer Kubota Shibaura Engine Model D1305-E3-D22 N843 Engine Type E-TVCS, liquid-cooled, 3-cylinder diesel 3-cylinder naturally aspirated diesel No. of Cylinders 3 3 Displacement 77.0 in³ 91.3 in³ Rated Engine Speed 2800 rpm 2600 rpm Engine Power (Gross) 29 hp 30 hp PTO Power 21 hp Gear: 25.5 hp; Hydrostatic: 24 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Liquid-cooled, pressurized radiator Liquid-cooled Air Cleaner Not Published Not Published Fuel System Indirect injection (E-TVCS) Not Published Alternator 14.5 A, 12 V Not Published ▶ HydraulicsPump Type Dual pump (3-point + power steering) Gear Implement Flow 4.7 gpm 6.2 gpm Steering Flow 3.6 gpm 3.8 gpm Total Hydraulic Flow 8.3 gpm (4.7 + 3.6, computed) 10.0 gpm (6.2 + 3.8, computed) Overall Hydraulic Pump Flow Not Published 10.0 gpm (6.2 + 3.8, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 or 2 Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 6.9 gal (6.9 U.S. gal, all models) 7.1 gal Coolant Capacity 4.1 qt Not Published Crankcase Capacity 3.7 qt Not Published Transmission / Hydraulic System Capacity 4.0 gal Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Live Live (FWD); transmission-driven (2WD gear) PTO Rear 540/960 rpm Gear 2WD: transmission-driven 540 rpm; Gear FWD: live 540 rpm; Hydrostatic FWD: live 540 rpm Mid-PTO Availability Optional mid-PTO, 2500 rpm (USA No. 5, Kubota 10-tooth) Optional on gear transmission: 2WD gear transmission-driven with overrunning clutch, 2000 rpm; FWD gear and hydrostatic: live 2000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1356 lb Not Published Hitch Lift Capacity (at 24”) 1058 lb 1,635 lb Lift Control Type Position control valve, quarter inching valve Not Published ▶ Transmission & DrivetrainTransmission Type Main-hydrostatic transmission, 3-range Gear: 9x3; Hydrostatic: 3-range (FWD only) No. of Speeds 3-range (3 forward, 3 reverse) Gear: 9F/3R; Hydrostatic: 3 ranges Max Travel Speed (Forward) 12.6 mph Gear: 12.9 mph (R1 tires), 12.1 mph (R4 tires); Hydrostatic: 14.5 mph (R1 tires), 13.6 mph (R4 tires) Max Travel Speed (Reverse) 10.0 mph Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Rear differential lock standard Mechanical rear differential lock (heel pedal) ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS (sunshade optional) Not Published Steering Integral type power steering Power steering Brakes Wet disk type Wet disc Seat Suspension & Adjustability Not Published Padded contoured seat on an inclined track Front Axle Type Not Published FWD (standard); 2WD (optional) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 95.1 in (w/o 3P) (without 3-point hitch) 2WD, ag tires: 108.9 in; FWD, R4 tires: 111.4 in (both with 3-point hitch raised) Overall Width 49.0 in 54.3 in (minimum, ag tires); 62 in (R4 tires) Wheelbase 61.5 in 63.0 in Ground Clearance 12.8 in Not Published Min. Turn Radius without Brakes 6.9 ft (w/brake) (with brake applied) Not Published Height to Top of ROPS 85.0 in 82.3 in (R4 tires) Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1554 lb 2,193 lb (2WD, ag tires, 9x3 gear); 2,385 lb (FWD, R4 tires, 9x3 gear) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard farm 7-12 front, 11.2-16 rear R1 Ag 7.4x14 / 11.2x24; R3 Turf 24x8.50-14 / 13.6x16; R4 Industrial 25x8.50-14 / 15x19.5 R1 Agricultural - Front 7-12 Not Published R1 Agricultural - Rear 11.2-16 11.2x24 R3 Turf - Front Not Published 24x8.50-14 R3 Turf - Rear Not Published 13.6x16 R4 Industrial - Front 23x8.50-12 25x8.50-14 R4 Industrial - Rear 12-16.5 15x19.5 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model LA364 7308 Loader Lift Height LA364: 78.6 in 7308: 100.5 in Loader Lift Capacity (Full Height) LA364: 952 lb 7308: 875 lb Loader Breakout Force LA364: 2144 lbf 7308: 1,602 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
