▶ EngineEngine Manufacturer Kubota Yanmar Engine Model V1505-E3-D24H 3TNV88-BMJT Engine Type Indirect injection, vertical, water-cooled, 4-cycle diesel 3-cylinder liquid-cooled diesel, direct injection No. of Cylinders 4 3 Displacement 91.5 in³ 100.1 in³ Rated Engine Speed 2700 rpm 2600 rpm Engine Power (Gross) 33 hp 32.4 hp PTO Power 25 hp 25 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dual paper element Dry type with safety element Fuel System Indirect injection Direct injection, self bleeding, in-line fuel pump with electric shutoff Alternator 14.5 A, 12 V 40 A ▶ HydraulicsPump Type Not Published Dual tandem gear pump Implement Flow 6.7 gpm 8.6 gpm Steering Flow 3.2 gpm 5.3 gpm Total Hydraulic Flow 9.9 gpm 13.9 gpm Overall Hydraulic Pump Flow 9.9 gpm 13.9 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 1 (optional rear valve) Not Published ▶ Fluid CapacityFuel Tank Capacity 8.1 gal 13.5 gal (open station); 11.8 gal (cab) Coolant Capacity 4.7 qt 5.6 qt (open station); 7.4 qt (cab) Crankcase Capacity 5.7 qt 5.1 qt Transmission / Hydraulic System Capacity 3.83 gal 6.8 gal (eHydro); 6.3 gal (PowrReverser) Front Axle Fluid Capacity Not Published 1.2 gal ▶ PTO & HitchPTO Type Live Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability None (no mid-PTO) Optional, 2100 rpm Category, 3-Point Hitch Category I Category 1 Hitch Lift Capacity 1786 lb Not Published Hitch Lift Capacity (at 24”) 1400 lb 2200 lb Lift Control Type Quarter inching valve Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission, 3-range eHydro 3-range hydrostatic (4WD); PowrReverser 12F/12R power shuttle (4WD) No. of Speeds 3-range Infinite forward and reverse, 3 ranges (eHydro); 12 forward, 12 reverse (PowrReverser) Max Travel Speed (Forward) 11.9 mph 19 mph (eHydro); 16.4 mph (PowrReverser) Max Travel Speed (Reverse) 9.5 mph 19 mph (eHydro); 16.4 mph (PowrReverser) Clutch Dry single plate Multiple stage wet disc, 4.4 in (PowrReverser) Differential Lock & Limited Slip Options Rear differential lock standard Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Two-post ROPS (sunshade optional) Two-post folding ROPS; cab optional; MFWD standard Steering Integral type power steering Hydrostatic power steering Brakes Wet disc type Wet disk Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Mechanical front wheel drive (MFWD), standard, all ranges Front Axle Rating Not Published 1587 to 3197 lb Drawbar Capacity 1100 lb 562 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 99.2 in (w/o 3P) (without 3-point hitch) 120.2 in Overall Width 53.7 in 52.4 in (minimum, R1 tires); 68.4 in (maximum, R1 tires) Wheelbase 66.8 in 68 in Ground Clearance 14.6 in Not Published Min. Turn Radius without Brakes 7.9 ft (w/brake) (with brake applied) Not Published Height to Top of ROPS 88.4 in 93.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 89.4 in ▶ WeightTractor Weight (Base) 1764 lb (farm tires); 1786 lb (industrial tires) 2900 lb (open station); 3570 lb (cab) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 bar tread, R3 turf, R4 industrial and golf tires available on all models R1 Agricultural - Front 7-12 7.00-14 R1 Agricultural - Rear 12.4-16 11.2-24 R3 Turf - Front Not Published 27x8.50-15 R3 Turf - Rear 13.6-16 41x14.00-20 R4 Industrial - Front Not Published 25x8.50-14 or 27x8.50-15 R4 Industrial - Rear Not Published 43x16.00-20 or 15.00-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Not Published John Deere quick-attach (Quik-Park); skid-steer style carrier optional on 300CX Loader Model LA504 300X; 300CX; H160; H165; 300R; 320R Loader Lift Height LA504: 82.6 in 300X: 90 in; 300CX: 102 in; H160: 90 in; H165: 102 in; 300R: 90 in; 320R: 102 in Loader Lift Capacity (Full Height) LA504: 1065 lb 300X: 1360 lb; 300CX: 1598 lb; H160: 1360 lb; H165: 1598 lb; 300R: 1360 lb; 320R: 1598 lb (to maximum height at pivot pin) Loader Breakout Force Not Published 300X: 2855 lbf; 300CX: 3327 lbf; H160: 2855 lbf; H165: 3327 lbf; 300R: 2855 lbf; 320R: 3327 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
