▶ EngineEngine Manufacturer Kubota Kubota Engine Model D1005-E-D16 D1703-M-DI-E4 / D1703-M-DI-E4K Engine Type Diesel, 3-cylinder, liquid-cooled Direct injection, vertical, water-cooled 4-cycle, diesel No. of Cylinders 3 3 Displacement 61.1 in³ 100.5 in³ Rated Engine Speed 2600 rpm 2200 rpm Engine Power (Gross) 21 hp 23.3 hp PTO Power Gear: 17 hp; Hydro: 16 hp 18.4 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dual paper element Dry type, single element Fuel System Not Published Direct injection Alternator Not Published 40 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow Not Published 5.2 gpm Steering Flow Not Published 3.1 gpm Total Hydraulic Flow 7 gpm 8.28 gpm (5.15 + 3.13, computed) Overall Hydraulic Pump Flow Not Published 8.28 gpm (5.15 + 3.13, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 5 gal 11.1 gal Coolant Capacity 4 qt 6.3 qt Crankcase Capacity 3.2 qt 6.0 qt Transmission / Hydraulic System Capacity Not Published HST (4WD): 6.9 gal; DT (2WD): 7.4 gal; DT (4WD): 7.5 gal Front Axle Fluid Capacity 3.4 qt 4.8 qt ▶ PTO & HitchPTO Type Gear: transmission-driven; Hydro: independent DT (2WD), DT (4WD): Transmission driven with overrunning clutch; HST (4WD): Live-independent hydraulic PTO with PTO brake, wet PTO Rear 540 rpm 540 rpm Mid-PTO Availability Mid-PTO, 2500 rpm Not Published Category, 3-Point Hitch Category I SAE Category I Hitch Lift Capacity 1356 lb 1874 lb Hitch Lift Capacity (at 24”) 1058 lb 1389 lb Lift Control Type Directional control Position control ▶ Transmission & DrivetrainTransmission Type 6-speed gear; hydrostatic DT (2WD), DT (4WD): Constant mesh with synchronized shuttle; HST (4WD): Hydrostatic transmission (3-range) No. of Speeds Gear: 6 forward, 2 reverse; Hydro: infinite (2-range) DT (2WD), DT (4WD): 8 forward, 8 reverse; HST (4WD): 3-range Max Travel Speed (Forward) Not Published DT (2WD), DT (4WD): 10.7 mph; HST (4WD): 11.5 mph Max Travel Speed (Reverse) Not Published DT (2WD), DT (4WD): 10.7 mph; HST (4WD): 10.3 mph Clutch Dry disc (gear) DT (2WD), DT (4WD): Dry type single stage; HST (4WD): Not Applicable Differential Lock & Limited Slip Options Mechanical rear differential lock Rear differential lock, pedal operated ▶ Chassis, Steering & ControlsFrame Type Two-post ROPS Not Published Steering Power steering Integral type power steering Brakes Wet disc Mechanical, wet disc type Seat Suspension & Adjustability Not Published Suspension seat with fore/aft travel adjustment and suspension tension adjustment Front Axle Type Spur gear final drives Cast-iron front axle Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 730 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 90.4 in DT (2WD): 110.6 in; DT (4WD), HST (4WD): 108.5 in (without 3-point hitch) Overall Width 42.4 in 55.1 in Wheelbase 59 in DT (2WD): 63.8 in; DT (4WD), HST (4WD): 63.4 in Ground Clearance 12 in DT (2WD): 13.6 in; DT (4WD), HST (4WD): 13.4 in Min. Turn Radius without Brakes Not Published DT (2WD): 7.9 ft; DT (4WD), HST (4WD): 8.2 ft (with brake applied) Height to Top of ROPS 76.4 in 91.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) Gear: 1323 lb; Hydro: 1367 lb DT (2WD): 2601 lb; DT (4WD): 2811 lb; HST (4WD): 2833 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard farm 6-12 front, 9.5-16 rear R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 6-12 DT (2WD): 5.0-15; DT (4WD), HST (4WD): 7.2-16 R1 Agricultural - Rear 9.5-16 11.2-24 R3 Turf - Front Not Published DT (2WD): 23X8.50-12; DT (4WD), HST (4WD): 25X8.50-14 R3 Turf - Rear Not Published 13.6-16 R4 Industrial - Front Not Published DT (2WD): Not Applicable; DT (4WD), HST (4WD): 27X8.50-15 R4 Industrial - Rear Not Published DT (2WD): Not Applicable; DT (4WD), HST (4WD): 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System LA272 and LA302 loaders offered Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) Loader Model LA272; LA302 LA526 Loader Lift Height LA272: 69.7 in; LA302: 69.5 in LA526: 94.8 in Loader Lift Capacity (Full Height) LA272: 685 lb; LA302: 770 lb LA526: 1,096 lb Loader Breakout Force LA272: 1003 lbf; LA302: 1120 lbf Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
