▶ EngineEngine Manufacturer Kubota Iseki Engine Model D1005-E-D16 E3112 Engine Type Diesel, 3-cylinder, liquid-cooled 3-cylinder liquid-cooled inline indirect-injection diesel No. of Cylinders 3 3 Displacement 61.1 in³ 68.5 in³ Rated Engine Speed 2600 rpm 2500 rpm Engine Power (Gross) 21 hp 21 hp PTO Power Gear: 17 hp; Hydro: 16 hp Gear: 17.5 hp; Hydro: 16 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dual paper element Dry Fuel System Not Published Indirect injection, glow plug pre-heating Alternator Not Published 40 A ▶ HydraulicsPump Type Not Published Not Published Implement Flow Not Published 5.2 gpm Steering Flow Not Published 2.5 gpm Total Hydraulic Flow 7 gpm 7.7 gpm Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published 1 or 2 ▶ Fluid CapacityFuel Tank Capacity 5 gal 4.75 gal Coolant Capacity 4 qt 5.4 qt Crankcase Capacity 3.2 qt 3.3 qt Transmission / Hydraulic System Capacity Not Published 2.64 gal Front Axle Fluid Capacity 3.4 qt Not Published ▶ PTO & HitchPTO Type Gear: transmission-driven; Hydro: independent Live, two-stage dry disc clutch PTO Rear 540 rpm 540 rpm (1.375 in) at 2327 engine rpm Mid-PTO Availability Mid-PTO, 2500 rpm Live, 2000 rpm at 2500 engine rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1356 lb 1,210 lb Hitch Lift Capacity (at 24”) 1058 lb Not Published Lift Control Type Directional control Position control ▶ Transmission & DrivetrainTransmission Type 6-speed gear; hydrostatic 6-speed gear, hydrostatic, or 9-speed gear with optional creeper range No. of Speeds Gear: 6 forward, 2 reverse; Hydro: infinite (2-range) Gear: 6F / 2R (9F / 3R with creeper); hydrostatic: infinite forward and reverse, 2 ranges Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dry disc (gear) 8.5 in dry disc (gear) Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Two-post ROPS Two-post folding ROPS Steering Power steering 2WD: power steering standard; 4WD: manual, power assist optional Brakes Wet disc Mechanical wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Spur gear final drives 2WD or 4WD; spur gear final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 90.4 in 108.3 in Overall Width 42.4 in 42.2 in Wheelbase 59 in 59.4 in Ground Clearance 12 in 11 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 76.4 in 77 in Height to Top of ROPS (folded) Not Published 60.5 in Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) Gear: 1323 lb; Hydro: 1367 lb 1,477 lb (2WD gear); 1,500 lb (2WD hydro); 1,654 lb (4WD gear); 1,676 lb (4WD hydro) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard farm 6-12 front, 9.5-16 rear Ag: 5.00-12 front (2WD) or 6-12 front (4WD), 9.5-16 rear; turf: 24x8.50-12 front, 315x75D-15 rear R1 Agricultural - Front 6-12 5.00-12 (2WD); 6-12 (4WD) R1 Agricultural - Rear 9.5-16 9.5-16 R3 Turf - Front Not Published 24x8.50-12 R3 Turf - Rear Not Published 315x75D-15 R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System LA272 and LA302 loaders offered Not Published Loader Model LA272; LA302 1242 Loader Lift Height LA272: 69.7 in; LA302: 69.5 in 1242: 73.5 in Loader Lift Capacity (Full Height) LA272: 685 lb; LA302: 770 lb 1242: 565 lb Loader Breakout Force LA272: 1003 lbf; LA302: 1120 lbf 1242: 955 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
