▶ EngineEngine Manufacturer Kubota YANMAR Engine Model D902 3TNM74F Engine Type Liquid-cooled, 4-cycle diesel 4-cycle inline, water-cooled diesel, naturally aspirated No. of Cylinders 3 3 Displacement 54.8 in³ 60.6 in³ Rated Engine Speed 3200 rpm 3200 rpm Engine Power (Gross) 21.6 hp 21.5 hp PTO Power 17.7 hp 15.6 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Water with pressurized radiator, reverse air-flow design Liquid cooled Air Cleaner Dry element Not Published Fuel System Direct injection Not Published Alternator 40 A, 12 V 40 A ▶ HydraulicsPump Type Open center tandem pump gear type Not Published Implement Flow 5.2 gpm 4.3 gpm Steering Flow 1.0 gpm 3.7 gpm Total Hydraulic Flow 6.2 gpm 8.0 gpm (4.3 + 3.7, computed) Overall Hydraulic Pump Flow 6.2 gpm 8.0 gpm (4.3 + 3.7, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None (2-valve rear remote coupler optional) Not Published No. of Optional Remote Valves 2 (optional; ISO 7241-1 series A or B) Not Published ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.1 gal Coolant Capacity 3.3 qt 3.0 qt Crankcase Capacity 3.5 qt 3.1 qt Transmission / Hydraulic System Capacity 3.0 gal 4.1 gal Front Axle Fluid Capacity 3.8 qt 3.17 qt ▶ PTO & HitchPTO Type Live independent PTO (with hydraulic clutch) Independent, hydraulic clutch PTO Rear STD (540 rpm) 554 rpm @ 3,200 engine rpm; 1.4 in OD, 6 splines Mid-PTO Availability STD (2500 rpm) Independent mid-PTO, 2,057 rpm at 3,200 engine rpm, SAE 16/32, 15 splines Category, 3-Point Hitch SAE Category I Limited Category I Hitch Lift Capacity 1,213 lb Not Published Hitch Lift Capacity (at 24”) 680 lb 660 lb Lift Control Type Quarter-inching valve Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission Hydrostatic transmission, dual range speeds No. of Speeds 2 Range (Low-High) Infinite forward and reverse (hydrostatic); 2 ranges Max Travel Speed (Forward) 8.4 mph 9.5 mph (high range, with R4 tires) Max Travel Speed (Reverse) 6.5 mph 6.6 mph (high range, with R4 tires) Clutch None (HST) Not Published Differential Lock & Limited Slip Options Rear differential lock standard Differential lock ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS Full-frame chassis Steering Hydrostatic type power steering Hydrostatic power steering Brakes Mechanical, wet disc type Wet disc Seat Suspension & Adjustability High-back seat with armrests; fore/aft slide and backrest-tilt adjustment Fore-and-aft adjustable operator seat Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Max. drawbar load @ hitch: 550 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 45.1 in 47.3 in (with R4 tires) Wheelbase 55.1 in 57.9 in Ground Clearance 6.5 in 6.4 in (with R4 tires) Min. Turn Radius without Brakes 7.5 ft 7.87 ft Height to Top of ROPS 83.1 in 82.3 in (with R4 tires) Height to Top of ROPS (folded) Not Published 66.3 in (folded ROPS, top of steering wheel, R4 tires) Height to Top of Cab Model Not Published Not Published Overall Length 95.5 in (with 3-point hitch) 102.1 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 1,454 lb 1,537 lb (with ROPS, R4 tires) Weight with ROPS and Loader Not Published 1,962 lb (1,537 + 425, computed) Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R3 Turf; R4 Industrial R1 Agricultural - Front 18X8.5-10 Not Published R1 Agricultural - Rear 26X12-12 Not Published R3 Turf - Front 18X8.5-10 18x8.50-10 4PR R3 Turf - Rear 26X12-12 26x12.0-12 4PR R4 Industrial - Front 18X8.5-10 18x8.50-10 6PR R4 Industrial - Rear 26X12-12 26x12.0-12 4PR ▶ Loader & AttachmentsQuick Attach Loader System Swift-Tach Loader (LA344S - Two Lever Quick Attach Bucket) YL110: YANMAR quick attachment system Loader Model LA344S (standard, quick attach); LA344 (pin-on option) YL110 Loader Lift Height 71.0 in (at pivot pin) YL110: 71 in to pivot pin (51 in under level bucket) Loader Lift Capacity (Full Height) 739 lb (LA344 pin-on); 613 lb (LA344S quick attach) YL110: 825 lb at pivot pin Loader Breakout Force 1,407 lbf (LA344 pin-on); 1,286 lbf (LA344S quick attach) YL110: 1,342 lb at pivot pin ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Private individual use: basic 24 months or 2,000 hours, powertrain 10 years or 3,000 hours; attachments 1 year ▶ ITC Company AccessoriesAccessories that fit None tagged yet
