Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
—
KubotaBX23S
—
BadBoy1022
Comparison loaded for 2 tractors.
Spec
KubotaBX23S
Bad Boy Tractors1022
PTO Power
17.7 hp
15.4 hp
Alternator
40 A, 12 V
40 A, 12 V
Air Cleaner
Sheet net and replaceable treated paper element, spin on oil filter
Water with pressurized radiator, reverse air-flow design
Water-cooled
Engine Manufacturer
Kubota
Yanmar
Engine Power (Gross)
21.6 hp
21.5 hp
Engine Emissions Constraints
Not Published
Tier 4
Tractor Weight with Loader
Not Published
Not Published
Weight with Cab and Loader
Not Applicable
Not Published
Weight with ROPS and Loader
Not Published
1,433 lb
Pump Type
Open center tandem pump gear type
Single gear pump with flow divider
Steering Flow
1.0 gpm
2.11 gpm
Implement Flow
5.2 gpm
4.17 gpm
Total Hydraulic Flow
6.2 gpm
6.97 gpm (max total flow)
Hydraulic System Type
Open center
Not Published
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
6.2 gpm
6.97 gpm (max total flow)
No. of Optional Remote Valves
2 (optional; ISO 7241-1 series A or B)
Up to 1
No. of Standard Remote Valves
Not Published
Not Published
PTO Rear
STD (540 rpm)
540 rpm
PTO Type
Live independent PTO (with hydraulic clutch)
Independent
Lift Control Type
Not Published
Position
Hitch Lift Capacity
Not Published
1,100 lb
Mid-PTO Availability
STD (2500 rpm)
Optional (2,500 rpm)
Category, 3-Point Hitch
SAE Category I Optional
Category I (N)
Hitch Lift Capacity (at 24”)
680 lb
679 lb
R3 Turf - Rear
26X12-12
TURF R 16X12.00-12
R3 Turf - Front
18X8.5-10
TURF F 16X7.50-8
Tire Size & Options
R3 Turf, R4 Industrial
R1 (BAR) / R3 (TURF) / R4 (IND)
R4 Industrial - Rear
26X12-12
26X12-12
R4 Industrial - Front
18X8.5-10
18X8.50-10
R1 Agricultural - Rear
Not Applicable
BAR R 24X12.00-12
R1 Agricultural - Front
Not Applicable
BAR F 16X7.50-9
Coolant Capacity
Not Published
3.7 qt
Crankcase Capacity
Not Published
2.1 qt (with filter)
Fuel Tank Capacity
6.6 gal
6.6 gal
Front Axle Fluid Capacity
Not Published
2.6 qt
Transmission / Hydraulic System Capacity
Not Published
3.6 gal
Loader Lift Height
71.0 in
72.7 in (under level bucket); 78.5 in (pivot pin)
Loader Breakout Force
1,286 lbf (bucket pivot pin)
1,531 lb (at pivot pin, ground level)
Price for Backhoe Option
Already included in base model
Not Published
Price for Mid-Mount Mower
Not Published
Optional 54 in mid-mount mower deck
Quick Attach Loader System
Swift-Tach Loader (LA340S - Two Lever Quick Attach Bucket)
Yes (quick attach)
Loader Lift Capacity (Full Height)
613 lb
992 lb (at pivot pin)
Clutch
Dry type single plate - Main clutch 9.45 in.
Dry single plate
No. of Speeds
2 Range (Low-High)
2 Range
Transmission Type
Hydrostatic transmission
HST
Max Travel Speed (Forward)
8.4 mph
7.8 mph
Max Travel Speed (Reverse)
6.5 mph
Not Published
Differential Lock & Limited Slip Options
Rear differential lock standard
Mechanical rear differential lock
Brakes
Mechanical, wet disc type
Wet disc
Steering
Integral power steering
Hydrostatic
Frame Type
Not Published
Sub-compact tractor, 4WD
Front Axle Type
4WD: Bevel gear front axle, non-adjustable tread spacing
Center pin front axle
Drawbar Capacity
Max. drawbar load @ hitch: 550 lb.
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Not Published
Standard adjustable seat
Wheelbase
55.1 in
53.1 in
Overall Width
45.1 in
44.5 in
Ground Clearance
5.83 in
8.3 in
Height to Top of ROPS
86.2 in
86.6 in
Height to Top of Cab Model
Not Applicable
Not Published
Height to Top of ROPS (folded)
Not Published
Not Published
Min. Turn Radius without Brakes
7.5 ft (2.3 m)
Not Published
Overall Length with 3-Point Hitch
99.0 in (w/ Front guard)
94.2 in
Financing Options
Check with your local dealer for the best offer.
Payments as low as $180.00/month
Base Price with Loader
$27,603 MSRP as low as (BX23S model offering includes front loader)
Not Published
Warranty Length & Coverage
Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours.
