▶ EngineEngine Manufacturer Kubota Yanmar Engine Model D902 3TNM74F-NCJT Engine Type Liquid-cooled, 4-cycle diesel Diesel No. of Cylinders 3 3 Displacement 54.8 in³ 60 in³ Rated Engine Speed 3200 rpm 3200 rpm Engine Power (Gross) 21.6 hp 21.5 hp PTO Power 17.7 hp 16.2 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry element Not Published Fuel System Direct injection Not Published Alternator 40 A, 12 V Not Published ▶ HydraulicsPump Type Open center tandem pump gear type Gear Implement Flow 5.2 gpm 3.5 gpm Steering Flow 1.0 gpm 3.5 gpm Total Hydraulic Flow 6.2 gpm 7 gpm Overall Hydraulic Pump Flow 6.2 gpm 7 gpm Hydraulic System Type Open center tandem pump gear type Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None (2-valve rear remote coupler optional) Not Published No. of Optional Remote Valves 2 (optional; ISO 7241-1 series A or B) Not Published ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 5.57 gal Coolant Capacity 3.3 qt Not Published Crankcase Capacity 3.4 qt Not Published Transmission / Hydraulic System Capacity 2.98 gal Not Published Front Axle Fluid Capacity 3.8 qt Not Published ▶ PTO & HitchPTO Type Live independent PTO (with hydraulic clutch) Independent PTO Rear STD 540 rpm 540 rpm Mid-PTO Availability USA No.5 (KUBOTA 10-tooth) involute spline, 2500 rpm Standard, 2100 rpm Category, 3-Point Hitch SAE Category I (optional) Limited Category I Hitch Lift Capacity 1,213 lb Not Published Hitch Lift Capacity (at 24”) 680 lb 758 lb Lift Control Type Quarter-inching valve Select control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission, high-low gear shift (2 forward, 2 reverse) Hydrostatic - 2 range No. of Speeds 2 Range (Low-High) Infinite (hydrostatic), 2 ranges forward and reverse Max Travel Speed (Forward) 0 mph to 8.4 mph 9.1 mph Max Travel Speed (Reverse) 0 mph to 6.5 mph 9.1 mph Clutch Dry type single plate - Main clutch 9.45" Not Published Differential Lock & Limited Slip Options Rear differential lock standard Not Published ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS Foldable ROPS, standard equipment Steering Hydrostatic Power Steering Power steering Brakes Mechanical, wet disc type Wet disc, left-hand pedal Seat Suspension & Adjustability High-back reversible seat (rotates for backhoe operation); fore/aft slide and backrest tilt adjustment Suspension seat, high back, adjustable settings; no tilt steering Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing Four-wheel drive (mechanical front-wheel drive) Front Axle Rating Not Published Not Published Drawbar Capacity Maximum tongue weight 550 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 45.1 in 47.22 in (R3 tires); 47.32 in (R4 tires) Wheelbase 55.1 in 57.1 in Ground Clearance 6.5 in (front axle) Not Published Min. Turn Radius without Brakes 7.5 ft Not Published Height to Top of ROPS 86.2 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 99.0 in (with 3-point hitch, with front guard) Not Published ▶ WeightTractor Weight (Base) 1,600 lb (with ROPS, front guard and control valve assembly) 1,475 lb (shipping weight, open station) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front Turf/Industrial: 18×8.5-10; Rear Turf/Industrial: 26×12-12; Bar tire N/A R3 Turf, R3 Hybrid, or R4 R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front 18×8.5-10 18x8.50-10 R3 Turf - Rear 26×12-12 26x12-12 R4 Industrial - Front 18×8.5-10 18x8.5-10 R4 Industrial - Rear 26×12-12 26x12-12 ▶ Loader & AttachmentsQuick Attach Loader System Kubota Swift-Tach (Quick attach) Tool-free attach and park Loader Model LA340S (standard, quick attach); LA340 (pin-on option) 120R Loader Lift Height 71.0 in (at pivot pin) 120R: 72 in Loader Lift Capacity (Full Height) 739 lb (LA340 pin-on); 613 lb (LA340S quick attach) 120R (NSL): 704 lb (at pivot, full height) Loader Breakout Force 1,407 lbf (LA340 pin-on); 1,286 lbf (LA340S quick attach) Not Published ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours Powertrain 6 years or 2,000 hours, standard at no cost, covers residential and commercial use ▶ ITC Company AccessoriesAccessories that fit None tagged yet
