Not explicitly published as a combined ROPS+loader figure in sources found. Tractor-only weight is 1,632 lb (740 kg).
Weight with Cab and Loader
Not Applicable
Not Applicable
Warranty Length & Coverage
Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours.
Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours.
Pump Type
Hydrostatic transmission
Dual pump
Steering Flow
1.0 gpm
Not Published
Implement Flow
6.2 gpm (23.5 l/min.)
8.3 gal/min total - open center dual pump system shared between steering and implement circuits; individual split not published
Total Hydraulic Flow
6.2 gpm
8.3 gpm 31.4 lpm
Hydraulic System Type
Open center tandem pump gear type
open center
System Operating Pressure
12.3 MPa to 12.8 MPa
—
Rear Remote Hydraulic Flow
Not Published
8.3 gal/min (total system - individual remote valve flow not separately published)
Overall Hydraulic Pump Flow
6.2 gpm
8.3 gpm
No. of Optional Remote Valves
2 (optional; ISO 7241-1 series A or B)
1 (single rear remote is optional)
No. of Standard Remote Valves
2 valves
Not Published
PTO Rear
STD 540 rpm
540
PTO Type
Live independent PTO (with hydraulic clutch)
Independent
Lift Control Type
Quarter-inching valve
position control
Hitch Lift Capacity
1,213 lbs.
1808 lbs.
Mid-PTO Availability
STD (2500rpm)
independent, 2500
Category, 3-Point Hitch
SAE Category 1
I
Hitch Lift Capacity (at 24”)
680 lb
1290 lb
R3 Turf - Rear
26×12-12
22x8.50-12
R3 Turf - Front
18×8.5-10
22x8.50-12
Tire Size & Options
Front Turf/Industrial: 18×8.5-10; Rear Turf/Industrial: 26×12-12; Bar tire N/A
Ag (R1): 7-12 front / 11.2-16 rear; Turf (R3): 22x8.50-12 front / 22x8.50-12 rear; Industrial (R4): 23x8.50-12 front / 12-16.5 rear; also Goodyear R14 hybrid multi-purpose tire available
R4 Industrial - Rear
26×12-12
12-16.5
R4 Industrial - Front
18×8.5-10
23x8.50-12
R1 Agricultural - Rear
Not Applicable
11.2-16
R1 Agricultural - Front
Not Applicable
7-12
Coolant Capacity
0.8 gal (3.3 U.S.qts.)
4.0 qts.
Crankcase Capacity
0.9 gal (3.4 U.S.qts.)
3.3 qts.
Fuel Tank Capacity
6.6 gal (6.6 U.S.gals.)
6.1 gal
Front Axle Fluid Capacity
Not Published
Not Published
Transmission / Hydraulic System Capacity
2.98 U.S. gals.
4.0 gal
Loader Lift Height
71.0 in
78.5 in.
Loader Breakout Force
6258 N (1407 lbs) [LA340] / 5719 N (1286 lbs) [LA340S]
